NEC Neax 2400 Ipx Feature Programming Manual
Here you can view all the pages of manual NEC Neax 2400 Ipx Feature Programming Manual . The NEC manuals for Communications System are available online for free. You can easily download all the documents as PDF.
Page 451
NEAX2400 IPX Feature Programming ManualPage 408NDA-24297, Issue 1 I-21 Internal Zone Paging Operating Procedure (cont’d) b.) To Answer by using Off-Hook key:Note 2 Note 1: The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s). Note 2:Using Prime Line or Off-Hook to answer is selected by the ASYD SYS1, Index 388, bit 4 0/1: Press Prime Line key after Off-Hook/Press Off-Hook. Note 3:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3. bit 0=0: 2-digit...
Page 452
![Page 452
NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 409
Internal Zone Paging I-21
Operating Procedure (cont’d)
c.) To answer by using CALL PICKUP-DIRECT [C-30]:
Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s).
Note 2:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3.
bit 0=0: 2-digit (group 01~99) Ex. When IZPG=1, dial 01.
bit 0=1: 3-digit (group 001~255) Ex. When IZPG=1, dial 001.
OPERATIONTONE CONTROLDTERM DISPLAY
CALLING...](http://img.usermanuals.tech/thumb/54/84273/w300_nec-neax2400-ipx-feature-programming-manual_d-451.png "Page 452
NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 409
Internal Zone Paging I-21
Operating Procedure (cont’d)
c.) To answer by using CALL PICKUP-DIRECT [C-30]:
Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s).
Note 2:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3.
bit 0=0: 2-digit (group 01~99) Ex. When IZPG=1, dial 01.
bit 0=1: 3-digit (group 001~255) Ex. When IZPG=1, dial 001.
OPERATIONTONE CONTROLDTERM DISPLAY
CALLING...")
NEAX2400 IPX Feature Programming Manual NDA-24297, Issue 1Page 409 Internal Zone Paging I-21 Operating Procedure (cont’d) c.) To answer by using CALL PICKUP-DIRECT [C-30]: Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s). Note 2:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3. bit 0=0: 2-digit (group 01~99) Ex. When IZPG=1, dial 01. bit 0=1: 3-digit (group 001~255) Ex. When IZPG=1, dial 001. OPERATIONTONE CONTROLDTERM DISPLAY CALLING...
Page 453
![Page 453
NEAX2400 IPX Feature Programming ManualPage 410NDA-24297, Issue 1
I-21 Internal Zone Paging
Operating Procedure (cont’d)
d.) To answer by using CALL PICKUP-GROUP [C-7]:
Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s).
Note 2:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3.
bit 0=0: 2-digit (group 01~99) Ex. When IZPG=1, dial 01.
bit 0=1: 3-digit (group 001~255) Ex. When IZPG=1, dial 001.
OPERATIONTONE CONTROLDTERM DISPLAY
CALLING...](http://img.usermanuals.tech/thumb/54/84273/w300_nec-neax2400-ipx-feature-programming-manual_d-452.png "Page 453
NEAX2400 IPX Feature Programming ManualPage 410NDA-24297, Issue 1
I-21 Internal Zone Paging
Operating Procedure (cont’d)
d.) To answer by using CALL PICKUP-GROUP [C-7]:
Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s).
Note 2:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3.
bit 0=0: 2-digit (group 01~99) Ex. When IZPG=1, dial 01.
bit 0=1: 3-digit (group 001~255) Ex. When IZPG=1, dial 001.
OPERATIONTONE CONTROLDTERM DISPLAY
CALLING...")
NEAX2400 IPX Feature Programming ManualPage 410NDA-24297, Issue 1 I-21 Internal Zone Paging Operating Procedure (cont’d) d.) To answer by using CALL PICKUP-GROUP [C-7]: Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s). Note 2:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3. bit 0=0: 2-digit (group 01~99) Ex. When IZPG=1, dial 01. bit 0=1: 3-digit (group 001~255) Ex. When IZPG=1, dial 001. OPERATIONTONE CONTROLDTERM DISPLAY CALLING...
Page 454
![Page 454
NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 411
Internal Zone Paging I-21
Operating Procedure (cont’d)
2. Voice Call by Internal Zone Paging [I-20] (Station Hold)
a.) To answer: Using Prime Line:
Note 2
Note 1:
The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s).
Note 2:Using Prime Line or Off-Hook to answer is selected by the ASYD SYS1, Index 388, bit 4 0/1: Press Prime
Line key after Off-Hook/Press Off-Hook.
Note 3:The number of digit of IZP group number...](http://img.usermanuals.tech/thumb/54/84273/w300_nec-neax2400-ipx-feature-programming-manual_d-453.png "Page 454
NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 411
Internal Zone Paging I-21
Operating Procedure (cont’d)
2. Voice Call by Internal Zone Paging [I-20] (Station Hold)
a.) To answer: Using Prime Line:
Note 2
Note 1:
The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s).
Note 2:Using Prime Line or Off-Hook to answer is selected by the ASYD SYS1, Index 388, bit 4 0/1: Press Prime
Line key after Off-Hook/Press Off-Hook.
Note 3:The number of digit of IZP group number...")
NEAX2400 IPX Feature Programming Manual NDA-24297, Issue 1Page 411 Internal Zone Paging I-21 Operating Procedure (cont’d) 2. Voice Call by Internal Zone Paging [I-20] (Station Hold) a.) To answer: Using Prime Line: Note 2 Note 1: The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s). Note 2:Using Prime Line or Off-Hook to answer is selected by the ASYD SYS1, Index 388, bit 4 0/1: Press Prime Line key after Off-Hook/Press Off-Hook. Note 3:The number of digit of IZP group number...
Page 455
NEAX2400 IPX Feature Programming ManualPage 412NDA-24297, Issue 1 I-21 Internal Zone Paging Operating Procedure (cont’d) b.) To answer by using Off-Hook key:Note 2 Note 1: The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s). Note 2:Using Prime Line or Off-Hook to answer is selected by the ASYD SYS1, Index 388, bit 4 0/1: Press Prime Line key after Off-Hook/Press Off-Hook. Note 3:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3. bit 0=0: 2-digit...
Page 456
![Page 456
NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 413
Internal Zone Paging I-21
Operating Procedure (cont’d)
c.) To answer by using Call Pickup-Direct [C-30]:
Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s).
Note 2:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3.
bit 0=0: 2-digit (group 01~99) Ex. When IZPG=1, dial 01.
bit 0=1: 3-digit (group 001~255) Ex. When IZPG=1, dial 001.
OPERATIONTONE CONTROLDTERM DISPLAY...](http://img.usermanuals.tech/thumb/54/84273/w300_nec-neax2400-ipx-feature-programming-manual_d-455.png "Page 456
NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 413
Internal Zone Paging I-21
Operating Procedure (cont’d)
c.) To answer by using Call Pickup-Direct [C-30]:
Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s).
Note 2:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3.
bit 0=0: 2-digit (group 01~99) Ex. When IZPG=1, dial 01.
bit 0=1: 3-digit (group 001~255) Ex. When IZPG=1, dial 001.
OPERATIONTONE CONTROLDTERM DISPLAY...")
NEAX2400 IPX Feature Programming Manual NDA-24297, Issue 1Page 413 Internal Zone Paging I-21 Operating Procedure (cont’d) c.) To answer by using Call Pickup-Direct [C-30]: Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s). Note 2:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3. bit 0=0: 2-digit (group 01~99) Ex. When IZPG=1, dial 01. bit 0=1: 3-digit (group 001~255) Ex. When IZPG=1, dial 001. OPERATIONTONE CONTROLDTERM DISPLAY...
Page 457
![Page 457
NEAX2400 IPX Feature Programming ManualPage 414NDA-24297, Issue 1
I-21 Internal Zone Paging
Operating Procedure (cont’d)
d.) To answer by using Call Pickup-Group [C-7]:
Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s).
Note 2:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3.
bit 0=0: 2-digit (group 01~99) Ex. When IZPG=1, dial 01.
bit 0=1: 3-digit (group 001~255) Ex. When IZPG=1, dial 001.
OPERATIONTONE CONTROLDTERM DISPLAY
OPERATING...](http://img.usermanuals.tech/thumb/54/84273/w300_nec-neax2400-ipx-feature-programming-manual_d-456.png "Page 457
NEAX2400 IPX Feature Programming ManualPage 414NDA-24297, Issue 1
I-21 Internal Zone Paging
Operating Procedure (cont’d)
d.) To answer by using Call Pickup-Group [C-7]:
Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s).
Note 2:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3.
bit 0=0: 2-digit (group 01~99) Ex. When IZPG=1, dial 01.
bit 0=1: 3-digit (group 001~255) Ex. When IZPG=1, dial 001.
OPERATIONTONE CONTROLDTERM DISPLAY
OPERATING...")
NEAX2400 IPX Feature Programming ManualPage 414NDA-24297, Issue 1 I-21 Internal Zone Paging Operating Procedure (cont’d) d.) To answer by using Call Pickup-Group [C-7]: Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s). Note 2:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3. bit 0=0: 2-digit (group 01~99) Ex. When IZPG=1, dial 01. bit 0=1: 3-digit (group 001~255) Ex. When IZPG=1, dial 001. OPERATIONTONE CONTROLDTERM DISPLAY OPERATING...
Page 458
NEAX2400 IPX Feature Programming Manual NDA-24297, Issue 1Page 415 Internal Zone Paging I-21 Operating Procedure (cont’d) 3. Voice Call by Internal Zone Paging (Trunk Hold) a.) ToanswerbyusingPrimeLine: Note 2 Note 1: The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s). Note 2:Using Prime Line or Off-Hook to answer is selected by the ASYD SYS1, Index 388, bit 4 0/1: Press Prime Line key after Off-Hook/Press Off-Hook. Note 3:The number of digit of IZP group number is...
Page 459
NEAX2400 IPX Feature Programming ManualPage 416NDA-24297, Issue 1 I-21 Internal Zone Paging Operating Procedure (cont’d) b.) To answer by using Off-Hook key:Note 2 Note 1: The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s). Note 2:Using Prime Line or Off-Hook to answer is selected by the ASYD SYS1, Index 388, bit 4 0/1: Press Prime Line key after Off-Hook/Press Off-Hook. Note 3:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3. bit 0=0: 2-digit...
Page 460
![Page 460
NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 417
Internal Zone Paging I-21
Operating Procedure (cont’d)
c.) To answer by using Call Pickup-Direct [C-30]:
Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s).
OPERATIONTONE CONTROLDTERM DISPLAY
OPERATING
PARTYCALLED
PARTYOPERATING
PARTYCALLED
PARTYCALLING
PARTYOPERATING
PARTYCALLED
PARTYCALLING
PARTY
(1) Receive a
call
(2) Perform the
SHF(1) Special
Dial Tone can
be heard(1) MSC
can be
heard
(3)...](http://img.usermanuals.tech/thumb/54/84273/w300_nec-neax2400-ipx-feature-programming-manual_d-459.png "Page 460
NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 417
Internal Zone Paging I-21
Operating Procedure (cont’d)
c.) To answer by using Call Pickup-Direct [C-30]:
Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s).
OPERATIONTONE CONTROLDTERM DISPLAY
OPERATING
PARTYCALLED
PARTYOPERATING
PARTYCALLED
PARTYCALLING
PARTYOPERATING
PARTYCALLED
PARTYCALLING
PARTY
(1) Receive a
call
(2) Perform the
SHF(1) Special
Dial Tone can
be heard(1) MSC
can be
heard
(3)...")
NEAX2400 IPX Feature Programming Manual NDA-24297, Issue 1Page 417 Internal Zone Paging I-21 Operating Procedure (cont’d) c.) To answer by using Call Pickup-Direct [C-30]: Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s). OPERATIONTONE CONTROLDTERM DISPLAY OPERATING PARTYCALLED PARTYOPERATING PARTYCALLED PARTYCALLING PARTYOPERATING PARTYCALLED PARTYCALLING PARTY (1) Receive a call (2) Perform the SHF(1) Special Dial Tone can be heard(1) MSC can be heard (3)...
