NEAX2400 IPX Feature Programming ManualPage 1028NDA-24297, Issue 1
S-60 Synchronous Data Switching - CCIS
Programming (cont’d)
For Data Module
STEP 1:ASDT- Assign levels 1, 2, & 3 of a PA-4DTL as TEC = 16. Also assign an RSC and SFC.
STEP 2:ASFC- For TEC = 16 stations, assign an SFC that, at a minimum, SFI 11 = 0, DATA LINE
SECURITY.
STEP 3:ARSC- Construct a Route Restriction Class that allows access to the desired incoming and outgoing
routes. Those routes include PA-24DTA ACIS and CCIS routes.
STEP...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 1029
Supervisory Call - CCIS S-73
S-73  Supervisory Call - CCIS
General Description
This feature allows an Attendant, in a CCIS network, to set Supervisory Call status before releasing a Central Office
call to a station. When the call is extended to a station, the loop will remain up until the called station answers. This
overrides ATTENDANT LOOP RELEASE [A-6] on a per call basis.
Operating Procedure
To activate a SUPERVISORY CALL - CCIS from...

NEAX2400 IPX Feature Programming ManualPage 1030NDA-24297, Issue 1
S-73 Supervisory Call - CCIS
Programming
STEP 1:ASYD- SYS2, Index 7, bit 3. Supervisory Call service. 0/1. Out/In Service. SYS1, Index 43, bit 4.
Attendant re-enters loop on supervisory call? 0/1: Restricted/Allowed.

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 1031
Toll Restriction - 3/6-Digit - CCIS T-26
T-26  Toll Restriction - 3/6-Digit - CCIS
General Description
This feature allows the NEAX2400 IPX to restrict outgoing calls through CCIS according to specific Area and/or
Central Office codes. This restriction is determined on the basis of a three-digit Area Code or six-digit Area and
Office Code numbering plan.
Operating Procedure
No manual operation is required.
Service Conditions
1. The...

NEAX2400 IPX Feature Programming ManualPage 1032NDA-24297, Issue 1
T-26 Toll Restriction - 3/6-Digit - CCIS
Programming (cont’d)
See DAY/NIGHT CLASS OF SERVICE[D-15].
SYS2, Index 1, bit 3. Does TOLL RESTRICTION apply to SPEED CALLING - STATION? 0/1: Yes/
No.
SYS2, Index 1, bits 4 & 5. If TOLL DENIAL is required assign these bits as data“00”.IfTOLL
DIVERSION is required assign these bits as“01”.
SYS2, Index 1, bit 7. Does TOLL RESTRICTION apply to SPEED CALLING - SYSTEM? 0/1: Yes/
No.
STEP 2:ARSC- Assign...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 1033
Toll Restriction - 3/6-Digit - CCIS T-26
Programming (cont’d)
OGRT: Outgoing Route Number
DC: Destination (Area) Code (Maximum 11 digits)
TDI: Restriction Data*
0: Connection is Restricted
1: Connection is Allowed
2: 3/6-Digit Toll Restriction [Go to AARP]
3: C.O. Operator Call 9 + 0.
NND: Number of Necessary Digits (Used only when TDI = 2).
Note:TDI 4 may appear when the digits input under the DC parameter are incorrect. The switch is...

NEAX2400 IPX Feature Programming ManualPage 1034NDA-24297, Issue 1
T-26 Toll Restriction - 3/6-Digit - CCIS
Programming (cont’d)
Notice that assignments for digit codes 90 and 91 which cover operator calls and all 1 + Area Codes
calls are not assigned. Digit Codes (DC) which are not assigned are automatically restricted.
AARP Command -
Not Required. This command is only required when TDI = 2 is assigned in ATDP.
Example 2 - RSC 2 Assignment
ATDP Command -
TDM/OG: O (Outgoing Connection)
DAY/NIGHT: D...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 1035
Toll Restriction - 3/6-Digit - CCIS T-26
Programming (cont’d)
This allows office codes 239, 465, & 798 to Area Code 914. All other office codes are automatically
restricted.
Note that this method of assignment allows office codes 239, 465 & 798 to any Area Code that is
assigned as TDI = 2 in ATDP.
For example, if the assignment for Area Code 718 was changed from TDI = 1 (allowed) to TDI = 2,
then the office codes 239, 465, & 798 would...

NEAX2400 IPX Feature Programming ManualPage 1036NDA-24297, Issue 1
T-26 Toll Restriction - 3/6-Digit - CCIS
Programming (cont’d)
DC: 912 TDI: 2 (Go to AARP Command)
NND: 3
DC: 913 TDI: 2 (Go to AARP Command)NND:3
DC: 914 TDI: 2 (Go to AARP Command)NND:3
\\\\ (Through) \\\\
DC: 919 TDI: 2 (Go to AARP Command)NND:3
This tells the system to check AARP tables for all Area Code restrictions.
AARP Command -
OGRT: 1 RSC: 4 FLAG: 1 DC: 808 RES: 0*
OGRT: 1 RSC: 3 FLAG: 1 DC: 213 RES: 0*
OGRT: 1 RSC: 3 FLAG: 1 DC:...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 1037
Toll Restriction - 3/6-Digit - CCIS T-26
Programming (cont’d)
DC: 000000 RES: 1 (Allowed)
This will restrict 976 and allow every other Office Code.
STEP 6:ARRC- This command provides trunk-to-trunk connection abilities according to the requirements of
the system. The applicable trunk-to-trunk will be those connections provided by parameter ARI-D-
RES direct connection. For example, REMOTE ACCESS TO THE SYSTEM [R-2] and TANDEM
SWITCHING...
