Panasonic Digital Color Imaging System DP-C106 Operating Instructions

10 Bin Sorter Error Messages Problem Solving
109
10 Bin Sorter Error Messages
Message Cause and Solution
A3-Ov is not available with
Sorter. Select top tray.The paper size selection you made for the job, for
example, 12 x 18 inches, is not valid. Redirect the
job to the printer Top Tray or change the output
paper size so the job may be sent to the 10 Bin
Sorter.
Check printer panel and remove
papersFollow jam clearance procedures for the 10 Bin
Sorter and the DP-C106. For complete jam
clearance...

Problem Solving 10 Bin Sorter Error Messages
110
Invalid for Stack The selections (such as paper size) you made for the
job are not valid for stacking. Redirect the job to the
Top Tray or change the selections so the job may be
sent for stacking.
Remove papers from High Cap 500 sheets are in the high capacity bin. Remove the
sheets from the high capacity bin and continue
copying.
Remove papers from Sorter The capacity of the Exit Tray (bin 1) or other bins has
been reached. Remove the sheets from the...

Network Problem Solving Problem Solving
111
Network Problem Solving
Because the DP-C106 server is part of the Printer, most references in this
chapter are simply to the Printer. The word server is used to refer to network
servers.
Problems During Setup from the Control Panel
If you have difficulty printing the test page and no message is displayed,
perform the following steps:
1.  Check the Printer status.
2.  Use the table below to attempt to resolve the problem.
3.  Try printing again.
Symptom Possible...

Problem Solving Network Problem Solving
112
Network Protocol Setup Messages
The following table lists the network protocol messages that you may see
during the Network Protocol setup.  It also contains the last Setup screen
shown before the message appeared, a description of the problem, and any
action required.
Message Setup Screen Description and Action
NO APPLETALK
ZONE FOUND.ENABLE APPLETALK
(NETWORK
PROTOCOL SETUP>
APPLETALK SETUP)•  The Ethernet network cable
is not attached to the
connector on the...

Network Problem Solving Problem Solving
113
Message Setup Screen Description and Action
NO NDS TREES
FOUND.ENABLE NDS
(NETWORK SETUP>
SERVICE SETUP>
PSERVER SETUP>
NDS SETUP)No NDS trees were found on
the Novell network. Ensure that
the Frame Types on the Printer
are properly configured.
WARNING!
SELECTING A NEW
NDS TREE
DELETES BINDERY
SETUP.SELECT NDS TREE
(NETWORK SETUP>
SERVICE SETUP>
PSERVER SETUP>
NDS SETUP)You have previously connected
the DP-C106 to a different NDS
tree. NetWise supports only a...

Problem Solving Network Problem Solving
114
Message Setup Screen Description and Action
ERROR. CANNOT
OPEN BINDERY
CONNECTION TO
NDS SERVER.SELECT FILE
SERVER FROM LIST
(NETWORK SETUP>
SERVICE SETUP>
PSERVER SETUP>
BINDERY SETUP)Select this server through NDS
Setup or disable NDS and
select it through Bindery.
NO NETWARE FILE
SERVER FOUND.SELECT FILE
SERVER FROM LIST
(NETWORK SETUP>
SERVICE SETUP>
PSERVER SETUP>
BINDERY SETUP)No file server was found when
the DP-C106 queried the
Network to create a list...

Network Problem Solving Problem Solving
115
Message Setup Screen Description and Action
NOVELL ERROR
CODE, FOLLOWED
BY A MESSAGE.ANY BINDERY SETUP
SCREENNovell NetWare has reported
an error. The Printer Control
Panel reports the error number
and displays a brief message.
For the most common errors, a
screen is displayed, enabling
you to retry the action that
caused the error. If the action
cannot be completed, you are
prompted to notify the Novell
administrator to troubleshoot
the error on the network....

Problem Solving Network Problem Solving
116
Novell Problems During Network Setup
In Network Setup, when you are configuring your IPX (Novell) connection, the
DP-C106 queries the network for Novell file servers and trees and temporarily
attaches to them. If a guest login is enabled, it will be used. If not, you will be
prompted to login from the DP-C106 Printer Control Panel.
If the selected NetWare file server or tree does not have a guest account, or if
the guest account has expired or has been disabled...

Network Problem Solving Problem Solving
117
Novell Error Messages
Message Cause Suggested Action or Exit
220
Guest account not
available.The guest account,
which you have
selected for initial login,
has expired or has
been disabled by the
NetWare supervisor.•  Enable a guest account on
the NetWare server for the
purpose of setup.
•  Login to a different account.
On the login screen, change
the default name (guest) to
supervisor or enter another
valid login name. When you
are prompted for a password,...

Problem Solving Network Problem Solving
118
Message Cause Suggested Action or Exit
Notify IPX (Novell)
AdministratorDP-C106 is already
connected to a file
server. Something
unexpected has
happened and the user
generally cannot
recover without the
intervention of the
system administrator.
Error #197 indicates
that you have
exceeded the number
of login attempts
permitted for this
account on the
NetWare file server.
Error #255 usually
indicates a hard failure.The error screen exits to the
PServer Setup...
