Panasonic Digital Color Imaging System DP-C106 Operating Instructions

Operating Instructions Table of contents
xi
Transporting the Scanner....................................................................................... 68
5.  Problem Solving ..................................................................................................... 69
Avoiding Paper Jams ................................................................................................. 69
Printer Jam Clearance...

Table of contents Operating Instructions
xii
Printing Problems .................................................................................................... 122
On a Windows Workstation .................................................................................. 122
On a Mac OS Workstation ................................................................................... 123
General Printing Problems ................................................................................... 124...

1
Getting to Know the DP-C106
Printer, Front View
1. Paper Tray 1 – place paper supply here
2. Duplex Unit/Kit – option that allows two-sided printing
3. Front Cover – open to access the Toner Cartridges and the Print/Copy
Cartridge
4. Control Panel – use to access the Printer menus and to view messages
5. Printer Output Top Tray – the prints are delivered here
6. Paper Stop – use to stop oversized prints from being pushed out of the
Output Tray.  The Paper Stop is adjustable up to 17 x 11 inch (B4)...

Getting to Know the DP-C106 Printer, Rear View
2
Printer, Rear View
11. Scanner Power Connector –provides power to the Scanner
12. Scanner Interface Connector – provides interface to the Scanner
13. Area 4 Access Cover – open to access paper jams
14. Printer Side Output Tray – copies are delivered to this tray
15. Printer Power Switch – use to switch the Printer power Off and On
16. Printer Power Cable Connector – connect the Printer Power Cable
here
12
11
13
15
16
14

Printer, Internal View Getting to Know the DP-C106
3
Printer, Internal View
17. Toner Carousel Access – the four Toner Cartridges are installed one at
a time, through this opening
18. Fuser Jam Clearance Area – the Fuser applies heat to the Toner in
order to adhere it to the paper
19. Anti-rotation Lever – use to release the Toner Carousel in order to
remove and replace the Toner Cartridges
20. Lever B – used to lock the Print/Copy cartridge in position
21. Print/Copy Cartridge – use to transfer...

Getting to Know the DP-C106 Printer Control Panel
4
C/
1010
01010010
Printer Control Panel
1. Control Panel Screen – use to view the system status, menu options,
problem messages, and fault codes
2. (              ) ARROW buttons – use to view listed options in a menu
3. MENU button – use to step through the Printer menus
4. OFFLINE button– use this button to change the system status from on-
line to off-line and back again
5. CLEAR/STOP button – use this button to Clear an entry, Stop a
procedure or...

Scanner and Automatic Document Feeder (ADF) Components Getting to Know the DP-C106
5
Scanner and Automatic Document Feeder (ADF) Components
The ADF comes mounted to the Scanner. Its components are illustrated and
described by numbers 3 through 6.
1. Scanner Control Panel – use to access the DP-C106 features and
options
2. Memory Expansion Slot – provided for the 1 to 2 Side Copy option
3. Document Input Tray – place the originals to be scanned here
4. Original Exit Tray – scanned originals are delivered...

Getting to Know the DP-C106 Scanner and Automatic Document Feeder (ADF) Components
6
7. Registration Guide– align the original with the Registration Guide
8. Document Glass – supports the original for scanning
7
8

Scanner Control Panel Getting to Know the DP-C106
7
Scanner Control Panel
1. Control Panel Screen – use to view the system status, menu options,
problem messages, and fault codes
2. Copy button – use to change the system from the on-line mode to
copying mode
3. Tools button – provides access to the administration features
4. Clear All button – use to clear the selected option and reset the system
to the defaults
5. Stop button – use to stop the copying process
6. Start button – use to start the copying...

Getting to Know the DP-C106 Scanner Control Panel
8
15. Zoom (        ) ARROW buttons – use to select Reduce/Enlarge from 25-
400%
16. Reduce/Enlarge (        ) ARROW buttons – use to select one of the
preset reduction or enlargement settings
17. Reduce/Enlarge indicators – indicates which setting is currently
selected
18. Paper Supply indicators – indicates which paper tray is currently
selected
19. Color Mode button – use to access color mode options
20. Lighten/Darken button – use to lighten or darken...
