NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 398NDA-24297, Issue 1
I-8D I-Use Indication - Dterm
I-8D  I-Use Indication - Dterm
General Description
This feature provides the Dtermwith a unique LED indication to display the particular line the user is on.
Operating Procedure
Manual operation is not required.
Service Conditions
Condition of LED is as follows:
Programming
This is a Dtermfeature. No programming is required.
    Burst Wink
On
Off0.5 1.01.5Seconds
Lit

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 399
Intercom Calling I-9
I-9 Intercom Calling
General Description
This feature allows a sub-line appearance, assigned to a Dterm,tobeusedforINTERCOMCALLING.
Operating Procedure
To originate
1. Press the Intercom sub-line appearance.
2. Lift the handset or press the SPEAKER key; dial tone is heard.
3. Dial an Intercom station, receive ringback tone. The display will show:
4. The called party answers and the conversation begins.
To answer
1....

NEAX2400 IPX Feature Programming ManualPage 400NDA-24297, Issue 1
I-9 Intercom Calling
Interactions (cont’d)
Numbering Consists of the following:
30-39
Stations in Group Calling would dial only two digits to reach other members of the group.
2. All My-line STATION-TO-STATION CALLING [S-11] capabilities such as VOICE CALL-D
term[V-
2D], MESSAGE REMINDER-Dterm[M-19D], CALL BACK [C-1], etc. are denied because INTERCOM
CALLING uses a virtual circuit sub-line appearance.
3. An incoming Intercom Call will be...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 401
Intercom Calling I-9
Programming (cont’d)
27: Eight Conference Equipment
RSC: Route Restriction Class (0-15)
For assignment of RSC, ARSC command.
SFC: Service Feature Class (0-15)
For assignment of SFC, ASFC command.
STEP 5:AISA- Program the tenant, station, type of station, and the number of SPEED CALLING blocks to be
assigned to the Primary station. One MY Line station of each GROUP CALLING group is assigned as
the Primary. The Primary...

NEAX2400 IPX Feature Programming ManualPage 402NDA-24297, Issue 1
I-10D Intermediate Station Number Display - Dterm
I-10D  Intermediate Station Number Display - Dterm
General Description
This feature provides an LCD display to the called and calling Dtermstation when an intermediate station has been
involved in call processing.
Operating Procedure
No manual operation is required.
Service Conditions
1. For a transferred call, the LCD displays:
Note:When the telephone number of the intermediate or...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 403
Inter-Office Off-Hook Queuing I-11
I-11 Inter-Office Off-Hook Queuing
General Description
This feature can be employed in a Main-Satellite configuration to allow a Satellite user to queue for LEAST COST
ROUTING - 3/6-DIGIT [L-5] at the Main location. This feature can also be used when all outgoing facilities are
concentrated at the Main location.
Operating Procedure
Operation at the Main location
1. The Main location receives dialed...

NEAX2400 IPX Feature Programming ManualPage 404NDA-24297, Issue 1
I-11 Inter-Office Off-Hook Queuing
Service Conditions (cont’d)
7. OGQ data is transmitted to and stored in the Network Control Node (NCN). Therefore, all the OGQ data
will be cleared by the system initialization of the NCN.
8. When the access to the NCN is impossible (system down or the cable disconnection or trouble has
occurred), the user cannot set or cancel OGQ data. After dialing the access code or pressing the feature
keys for...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 405
Inter-Office Off-Hook Queuing I-11
FCCS Programming (cont’d)
Index 68, b3: Enables automatic cancel timer
0/1 = -/Automatic cancel timer is Available
Index 159: Designate Automatic Cancel Timer
STEP 2:ASPAN- These data must be assigned to the NCN.
TN: Tenant Number
ACC: Access number
CI: B = Busy (for Entry), N = Normal (for Cancel)
SRV: SSC
SID: 19 = OG Queuing-Entry
CI: N = Normal
SID: 20 = OG Queuing-Cancel
Note 1:When using ASYDL or...

NEAX2400 IPX Feature Programming ManualPage 406NDA-24297, Issue 1
I-20 Immediate Ringback Tone
I-20  Immediate Ringback Tone
General Description
IMMEDIATE RINGBACK TONE will be heard by the caller immediately upon determination by the system that
the called station is idle. IMMEDIATE RINGBACK TONE is connected, even if the call occurs during the OFF
portion of the ringing cycle.
Operating Procedure
When a station calls another station or Attendant
1. The station goes off hook, hears dial tone, and dials...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 407
Internal Zone Paging I-21
I-21  Internal Zone Paging
General Description
This feature allows an individual to make a voice call through the Dtermspeakers of the designated group by dialing
the INTERNAL ZONE PAGING access code or pressing the INTERNAL ZONE PAGING key on the Dterm.
Operating Procedure
To originate
1. Lift the handset; receive dial tone.
2. Dial the access code or press the feature key for INTERNAL ZONE PAGING [I-21];...
