NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 988NDA-24297, Issue 1
N-15 Night Connection - Fixed - CCIS
N-15  Night Connection - Fixed - CCIS
General Description
When the Night mode has been entered, this service feature routes calls, normally directed to the ATTENDANT
CONSOLE [A-3], to a preselected station in another node through CCIS.
Operating Procedure
1. The Night lamp illuminates, when the Attendant in Node A sets Night mode with the NITE key pressed.
2. An incoming call from the CO RT to the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 989
Night Connection - Fixed - CCIS N-15
Operating Procedure (cont’d)
3. Station C answers and is connected with the CO RT. If necessary, the call can be transferred to another
station by means of Call Transfer-All Calls service.
Service Conditions
1. Calls that are being processed, or are in the Hold state when the NIGHT mode is entered, will be
disconnected after the mode changeover has been completed.
2. If the NIGHT CONNECTION station to...

NEAX2400 IPX Feature Programming ManualPage 990NDA-24297, Issue 1
N-16 Night Connection - Flexible - CCIS
N-16  Night Connection - Flexible - CCIS
General Description
This feature provides inter-office flexible Night Connection service through the CCIS network, when the NIGHT
CONNECTION-FIXED - CCIS and NIGHT CONNECTION-FLEXIBLE - CCIS stations are located in different
nodes.
Operating Procedure
To set
1. The NIGHT CONNECTION-FIXED - CCIS station in the destination office sets CALL FORWARDING-
ALL CALLS...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 991
Name Display - System - CCIS N-37
N-37  Name Display - System - CCIS
General Description
In between CCIS networks, this service allows calling or called party information (user’s name, telephone number,
etc.) to be displayed on the LCD of the Dterm.
Operating Procedure
No manual operation is required.
Service Conditions
1. When the called party is being rung, the LCD of the calling Dtermdisplays the name of the called party.
2. When the...

NEAX2400 IPX Feature Programming ManualPage 992NDA-24297, Issue 1
N-37 Name Display - System - CCIS
Service Conditions (cont’d)
11. When a call has been transferred by Call Forwarding-All Outside Line Calls or Call Forwarding-Busy
Outside Line service, the LCD of the calling party’sDtermdisplays the name information of the transfer
destination instead of the name information of the originally dialed station.
12. This service cannot be used in conjunction with ISDN Information Transfer - CCIS service.
13....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 993
Name Display - System - CCIS N-37
Programming (cont’d)
STEP 2:ARTD- Assign route class data for CCIS trunk route.
RT:
43-BT :1 50-DPLY :1 98-CI :0 112-IND :1

NEAX2400 IPX Feature Programming ManualPage 994NDA-24297, Issue 1
N-46 Number Portability - CCIS
N-46  Number Portability - CCIS
General Description
This feature allows telephone number data in an FCCS group (a network where multiple NEAX2400 IPXs are
connected via FCCS link) to be carried to another FCCS group. This feature also allows telephone number data to
be carried in a NEAX2000 IVS
2via CCIS link. This feature is available by simple command operation from the sole
Centralized MAT.
Note 1
Note 1:...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 995
Number Portability - CCIS N-46
Service Conditions (cont’d)
Legend:
* Destination node
** Node to be connected to the FCCS group where the new number is added
*** Node where the telephone number is located before the Number Portability activation
FCCS Programming
This data setting describes only the additional or replacement commands used to activate FCCS
services. When used as an FCCS feature, these commands replace the non-network...

NEAX2400 IPX Feature Programming ManualPage 996NDA-24297, Issue 1
N-46 Number Portability - CCIS
FCCS Programming (cont’d)
SYSTEM: Checkbox either of the checkboxes, depending on system type (NEAX2400 IPX 1/4/16
IMG system or NEAX2000 IVS2system)
TYPE: Checkbox either of the checkboxes, allocation of the telephone numbers is executed by
designating LENs or station number
Note 2
FUG: Enter the FUG number the designated station belongs toNote 2
FPC: Enter the FCCS network Point Code the designated station...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 997
Off-Hook Queuing - CCIS O-11
O-11  Off-Hook Queuing - CCIS
General Description
This feature allows a user in a CCIS network to remain off-hook and automatically enter a first-in, first-out queue
at the calling and distant nodes when an all-trunk-busy condition has been encountered. As soon as an outgoing trunk
becomes available, the off-hook station is connected to that trunk through CCIS.
Operating Procedure
1. Dial the trunk access code...
