NEAX2400 IPX Feature Programming ManualPage 418NDA-24297, Issue 1
I-21 Internal Zone Paging
Operating Procedure (cont’d)
Note 2:The number of digit of IZP group number is determined by SYS1, Index 804, bit 3.
bit 0=0: 2-digit (group 01~99) Ex. When IZPG=1, dial 01.
bit 0=1: 3-digit (group 001~255) Ex. When IZPG=1, dial 001.
d.) To answer by using Call Pickup-Group [C-7]
Note 1:The number of the chime can be set by ASYD SYS1, Index 321, b7 0/1: 4/1 time (s).
Note 2:The number of digit of IZP group number...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 419
Internal Zone Paging I-21
Service Conditions
1. The number of Internal Zone Paging groups is a maximum of 99 groups for each tenant.
2. Each D
termcan be a member of multiple Internal Zone Paging groups.
3. A maximum of 255 groups per system can be simultaneously paged using this feature.
4. This feature is activated to idle stations in an Internal Zone Paging group.
5. When all INTERNAL ZONE PAGING groups are busy, Busy Tone is sent.
6....

NEAX2400 IPX Feature Programming ManualPage 420NDA-24297, Issue 1
I-21 Internal Zone Paging
Service Conditions (cont’d)
21. Using Prime Line or Off-Hook to answer can be selected. If this selection is not unified between each node
within the FCCS network, execute the method of answering assigned to each node when answering a
phone.
22. When selected FCCS trunk is busy or FCCS link failure (Layer 2 down) occurs at FCH card, Busy Tone
is sent (or Busy is displayed on a LCD).
23. When IZP group number...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 421
Internal Zone Paging I-21
Programming (cont’d)
STEP 5:AIZP- Assign INTERNAL ZONE PAGING group data.
TN: Tenant number of calling party
IZPG: INTERNAL ZONE PAGING group number
IZPTN: Tenant number of IZPSTN
IZPSTN: Station number assigned to the INTERNAL ZONE PAGING group
STEP 6:AKYD-ForD
termsets, INTERNAL ZONE PAGING can be activated using a programmable line/
feature key. Assign KYI=1, FKY=28 (Answer) for answering INTERNAL ZONE PAGING...

NEAX2400 IPX Feature Programming ManualPage 422NDA-24297, Issue 1
L-1 Lamp Check
L-1 Lamp Check
General Description
This feature allows the Attendant, by pressing the LCHK key, to light all lamps and sound the ATTENDANT
CONSOLE [A-3] buzzer.
Operating Procedure
1. Attendant presses the Position Busy key; the LED lights.
2. Attendant simultaneously presses the HOLD, SRC and L3 keys.
3. All lamps will light.
Service Conditions
1. Every lamp field, including the BUSY LAMP FIELD - FLEXIBLE [B-2], will be lit...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 423
Line Lockout L-3
L-3 Line Lockout
General Description
This feature provides for the automatic release of a station from the common equipment when it has remained off-
hook for longer than the usual interval before dialing. The NEAX2400 IPX may be programmed to return a Howler
Tone to the station in the LINE lock-out mode.
Operating Procedure
For LINE lock-out
1. User goes off-hook and receives dial tone.
2. After approximately 12 seconds,...

NEAX2400 IPX Feature Programming ManualPage 424NDA-24297, Issue 1
L-3 Line Lockout
Interactions (cont’d)
5. CALL WAITING [C-12, 31]: Call Waiting cannot be activated on a station in lock-out. The calling party
will receive reorder tone.
6. CALL HOLD [C-6]: From a special dial tone state, LINE lock-out will occur if a user attempting to place
a station on hold dials the CALL HOLD [C-6] access code and partially dials any number. The sequence
prior to lock-out is: interdigit time-out for 6 seconds, reorder...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 425
Least Cost Routing - 3/6-Digit L-5
L-5  Least Cost Routing - 3/6-Digit
General Description
This feature allows the NEAX2400 IPX to be programmed to route outgoing calls over the most economical facility
(WATS, FX, DDD). Based on the area code and office code dialed (6-digit analyzing), the system examines the
programming tables and chooses the facilities in the order specified. Least-Cost Routing (LCR) may also be
performed on a sender...

NEAX2400 IPX Feature Programming ManualPage 426NDA-24297, Issue 1
L-5 Least Cost Routing - 3/6-Digit
Service Conditions (cont’d)
3/6-digit Least Cost Routing Translation Table, Dialed Number 9-NPA-NXX-XXXX
6. In certain cases, 3 and 6-digit translation will provide sufficient information for identification of the
service area. 4000 separate Outgoing Routing Patterns are available for this circumstance.
7. Up to 8 trunk routes can be in each Outgoing Routing Pattern.
8. STATION MESSAGE DETAIL RECORDING...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 427
Least Cost Routing - 3/6-Digit L-5
Service Conditions (cont’d)
18. The system will include the ability to detect a dialed DDD number and compare it with a DDD list table
to determine if the call is directed to a facility served by the trunk network. If the dialed number is found
in the DDD list table, a translation is provided to the 7-digit on-net number (ABC-XXXX) served by the
TIE Trunk. This allows an expensive public network dialed...
