5.  Return the Document Tray to the original position.
6.  If you are loading large size originals into the ADF, pull out the Exit Tray
Extension of the Document Exit Tray.
CAUTION
Pay attention to the following cautions when using the ADF:
•  Do not press on the originals while using the ADF; this could cause a
paper jam.
•  Do not let more than 30 sheets stack on the Document Exit Tray.  Do not
place any objects on the Document Exit Tray.  Both actions could cause
a paper jam.
The ADF...

Basic Copying
20
Making a Copy
Perform the following steps to make a copy on the DP-C106:
1.  If the Copier/Printer is in printer mode, press the Copy button.
2. Press the Clear All button to reset all default settings.
The settings for all of the copy features are not displayed on the Main
Screen.  Feature settings may be altered from a previous copy job.  Press
the Clear All button to ensure that all copy features are on the default
settings.
3.  Position the originals on the Document Glass or in the...

21
Copy Features
The following copy features are available on the DP-C106 Copier/Printer:
• Reduce/Enlarge Options
• Paper Supply Selection
•  Original Type Selection
• Lighten/Darken Adjustment
• Quality Adjustment
• Advanced Features
This chapter provides detailed information about using each of these features.
Reduce/Enlarge
The Reduce/Enlarge button allows you to increase or decrease the size of the
original image onto your copy output. Selecting a Reduce/Enlarge percentage
on the Copier Control...

Copy Features
22
•  Preset % - The Preset % settings are shown on the Copier Control
Panel. The Copier/Printer automatically determines output size based on
the selected reduction or enlargement percentage.
The following tables list the Preset % selections available on the DP-
C106 and how each percentage affects certain paper sizes.
•  Manual % selections - The Zoom (       ) ARROW buttons allow you to
set a manual zoom percentage between 25% and 400%. The manual
zoom percentage displays on the Copier...

Copy Features
23
4.  Perform one of the following:
• Use the Reduce/Enlarge (        ) ARROW buttons to select 100 %
to produce a copy that is the same size as the original document.
• Use the Reduce/Enlarge (        ) ARROW buttons to select Auto%.
• Use the Reduce/Enlarge (        ) ARROW buttons to select a
Preset % reduction/enlargement setting.
• Use the Zoom (        ) ARROW buttons to select a Manual %
reduction or enlargement percentage.
You can enter any percent between 25 % and 400 %.
5.  If...

Copy Features
24
Paper Supply
The Paper Supply feature allows you to select the desired paper for your
copies.
The following Paper Supply selections are available on the DP-C106:
• Auto – The Copier/Printer automatically determines original size and the
appropriate paper supply. The Copier/Printer then pulls the appropriate
copy stock from Paper Tray 1, 2, or 3.
• Paper Trays 1, 2, and 3 – This Paper Supply option allows you to
manually select a Paper Tray loaded with the desired output size.
Selecting...

Copy Features
25
4. Use the Paper Supply ARROW buttons to select one of the following:
• Auto
You cannot use the Auto Paper Supply feature with the Auto %
Reduce/Enlarge option. You must select a specific reduce/enlarge
percentage. Information on the Reduce/Enlarge feature is provided at the
beginning of this chapter.
• Tray 1
• Tray 2
• Tray 3
If paper is not loaded in the Paper Tray, the message “ADD PAPER TO
TRAY X” is displayed on the Copier Screen, where “X” is the selected tray.
For information on...

Copy Features
26
2.  Perform one of the following:
•  If loading A3 oversize paper, ensure that the blue-green, left-hand
Paper Guide is lowered and snapped into place.
•   If loading any other size paper, lift the blue-green, left-hand Paper
Guide.
3.  Slide the right-hand Paper Guide all the way to the right.
4.  If you are printing on longer paper, pull out the Tray Extension.
0302502A -WOL
030203O

Copy Features
27
5.  Insert your paper stock into the Bypass Tray. Place the left-hand edge of
the paper stock against the left-hand paper guide.
Follow these guidelines to help minimize paper jams in the Bypass Tray:
• Do not use paper that is folded, creased or curled.
• Do not load more sheets than can fit easily under the Paper
Guide Tab.
• Whenever possible, load paper for long edge feed.
6.  Slide the right-hand Paper Guide to fit against your paper stock.
Pushing the Paper Guide to tightly against...

Copy Features
28
Loading Transparencies into the Bypass Tray
Transparencies can be fed only from the Bypass Tray or optional
Transparency Tray that goes into Tray 1 position.
CAUTION
Do not use White-Framed Transparencies in this unit.  To prevent the white
tape(s) from jamming inside the Fuser Unit, this machine is designed with a
White-Frame Detection Sensor.  Upon detecting the White-Frame of the
Transparency, the unit stops feeding, causes a Jam Indication and the
Printer Screen displays: “WRONG OHP...
