Panasonic Digital Color Imaging System DP-C106 Operating Instructions

Network Problem Solving Problem Solving
129
Job Management Problem Solving
This section lists error messages you might see, and provides some
troubleshooting guidelines should a problem arise with the Printer. If you are
unable to resolve a problem after referring to this chapter, contact your
authorized service/support center.
Job Management Error Messages
Error messages can result from problems with the print job, a server, or the
DP-C106. Some of the most common error conditions are listed here....

Problem Solving Network Problem Solving
130
Message Corrective Action/Additional
Information
Print/Copy Cartrdg. type mismatched The Print/Copy Cartridge installed is
not the correct cartridge. Remove the
cartridge and check your
documentation for specifications on the
correct cartridge to install.
Printing . . . This is a normal status message
indicating that printing is in progress.
Ready within 1 minute This is a normal status message. The
Printer is warming up. It will be ready
for printing in a...

Network Problem Solving Problem Solving
131
 Unexpected Printing Results
If this Happens This is the Problem
A cover page is not printed when
you reprint a saved raster jobCover pages are not printed with saved
raster jobs that have already printed.
The job settings are not carried
out as you expectedIf printing from a Mac OS, refer to Print
Options in CDs Operating Instructions
for the table of job properties and
conflicting properties.
If you expected the settings you see in
the Properties window, be...

Problem Solving Network Problem Solving
132
Clearing the Printer
Clearing the Printer is an Administrator option that can be used as a last
resort if a job persists in the system and prevents printing despite attempts to
cancel or delete it. Clearing the Printer deletes all jobs currently saved in any
queue and all locally archived jobs. It also clears the Job Log and the index of
archived jobs.
Before clearing the Printer, export the Job Log if you have not recorded the
information in it. If you can,...

133
Maintenance
Cleaning Procedures
This section contains the recommended cleaning procedures for the DP-C106.
Cleaning the Printer Covers
The Printer does not require cleaning. However, if you wish to clean the
outside covers, perform the following procedure.
WARNING
Always switch Off the power and disconnect the power cord from the wall
outlet in order to avoid an electrical shock when cleaning the DP-C106.
1.  Moisten a clean cloth and wipe any stains from the covers.
2.  Wipe dry with a clean dry...

Maintenance Cleaning Procedures
134
Cleaning the Scanner
For the best copies, it is recommended that you clean the Scanner at least
once a month.
Document Glass and ADF Cover
If the Document Glass is dirty, the copy quality can be less than desirable. If
the inside of the ADF becomes dirty, the document size may not be
detectable by the Scanner.
1.  Lift the ADF.
2.  Moisten a clean, soft cloth with water and wipe the glass.
3.  Wipe dry with a clean, dry, soft cloth.
4.  Moisten another clean, soft...

Cleaning Procedures Maintenance
135
Cleaning the Document Feeder (ADF)
Document jams can be created by dirt on the feed rollers or the feed belt of
the ADF.  It is recommended that you clean the feeder once a month.
1.  Lift the ADF.
2.  Moisten a clean soft cloth with water and wipe the feed belt.
3.  Wipe dry with a clean and dry soft cloth.
CAUTION
Use care when pulling the feed belt.  Always pull it evenly and firmly toward
the Right-hand side of the Scanner.
a.  When the visible area is clean, grasp...

Maintenance Cleaning Procedures
136
4.  Close the ADF.
5.  Open the Jam Access Cover.
6.  Clean the Feed Rollers as shown.
7.  Close the Jam Access Cover.

Replacing the Toner Cartridges Maintenance
137
Replacing the Toner Cartridges
Use this procedure when you are referred here from the Problem Solving
section, or when a message to install a Toner Cartridge is displayed on the
Control Panel.
1.  Open the Printer Front Cover.
2.  If the cartridge to be replace is not visible in the opening perform the
following steps:
a. Press the Anti-rotation Button..

Maintenance Replacing the Toner Cartridges
138
b. Turn the Rotary Knob in the direction of the arrow until it stops.
c.  Repeat the steps until the desired cartridge is visible in the opening.
3.  With the desired cartridge visible in the opening, turn the cartridge in the
direction of the arrow until the Dot is aligned with the Unlock symbol.
4.  Pull the Toner Cartridge out of the Printer.
WARNING
DO NOT attempt to use old cartridges, as they could cause print quality
problems.
NEVER dispose of old...
