Panasonic Digital Color Imaging System DP-C106 Operating Instructions

Options and Supplies Getting to Know the DP-C106
9
Options and Supplies
The DP-C106 is a digital Color Copier/Printer which can produce images with
great color and clarity.  Furthermore, its copying/printing functionality can also
be greatly enhanced by the addition of the following options and supplies.
We hope you find that the wide ranging capabilities will make your office-
place more productive and efficient.
Options
Part Name Part No. Description
10 Bin Sorter DA-S27C The 10 Bin Sorter can sort or...

Getting to Know the DP-C106 Options and Supplies
10
Supplies
Part Name Part No.
1 Black Toner Cartridge DQ-UR26K
1 Cyan Toner Cartridge DQ-UR26C
1 Magenta Toner Cartridge DQ-UR26M
1 Yellow Toner Cartridge DQ-UR26Y
1 Print/Copy Cartridge DQ-UH26X
1 Toner Waste Container DQ-BF28X

11
Basic Copying
This chapter contains the elements and basic function descriptions of the DP-
C106 Copier Control Panel.  Also included are guidelines for placing the DP-
C106 in copier mode, positioning the originals on the Document Glass and in
the ADF, and a procedure for making a basic copy using the Copier/Printer
default settings.
The Copier Control Panel
Use the Copier Control Panel to program the DP-C106 for your copy jobs.
The following is a list of the various components on the Copier Control...

Basic Copying
12
7. Numeric Keypad
•  Use buttons 0-9 to select the copy quantity, enter personal
passwords, and specify particular feature settings.
•  Use the Clear button to reset copy quantity back to 1 or to clear an
incorrect numeric setting.
8. Exit – use to return to the previous screen.
9. Select – use to save copy settings other than the default settings.
10. (               ) ARROW buttons – use to highlight a specific setting on the
Copier Screen for a feature.
11.  Advanced Features – use to...

Basic Copying
13
Copy Mode
The default setting for the DP-C106 is the printer mode.  To make a copy you
must change the Copier/Printer to the copier mode.
When the DP-C106 Copier/Printer is in the printer mode, a message displays
in the Copier Screen that says
To Enter Copy Mode Press Copy Button
This message is referring to the Copy button on the Copier Control Panel.
After you press the Copy button, one of the following occurs:
• The Ready to Copy message appears on the Copier Control Panel
indicating...

Basic Copying
14
Auto Start
While the Please Wait message appears on the Copier Screen, you cannot
start copy operations.  You may, however, program your copy job.  Once the
Copier/Printer has successfully entered copy mode, your copy job will
automatically begin to print.
While the Please Wait message is displayed, position your originals, select
the desired options and press the Start button.  The Copier/Printer continues
to show the Please Wait message until it enters the copy mode.
Once the DP-C106...

Basic Copying
15
Positioning the Originals
There are two ways to position originals on the DP-C106: on the Document
Glass or in the ADF.
The Document Glass
Perform the following steps to use the Document Glass:
1.  Raise the ADF.
2.  Align the original into the rear, left-hand corner of the Document Glass
face down.  Place your original in the same orientation that the paper is
loaded in your selected Paper Tray.
For transparency sheets, tracing paper or other types of thin paper, place a
blank, white...

Basic Copying
16
The DP-C106 detects original sizes in either inches or millimeters. The table
below lists the various paper sizes that the DP-C106 can automatically detect
when configured to inches and to millimeters.
For information on changing the copier configuration between inches and
millimeters, go to the Tools Mode.
LEF = Long Edge Feed;  SEF = Short Edge Feed
Inch ConfigurationMetric Configuration
8.5 x 11 in. (SEF/LEF) B5 (SEF/LEF)
8.5 x 14 in (SEF) A4 (SEF/LEF)
11 x 17 in. (SEF) B4 (LEF)
A3...

Basic Copying
17
The Automatic Document Feeder (ADF)
The ADF allows you to load up to 30 originals into the DP-C106 for continuous
scanning.  Each original is scanned individually, beginning with the bottom sheet.
To use the ADF perform the following steps:
1.  Raise the document handler to the right.
2.  Place the originals into the ADF face up and in the same orientation as
the paper in the Paper Tray.

Basic Copying
18
3.  Gently push the originals into the ADF, as shown below, until the ADF
Light illuminates.
To prevent paper jams, ensure that the original documents rest against the
rear edge of the ADF. Make sure that the ADF Light illuminates.

4.  Adjust the Document Guide to gently touch the edges of the originals, as
shown below.
Pushing the Document Guide too tightly against the originals may cause a
ADF jam.

0302512A -WOL
ADF Light
