Panasonic Digital Color Imaging System DP-C106 Operating Instructions

Clearing Area 1 Jams Problem Solving
79
7.  Close the Bypass Tray.
8.  Reload the Bypass Tray with the desired stock and ensure that the width
guide is adjusted to the size of the stock.

Problem Solving Clearing Area 1 Jams
80
This page is intentionally left blank.

Clearing Area 2 Jams Problem Solving
81
Clearing Area 2 Jams
Perform this procedure when the message CLEAR JAM IN AREA 2 is
displayed on the Control Panel.
1.  Lower the Area 2 Access Cover.
2.  Remove any jammed or torn stock from Area 2.  Ensure that there are
no pieces of torn stock remaining in the area.
3.  Close the Access Cover.

Problem Solving Clearing Area 2 Jams
82
This page is intentionally left blank.

Clearing Area 3 Jams Problem Solving
83
Clearing Area 3 Jams
Perform this procedure when the message CLEAR JAM IN AREA 3 is
displayed on the Control Panel.
1.  Open the Area 3 Access Door.
2.  Remove any jammed or torn paper as shown below.  Ensure that there
are no pieces of torn paper remaining in the feed area.
3.  Close the Access Door.

Problem Solving Clearing Area 3 Jams
84
This page is intentionally left blank.

Clearing Area 4 Jams Problem Solving
85
Clearing Area 4 Jams
Perform this procedure when the message CLEAR JAM IN AREA 4 is
displayed on the Control Panel.
1.  Open the Area 4 Top Left-hand Cover.
2.  Remove the jammed paper.  If the paper is torn ensure that there are no
pieces of torn paper remaining in the Printer.
3.  Close the Top Left-hand Cover.

Problem Solving Clearing Area 4 Jams
86
This page is intentionally left blank.

Clearing Area 5 Jams Problem Solving
87
Clearing Area 5 Jams
Perform one of the following procedures when the message CLEAR JAM IN
AREA 5 is displayed on the Control Panel.
•  If you do not have the Duplex Unit/Kit option installed perform the
Clearing the Fuser Area procedure below.
•  If you have the Duplex Unit/Kit option installed, go to the Clearing the
Upper Inverter.
Clearing the Fuser Area
1.  In order to access Area 5, pull open the Fuser Area Access Cover.
WARNING
The Fuser may be hot.  Use...

Problem Solving Clearing Area 5 Jams
88
3.  If the paper is not visible, turn the Green Knob in the direction shown.
4.  Ensure that there are no pieces of torn paper remaining in the Fuser
Area.
5. Return the Green Lever to the original position.
Firmly close the Fuser Area Access Cover.
