NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 1038NDA-24297, Issue 1
T-26 Toll Restriction - 3/6-Digit - CCIS
Programming (cont’d)
DC: 91914 TDI: 1 (Allow)
This allows these specific Area Codes. All Area Codes not assigned are automatically restricted.

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 1039
Trunk Answer from Any Station - CCIS T-27
T-27  Trunk Answer from Any Station - CCIS
General Description
This feature allows any station not restricted from incoming calls to answer incoming calls when the network is in
Night mode.
When this feature is activated, incoming Central Office calls will activate a common TRUNK ANSWER FROM
ANY STATION (TAS) signal. By dialing a specified code, any station may answer the call and extend it to...

NEAX2400 IPX Feature Programming ManualPage 1040NDA-24297, Issue 1
T-27 Trunk Answer from Any Station - CCIS
Interactions
The system must be in the Night Mode for TAS to operate. Take into consideration the type of ATTENDANT
CONSOLE [A-3] system that is in service. Take special care when setting the resistance value via switch settings
on the PA-CS07 ATTENDANT CONSOLE [A-3] Circuit Card.
Programming
STEP 1:ASYD- SYS1, Index 68, bit 2. Type of TAS ringing; 0/1: Continuous/Interrupted.
SYS1, Index 77, bit...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 1041
Uniform Numbering Plan - CCIS U-5
U-5  Uniform Numbering Plan - CCIS
General Description
In a CCIS network, a Uniform Numbering Plan enables a user to call any other station in the network using a
Uniform Numbering system. Two alternative numbering plans are provided:
In the first plan, the user dials a four or five-digit station number. The node in which the called station is
located is identified by either the first digit or the first...

NEAX2400 IPX Feature Programming ManualPage 1042NDA-24297, Issue 1
U-5 Uniform Numbering Plan - CCIS
Interactions
If seven-digit Uniform Numbering Plans are used, an access code to the CCIS network may be added. Thus, a total
of eight digits will be dialed. For example, a user in Illinois wishes to reach a CCIS station number (753-4526) in
New York. Two options exist for network setup. The digit 8 may be programmed as a CCIS network access code,
such as a Least Cost Routing access code. The user then...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 1043
Uniform Numbering Plan - CCIS U-5
Programming (cont’d)
STEP 9:AO PR- The AFRS command designates the dialing sequence and the OPR to be selected. The AOPR
defines the routes and in what order these routes will be selected. In this case, the DTI routes will be
assigned. Also, it may be desirable to include DDD trunks as an overflow. Assign the following
parameters:
TDC NO. - Time-of-Day Pattern Change. Usually, this parameter does NOT...

NEAX2400 IPX Feature Programming ManualPage 1044NDA-24297, Issue 1
V-7 Voice Call - CCIS
V-7  Voice Call - CCIS
General Description
This service feature allows Inter-office VOICE CALL when the calling Dterm/Single-line Station and the called
Dtermbelong to different PBX’s in the CCIS network.
Operating Procedure
From a Dterm to a Dterm
1. Dterm(a) places a call to Dterm(b) through a CCIS line; receives ringback tone. Dterm(b) rings.
2. D
term(b) still does not answer. Dterm(a), then presses the VOICE key...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 1045
Voice Call - CCIS V-7
Operating Procedure (cont’d)
2. Station (a) switch hook flashes and receives special dial tone. Dterm(b) still does not answer.
3. Station (a) dial the Access Code of VOICE CALL service and sends out a signal tone to D
term(b) via the
speaker. Dterm(b) talks with Station (a) via the speaker.
Service Conditions
1. Once a VOICE CALL is executed, the message“VOICE on multi-line set”is displayed on the called
station....

NEAX2400 IPX Feature Programming ManualPage 1046NDA-24297, Issue 1
