Panasonic Digital Color Imaging System DP-C106 Operating Instructions

Copy Features
39
Advanced Features
The Advanced Features option includes the following:
• Output – to change the tray that your copies output to. The option can
be set to either the Exit Tray, the left-hand side Output Tray, or the Top
Tray, the tray above the printer where print jobs are output.
•  If the 10 Bin Sorter option is attached, there are other output selections
available. Refer to Determining Output with the Optional 10 Bin Sorter
for additional information.
• Erase – to set an erase value...

Copy Features
40
Using the Output Feature
Use the following procedure to make a copy using the Output feature:
1.  If the DP-C106 is in printer mode, press the Copy button to enter copy
mode.
2. Press the Clear All button to restore default settings.
3.  Position the original on the Document Glass or in the ADF.
For more information on position originals on the Document Glass and Using
the ADF, go to the Basic Copying.
4. Press the Advanced Features button. Advanced Features selection is
displayed on the...

Copy Features
41
Determining Output with the  Optional 10 Bin Sorter
The 10 Bin Sorter functions are available to copy jobs only.
1. Select the Copy button on the copier control panel to enter Copy Mode.
2. Select the Advanced Features button.
3. Select the Output feature.
4.  Select one of the following options:
12 x 18 Oversize paper cannot be sent to the 10 Bin Sorter.
• Exit Tray (default): Up to 100 output pages can be delivered to the
top output bin without sorting.
Example: Three copies of a...

Copy Features
42
Using the Erase Feature
Use the following procedure to make a copy using the Output feature:
1.  If the DP-C106 is in printer mode, press the Copy button to enter copy
mode.
2. Press the Clear All button to restore default settings.
3.  Position the original on the Document Glass or in the ADF.
For more information on positioning originals on the Document Glass and
Using the ADF, go to the Basic Copying.
4. Press the Advanced Features button. Advanced Features selection is
displayed on...

Copy Features
43
9. Press the Select button. Advanced Features selection is displayed on
the Copier Screen.
10. Press the Exit button. The Main Screen is displayed on the Copier
Screen.
11.  Enter your desired number of copies using the Numeric Keypad.
12. Press the Start button.
If you enter two values and wish to change the first, you must first exit and
then return before making the desired change.
Using the 2-Sided Feature
Use the following procedure to make a copy using the 2-Sided feature:
1.  If...

Copy Features
44
7. Use the (        ) ARROW  buttons to highlight one of the following:
•  OFF to turn the 2-Sided feature off.
•  Long Edge Binding to flip the images along the long edge of the
output. This feature prints the top of the long edge side 1 image on
the same edge of the page as the top of the side 2 image. For
Portrait documents, this creates a book effect. For Landscape
documents, this creates a landscape effect.
•  Short Edge Binding to flip the images along the short edge of the
output....

Copy Features
45
Using the 2 Up Feature
Use the following procedure to make a copy using the 2 Up feature:
1.  If the DP-C106 is in printer mode, press the Copy button to enter copy
mode.
2. Press the Clear All button to restore default settings.
3.  Position the originals in the ADF with the long edge of the paper entering
the ADF first (Long Edge Feed).
You must use the ADF  to create a 2 Up copy. For more information on
positioning originals in the ADF, go to the Basic Copying chapter.
4.  Select the...

Copy Features
46
9. Use the (        ) ARROW  buttons to select one of the following:
•  NO to turn the 2 Up feature Off.
• YES (L→R) to turn the 2 Up feature On, and position the images
from left to right.
• YES (R→L) to turn the 2 Up feature On, and position the images
from right to left.
The Copier Screen displays an error message if the 2-Sided feature is On
when you try to switch On the 2 Up feature. For information on using the 2-
Sided feature, go to the “Using the 2-Sided Feature”.
10.  Press the...

47
Tools Mode
Use the Tools button on the Copier Control Panel to access Tools Mode on
your DP-C106. The Tools Mode feature provides access to meter information
and the administrative features that allow you to customize and service your
copier.
For the Administration features, the default administrator password is 9999.
Change the password as soon as possible to prevent unauthorized
personnel from accessing the Administrator Menu and its options.
Meter Check
The Meter Check feature provides a...

Tools Mode
48
Use the following procedure to access the Meter Check screen:
1. Press the Tools button on the Copier Control Panel to display the Tools
Main Menu on the Copier Screen.
2.  Using the  (        ) ARROW buttons highlight the Meter Check feature.
3. Press the Select button. Meter Check is displayed on the Copier Screen.
4.  To exit the Meter Check feature, press the Exit button. The Tools Main
Menu is displayed on the Copier Screen.
5. Press the Tools button in order to exit Tools Mode....
