14. Auto Image Stabilizer (STABILIZER)
This function electronically compensates for an unstable camera image due to movement of a mounting pole or bracket. The
default setting is OFF.
ON:Automatically compensates for an unstable image.
OFF:Image stabilizer will not operate.
Important:
•When set to ON, some effective pixels on the edge of the CCD are used by the stabilization function. This may result in a
small reduction in resolution and a narrower angle of view. After activating the image stabilizer...

32
FIX: Fixes the back-focus after adjustment.
5. Select ON or OFF for SETUP-SW LOCK. The default setting is OFF.
OFF: Enables the [SET] button to open the back-focus adjustment screen while the camera picture is displayed.
ON: Disables the [SET] button from opening the back-focus adjustment screen.
6. To reset the back-focus to the default setting, press the [LEFT] and [RIGHT] buttons simultaneously.
Important:
•Select FIX or PRESET and adjust manually the back-focus when automatic adjustment is...

33
3. Move the cursor to the center of a blemish position until its
appearance becomes less obvious. Finally, press the [SET]
button.
→The horizontal and vertical positions (coordinate) of the
blemish will be displayed with a 6-digit number on the sec-
ond bottom line.
→The blemish position is registered to be compensated.
→The screen returns to the PIX OFF menu that displays the
number followed by an asterisk if it has been registered.
4. Repeat above steps as necessary.
5. To cancel a registration,...

34
Reference
pages Cause/solutionSymptom
•Are the power cord and coaxial cable connected appropri-
ately?
→Check whether the connection is appropriately estab-
lished.
Troubleshooting
No image displayed
Blurred image
Damaged power cord
sheathing
Heated portion of power
cord during use.
Warmed power cord or
loosened connection by
bending or stretching dur-
ing use.
LED not lit
14
•Is the monitor luminance appropriately adjusted, or is the
contrast appropriately adjusted?
→Check whether the monitor...

35
Specifications
Color CCTV Cameras
Power source and power
consumption: WV-CW384: 24 V AC 50 Hz, 18 W, 12 V DC, 560 mA
WV-CW380: 220 V to 240 V AC, 50 Hz, 14 W
Image sensor: 1/3-inch type interline transfer CCD
Effective pixels: 752 (H) x 582 (V)
Scanning area: 4.8 mm (H) x 3.6 mm (V)
Scanning system: 2:1 interlace
Scanning frequency: Horizontal: 15.625 kHz, Vertical: 50.00 Hz
Synchronization: Multiplexed vertical drive (VD2), line-lock (LL), internal (INT)
Resolution: Horizontal: 570 TV lines (BW...

36
Lens
Focal length: f=5 mm - 40 mm (8x variable focal lens)
F number: F1.6 (WIDE) - F1.9 (TELE)
Focus range:∞- 1.2 m
Angle of view: Horizontal: 6.6°(TELE) - 52.0°(WIDE)
Vertical: 5.0°(TELE) - 39.6°(WIDE)
Camera mount bracket
Adjusting angle: Panning range: ±100°
Tilting range: +30°, –90°
Dimensions: 125 (W) mm x 125 (H) mm x 143 (D) mm
Weight: 240 g
Finish: Aluminum die cast with silver metallic coating
Adapter box
Dimensions: 133 (W) mm x 133 (H) mm x 50 (D) mm
Weight: 510 g
Finish: Aluminium die...

37
Information on Disposal for Users of Waste Electrical & Electronic Equipment (private households)
This symbol on the products and/or accompanying documents means that used electrical and electronic products should not be
mixed with general household waste.
For proper treatment, recovery and recycling, please take these products to designated collection points, where they will be
accepted on a free of charge basis. Alternatively, in some countries you may be able to return your products to your local...

38
WARNUNG:
• Dieses Gerät muss geerdet werden.
• Alle mit der Installation dieses Produktes verbundenen Arbeiten
sollten von qualifiziertem Kundendienstpersonal oder System-
installateuren vorgenommen werden.
• Anschlüsse müssen den örtlichen elektrotechnischen Vor-
schriften entsprechen.
Wir erklären in alleiniger Verantwortung, daß das Produkt, auf das sich
diese Erklärung bezieht, mit der folgenden Normen oder normativen
Dokumenten übereinstimmt. Gemäß den Bestimmungen der Richtlinie
2006/95/EC und...

39
Wichtige Sicherheitsinstruktionen ................................................................................................................................................. 40
Beschränkung der Haftung  ........................................................................................................................................................... 41
Haftungsausschluss...

40
Wichtige Sicherheitsinstruktionen
1) Bitte lesen Sie diese Instruktionen aufmerksam durch.
2) Bewahren Sie die Instruktionen sorgfältig auf.
3) Befolgen Sie alle Warnungen.
4) Befolgen Sie alle Instruktionen.
5) Reinigen Sie dieses Gerät nur mit einem trockenen Tuch.
6) Blockieren Sie nicht die Belüftungsöffnungen. Installieren Sie das Gerät gemäß den Instruktionen des Herstellers.
7) Installieren Sie dieses Gerät niemals in der Nähe von Wärmequellen wie Heizkörpern, Öfen oder anderen wärme-...
