NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 428NDA-24297, Issue 1
L-5 Least Cost Routing - 3/6-Digit
Programming
STEP 1:ASYD- System Data 1, Index 6, Bit 0. Should special Sender Tone be sent to station when connected
to a sender? 0/1: No/Yes. (Optional)
System Data 1, Index 6, Bit 2. Should special Sender Tone be sent to the Attendant Console when
connected to a sender? 0/1: No/Yes. (Optional)
System Data 1, Index 65. Assign the number of routes in the system.
System Data 2, Index 2, Bit 0. What is the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 429
Least Cost Routing - 3/6-Digit L-5
Programming (cont’d)
Note:These same routes may also be listed in ASPA for SRV = OGC (Outgoing Call). In that case, these routes
may also be available via direct dial access codes. In ARNP, these access codes are not assigned to
implement the LCRS service in this command. This digit code is the first digit used when assigning the ATDP
table.
STEP 8:ARSC- LCR(S) uses only Bothway or Outgoing Only routes....

NEAX2400 IPX Feature Programming ManualPage 430NDA-24297, Issue 1
L-5 Least Cost Routing - 3/6-Digit
Programming (cont’d)
OPR No.(OPR) - Outgoing Pattern Route. The number referenced in AFRS, consisting of a series of
routes to be chosen based on number dialed.
Route Advance Number(RA) - The order in which a route will be selected (0-7). For the above
example; RA0 = Band 1, RA1 = Band 5, RA2 = DDD.
Route Advance End Display(E) - The last route in the route advance group is indicated with data“0”.
All...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 431
Least Cost Routing - 3/6-Digit L-5
Programming (cont’d)
When assigning for SCC, each NXX is assigned as the following:
EFFECT: 0 = Restricted
EFFECT: 1 = Allowed
EFFECT: 2 = Not Used
Note:*WhenPFX, EFFECT = 1 is assigned. Add the required digit in the AADC command. OFFICE is the next
3 digits after those assigned in AFRS.
Example: AFRS RT31 = 91214 OPR1
ASDC checks next 3 digits: 91214 XXX XXXX
STEP 14:AT C P- A maximum of eight...

NEAX2400 IPX Feature Programming ManualPage 432NDA-24297, Issue 1
L-5 Least Cost Routing - 3/6-Digit
FCCS Programming (cont’d)
STEP 7:AO PRL/N - The AFRSL/N command designates the dialing sequence and the OPR to be selected.
The AOPRL/N defines the routes and in what order these routes will be selected.
Assign the following:
TDPTN No.(TDPTN) - Time of Day Pattern Change. Designate 1-7 if different OPRs will be required
according to the time. Enter“0”if the OPR, assigned in AFRSL/N, is to be applied.
OPR...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 433
Least Cost Routing - 3/6-Digit L-5
FCCS Programming (cont’d)
When assigning for SCC, each NXX is assigned as the following
EFFECT: 0=Restricted
EFFECT: 1=Allowed
EFFECT: 2=Not used
Note:*WhenPFX, EFFECT = 1 is assigned. Add the required digit in the AADCL/N command. OFFICE is the
next 3 digits after those assigned in AFRSL/N.
Example: AFRSL/N RT31 = 91214 OPR1
ASDCL/N checks next 3 digits: 91214 XXX XXXX
Office

NEAX2400 IPX Feature Programming ManualPage 434NDA-24297, Issue 1
L-6 Last Number Called - Single-Line Station
L-6  Last Number Called - Single-Line Station
General Description
When a user originates a station-to-station call or an outgoing trunk call, but the call is not established, this feature
allows the calling station to recall the same destination by dialing only the special code instead of dialing all the
digits of the number.
Operating Procedure
1. Lift the handset; receive dial tone.
2. Dial...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 435
Last Number Called - Single-Line Station L-6
Programming (cont’d)
STEP 3:ASFC- Assign the stations to receive the feature LAST NUMBER CALLED a Service Feature Class
that allows SFI = 44.
FCCS Programming
This data setting describes only the additional or replacement commands used to activate FCCS
services. When used as an FCCS feature, these commands replace the non-network commands (for
example, AAED is replaced by AAEDN). Note that the...

NEAX2400 IPX Feature Programming ManualPage 436NDA-24297, Issue 1
L-6D Last Number Called - Dterm
L-6D  Last Number Called - Dterm
General Description
This feature allows the user of a Dtermto store the last five numbers dialed, and to redial the numbers by pressing
the REDIAL key. The Dtermuser can choose any destination out of the last 5 calls that have been stored in memory,
thus enabling the user to place a call without redialing the full number.
Operating Procedure
How to check the dialed numbers...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 437
Last Number Called - DtermL-6D
Operating Procedure (cont’d)
6. The called party answers the call.
a.) The Prime Line lights green.
b.) The Speaker Lamp is OFF.
Service Conditions
1. A maximum of 5 destinations can be stored.
2. The maximum digits of the destination is 32 digits.
3. When a feature key has been assigned as Last Number Called, the feature key also works as REDIAL key.
4. This feature is also effective when the calling party...
