NEAX2400 IPX Feature Programming ManualPage 388NDA-24297, Issue 1
I-2 Incoming Call Identification
Programming
STEP 1:ASYD- System Data 2, Indexes 8 & 9, flag the type of incoming calls the Attendant Console should
expect.
Note
Index 8
Bit 0: Listed Directory Number
Bit 1: Incoming Station Call
Bit 2: Attendant Recall
Bit 3: FX
Bit 4: WATS
Bit 5: CCSA (DID)
Bit 6: TIE Line
Bit 7: Call Forwarding Busy Line
Index 9
Bit 0: Call Forwarding Don’tAnswer
Bit 1: Call Forwarding Intercept
Bit 2: Special Common...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 389
Incoming Central Office Call to Tie-Line Connection I-3
I-3  Incoming Central Office Call to Tie-Line
Connection
General Description
This feature permits an Attendant to connect an incoming public network exchange call, via a TIE Line, to a station
at a distant PBX.
Operating Procedure
To connect an incoming call
1. The Attendant presses the LDN key and answers the incoming trunk call.
2. Dial the TIE Line access code; receive dial tone...

NEAX2400 IPX Feature Programming ManualPage 390NDA-24297, Issue 1
I-3 Incoming Central Office Call to Tie-Line Connection
Interactions (cont’d)
4. Stations must be allowed access to the routes they will need via the appropriate connection status, either
via the Attendant Console (RRI 2) or Direct connection (RRI 3).
5. Various combinations of TRUNK-TO-TRUNK [T-10] connections can be restricted by Alternate Route
Restriction (ARRC command).
Programming
STEP 1:ARTD- Assign the Central Office route as shown...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 391
Incoming Central Office Call to Tie-Line Connection I-3
FCCS Programming
This data setting describes only the additional or replacement commands used to activate FCCS
services. When used as an FCCS feature, these commands replace the non-network commands (for
example, AAED is replaced by AAEDN). Note that the data setting for FCCS service varies depending
on the node.
STEP 1:ARTDN- Assign the Central Office route as shown below:
GROUND...

NEAX2400 IPX Feature Programming ManualPage 392NDA-24297, Issue 1
I-4 Individual Trunk Access
I-4  Individual Trunk Access
General Description
This feature permits an Attendant to access an individual trunk within a trunk group via dial access at the
ATTENDANT CONSOLE [A-3].
Operating Procedure
1. Press the TKSL key.
2. Dial the trunk route number (2 digits or 3 digits).
3. Dial the trunk identification number (3 digits).
4. If the trunk is idle, dial tone will be received.
OR
1. Press an idle TKSL key....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 393
Individual Trunk Access I-4
Programming
STEP 1:ASYD- System Data 1, Index 68, Bit 1. Designates the method the Attendant Console must use to
operate INDIVIDUAL TRUNK ACCESS. 0/1: Route & Trunk Number/Listed Directory Number
(Central Office Code, ACOC).
System Data 1, Index 68, Bit 4. Is Trunk Select Key in service? 0/1: No/Yes. Assign data 1.
Optional
STEP 2:ARTD- If the Central Office Code option is exercised, assign data“1”in CDN 25....

NEAX2400 IPX Feature Programming ManualPage 394NDA-24297, Issue 1
I-5 Inter-position Transfer
I-5 Inter-position Transfer
General Description
This feature allows Attendants to transfer calls at their ATTENDANT CONSOLE [A-3] to another Attendants
Console in systems where MULTIPLE CONSOLE OPERATION [M-4] has been provided.
Operating Procedure
To transfer a call from Attendant Console A to Attendant Console B
1. Press the START key.
2. Attendant A dials Attendant Console B identification number, or“0”for...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 395
Inter-position Transfer I-5
FCCS Programming
This data setting describes only the additional or replacement commands used to activate FCCS
services. When used as an FCCS feature, these commands replace the non-network commands (for
example, AAED is replaced by AAEDN). Note that the data setting for FCCS service varies depending
on the node.
 Note
STEP 1:ASPAL- This data must be set to the node calling attendant, Assign SRV = SSC, SID = 2...

NEAX2400 IPX Feature Programming ManualPage 396NDA-24297, Issue 1
I-6 Individual Attendant Access
I-6  Individual Attendant Access
General Description
This feature permits a user to call a particular ATTENDANT CONSOLE [A-3] via an individual Attendant
identification number.
Operating Procedure
1. The user dials the individual Attendant identification number.
2. The directed Attendant gets INCOMING CALL IDENTIFICATION (ICI) [I-2] indication (“ATND”)and
can answer using the normal operating procedure....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 397
I-Hold Indication - DtermI-7D
I-7D  I-Hold Indication - Dterm
General Description
This feature provides the Dtermwith a distinctive flash to differentiate between a call the user placed on hold from
other calls.
Operating Procedure
No manual operation is required.
Service Conditions
Condition of the LED is as follows:
Programming
This is a Dtermfeature. No programming is required.
Burst Wink
LIT On
Off0 0.5 1.0 1.5 Seconds
