Panasonic Digital Color Imaging System DP-C106 Operating Instructions

Clearing Area 5 Jams Problem Solving
89
Clearing the Upper Inverter
1.  In order to access Area 5, pull open the Upper Inverter.
2.  To release any paper, lift the Green Lever, and gently pull the paper in
the direction of the arrow. If the paper is not visible, turn the Green
Knob in the direction of the arrow.

Problem Solving Clearing Area 5 Jams
90
3.  Open the small, clear, cover and ensure that all the paper and paper bits
are removed.
a.  If paper is visible under the clear cover, hold the cover open and
push the paper toward the paper exit with your fingers.

Clearing Area 5 Jams Problem Solving
91
b.  Pull the paper in the direction of the arrow shown below.
c.  If paper is only partially visible under the cover, check under the
tray for access to the paper.
d.  Pull the paper down and remove.
0301112A-W O L

Problem Solving Clearing Area 5 Jams
92
4.  Close the small clear cover and move the Green Lever to the lower
position.
0301113A-WOL
5.  Firmly close the Upper Inverter.

Clearing Area 6 Jams Problem Solving
93
Clearing Area 6 Jams
Perform this procedure when the message CLEAR JAM IN AREA 6 is
displayed on the Control Panel.
1.  In order to access Area 6, open the Lower Inverter Cover.
2.  Remove the jammed paper.  Ensure that there are no pieces of torn
paper remaining in the Lower Inverter.
3.  Close the Lower Inverter Cover.

Problem Solving Clearing Area 6 Jams
94
Clearing Jams in the 10 Bin Sorter
1.  Read the messages that display on the copier and printer control panels.
2.  Slide the 10 Bin Sorter to the left away from the DP-C106.
3.  Lift the Jam Clearance Cover.
4. Lift the Green Handle and gently remove any sheets that are jammed in
the output area.
5.  Close the Jam Clearance Cover.
6.  Continue to follow the messages that display in the copier and printer
control panels and clear any additional jams that have...

Copy/Print Quality Problems Problem Solving
95
Copy/Print Quality Problems
If the problem still exists after following the instructions in this table, call your
local Authorized Panasonic Representative.
Description Possible Cause Action
Faded print/copy Printer out of adjustment.Go to Adjusting the Color in
this section.
The Print/Copy Cartridge is
old or damaged.Go to Replacing the
Supplies in the
Maintenance section.
If only some colors are
faded, a Toner Cartridge is
old or damaged.Go to Replacing...

Problem Solving Copy/Print Quality Problems
96
Blank pages Sheets of paper are
sticking together.Remove the paper stack
from the Paper Tray. Fan
the corners of the stack,
and replace it in the Paper
Tray.
The Low Toner  message
is displayed on the Control
Panel.Go to Replacing the Toner
Cartridges in the
Maintenance section.
The Print/Copy Cartridge is
old or damaged.Go to Replacing the
Print/Copy Cartridge in the
Maintenance section.
Vertical blanks The Print/Copy Cartridge is
old or damaged.Go to...

Adjusting the Printer Color Problem Solving
97
Adjusting the Printer Color
Perform this procedure if you have color problems such as insufficient
amounts of one or more colors, or excessive amounts of one or more colors.
If a message to replace a Color Toner Cartridge is displayed on the Printer
Control Panel, replace the cartridge BEFORE performing this adjustment.
VisualCal
There are three parts to the VisualCal adjustment.  Do not skip any steps or
perform any part out of sequence.
If you wish to stop...

Problem Solving Adjusting the Printer Color
98
d.  If you see all the circles in a row, write 0 next to the row.
6.  Repeat step 5 for each color rows, drawing circles around your preferred
selections or recording a 9 or a 0 next to the row.
7. For the 30% MATCH row, hold the sheet at arms length.  Select the
circle that best matches the background and draw a circle around it.
8. BLACK START 4 is displayed on the Printer Control Panel.  Press the
(        ) ARROW buttons to enter the number that...
