NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 438NDA-24297, Issue 1
L-6D Last Number Called - Dterm
Service Conditions (cont’d)
12. If making an abbreviated call using the REDIAL key, the number dialed is not stored. Therefore, redialing
through LAST NUMBER CALL - stock redial is not available. A newly dialed destination is stored in
accordance with the following flowchart:
Stack #1
Stack #2
Stack #3
Stack #4
Stack #5
Yes
No
The dialed destination and the number stored in the Stack Memory 2 are the same?...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 439
Last Number Called - DtermL-6D
Service Conditions (cont’d)
Programming
STEP 1:AKYD- Assign a programmable line/feature key as the LAST NUMBER CALLED key, if necessary.
KYI: Service Index 1 (= Feature Key)
FKY: Feature Key Number 8 (= LAST NUMBER CALLED)
STEP 2:ASDT-AssignaD
termwith TEC (Telephone Equipment Class) 12.
Stack #1
Stack #2
Stack #3
Stack #4
Stack #5
Yes
No
The dialed destination and the number stored in the Stack Memory 5 are...

NEAX2400 IPX Feature Programming ManualPage 440NDA-24297, Issue 1
L-7D Line Reconnect - Same Line - Dterm
L-7D  Line Reconnect - Same Line - Dterm
General Description
This feature allows a user to disconnect a call and receive dial tone by pressing the RECALL key.
Operating Procedure
While a call is in progress
1. Press the RECALL key; disconnect and receive dial tone on the same line.
2. Userisreadytodialagain.
Service Conditions
1. Conflicting service features are: CALL TRANSFER - ALL CALLS [C-11],...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 441
Line Reconnect - Other Line - DtermL-8D
L-8D  Line Reconnect - Other Line - Dterm
General Description
This feature allows a user to select another line key without going on-hook.
Operating Procedure
While off-hook on the original line, press a line key that is either idle or ringing; the user is disconnected from the
original line and connected to the new line.
Service Conditions
1. LINE RECONNECT - OTHER LINE Dtermcannot be used with a...

NEAX2400 IPX Feature Programming ManualPage 442NDA-24297, Issue 1
L-9D Line Pre-selection - Dterm
L-9D  Line Pre-selection - Dterm
General Description
This feature provides the user with the ability to select an idle or ringing line before going off-hook.
Operating Procedure
To originate
1. Press the desired line key; receive dial tone.
2. Dial the desired destination.
To answer
1. Press the line key (ringing and flashing LED alerts incoming call).
2. Lift the handset or press SPEAKER key; answer the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 443
LCR - Time Of Day Routing L-10
L-10  LCR - Time Of Day Routing
General Description
This feature provides automatic routing of outgoing calls over alternative customer facilities, based on the
destination code. The system will select the most economical route available at the time of connection. The pattern
of alternate routing can be changed up to 8 times per day, based on a prearranged time schedule.
Operating Procedure
1. Lift the...

NEAX2400 IPX Feature Programming ManualPage 444NDA-24297, Issue 1
L-10 LCR - Time Of Day Routing
Programming (cont’d)
STEP 2:ASDC- If 6-digit translation is required where both the Area and Office codes must be examined, this
command must be used. The system is automatically set as an Allow table. To create a Deny table,
assign the following:
OFFICE: 0
EFFECT: 1
Program the type of route as PFX (Prefix, Foreign Exchange, FX) or as SCC (Special Common
Carrier).
Choose TDC PTN, Time-of-Day Pattern. Go to...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 445
LCR - Time Of Day Routing L-10
FCCS Programming (cont’d)
Route Number(RT) - The physical Route Number to be selected.
Skip Digits(SKIP) - The digits to be skipped when translating the dialed digits in AFRS. If ARTD is
assigned as shown, at a minimum, always assign“1”to skip the LCR (S) access code.
Pattern Number Location(PNL) - If digits are to be added after translating the dialed digits in AFRS,
go to the AADC command.
Overflow...

NEAX2400 IPX Feature Programming ManualPage 446NDA-24297, Issue 1
L-11 Line Load Control
L-11  Line Load Control
General Description
This feature allows the Attendant to deny a preselected group of stations the ability to originate calls by activating
a key. The sole intention of this feature is to temporarily restrict the least important internal stations from outward
calling during an excessive traffic load or emergency conditions.
Operating Procedure
To activate from the ATTENDANT CONSOLE [A-3]
1....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 447
Line Load Control L-11
Programming
STEP 1:ASYD- System Data 1, Index 59, Bit 0. Should the system restrict incoming calls during LINE LOAD
CONTROL? 0/1: No/Yes.
Note:Incoming calls terminated to CCIS/ISDN cannot be restricted.
STEP 2:ANPD- Reserve a number level for feature access and cancel. Assign Connection Indexes, CI = N, H,
B; Normal (N), Hooking (H), and Busy (B) (applicable to any feature assigned to this level). Assign
NND in...
