Panasonic Digital Color Imaging System DP-C106 Operating Instructions

Tools Mode
49
Use the following procedure to access the Administrative Features menu:
1. Press the Tools button on the Copier Control Panel to display the Tools
Main Menu on the Copier Screen.
2.  Using the (       ) ARROW buttons highlight the Admin menu selection.
3. Press the Select button. Password Input is displayed on the Copier
Screen.
The default system administrator password is 9999. Change the password
as soon as possible to prevent unauthorized personnel from accessing the
Administrator Menu...

Tools Mode
50
Defaults for Copy
The DP-C106 automatically restores default feature settings.
•  When the power is switched On.
•  When restoring power from Energy Saver Mode.
• When the Clear All button is pressed.
To change the default settings for the following features, select the Defaults
for Copy option from the Administrator menu in Tools Mode:
• Paper: This option allows you to change the default setting for the Paper
Supply feature.
The Paper Supply default can be set at Auto, Tray 1, Tray 2 or...

Tools Mode
51
• Color Mode: This option allows you to change the default setting for the
Original Type feature.
The Original Type default can be programmed to one of the following:
• Black Text
• Black Text/Photo
• Black Photograph
• Color Text/Photo
•  Color Prnt Photo
• Color Photograph
• Auto
Setting a default value for the Color Mode feature is useful when most
originals are of the same type.
• Output: This option allows you to change the default Output location for
copies.
The Output destination...

Tools Mode
52
Use the following procedure to change a Defaults for Copy setting:
1. Press the Tools button on the Copier Control Panel to display the Tools
Main Menu on the Copier Screen.
2.  Using the (        ) ARROW buttons highlight the Admin menu option.
3. Press the Select button. Password Input is displayed on the Copier
Screen.
4.  Using the Numeric Keypad, enter your Administrator Password. The
numbers display as asterisks (*).
If you make a mistake while entering the password, press the Clear...

Tools Mode
53
Color
The color balance setting changes the toner density for the colors yellow,
magenta, cyan and black. Each color is set for a high, medium and low
density. Each color has a density setting for three document types:
Text/Photo, Print Photo, and Photograph.
The color balance adjustment is for copies only. When the machine is in the
printer mode, color adjustments do not affect the output.
Use the following procedure to adjust the Color settings:
1. Press the Tools button to display the...

Tools Mode
54
9. Press the Select button. Color selection is displayed on the Copier
Screen.
10.  Using the (        ) ARROW buttons, highlight one of the following: Y for
Yellow, M for Magenta, C for Cyan and B for Black. Press the Select
button.
11.  Using the (        ) ARROW buttons, adjust the color density between –3
and +3 for each of the three density levels, Low, Middle and High.
Use the Up and Down arrows to increase or decrease the density level. Use
the Left and Right arrows to switch between...

Tools Mode
55
Auto Color Adjust
The Automatic Color Adjust option allows you to correct any color degradation
that occurs from use to maintain the optimum copy quality for the
Copier/Printer.
The color adjustment is for copying only. When the DP-C106 is in the printer
mode, the adjustments have no effect.
Use of High Brightness Paper (90 Brightness or higher) is strongly
recommended when making color adjustments.
Use the following procedure to apply the Auto Color Adjust feature:
1. Press the Tools...

Tools Mode
56
10.  Confirm that the Printout document option is highlighted. Press the
Select button.
11.  Load 8.5 in. x 11 in. or A4 paper in the Bypass Tray and press the Start
button. Load by long edge first.
For directions on loading paper in the Bypass Tray, go to the Copy Features.
12.  The Auto Color Adjustment Patch Page prints out to the Top Tray.
13.  Place the Auto Color Adjustment Patch Page face down on the
Document Glass. Position the magenta patches on the left-hand side of
the glass.
14....

Tools Mode
57
Detect Document Size
The DP-C106 can automatically detect the size of an original if it is a certain
size. The copier measures original document sizes in millimeters or in
inches.
For a complete list of all paper sizes the DP-C106 can automatically detect,
go to the Basic Copying.
Use the following procedure to set the default unit of size:
1. Press the Tools button to display the Tools Main Menu on the Copier
Screen.
2.  Using the (        ) ARROW buttons highlight the Admin menu option....

Tools Mode
58
Auto Mode Change
The DP-C106 can enter copy mode when originals are loaded into the ADF or
the ADF is opened if the Auto mode change feature is set to Copy. You do
not need to press the Copy button to enter Copy Mode.
For further information on using the Copy button to enter copy mode, go to
the Basic Copying.
Use the following procedure to access the Auto Mode Change option:
1. Press the Tools button to display the Tools Main Menu on the Copier
Screen.
2.  Using the (        ) ARROW...
