Panasonic Digital Color Imaging System DP-C106 Operating Instructions

Copy Features
29
Loading Postcards into the Bypass Tray
Postcards must be fed through the Bypass Tray.
When printing on the back of pre-printed postcards, make sure that the
postcard is not bent. To avoid paper jams, flatten every bend by hand before
printing.
Use the following procedure to load postcards into the Bypass Tray:
1.  Load a postcard into the Bypass Tray with the copy side face up.
2.  Adjust the Paper Guides to fit snuggly against the postcard stack.
Use the Reduce/Enlarge feature to copy...

Copy Features
30
Loading Envelopes in the Bypass Tray
All envelopes must be fed through the Bypass Tray. Open the flap and insert
the envelope, one at a time, into the Bypass Tray as shown below.
Follow these guidelines when printing onto envelopes to help minimize
potential jams and other problems:
• Do not use envelopes that have tape seals. If you are using
an envelope with a glue seal, make sure it is dry before use.
• Only use landscape (horizontal) type envelopes (more than
3.5 inches wide, and...

Copy Features
31
Making a Copy Using the Bypass Tray
Use the following procedure to make a copy using the Bypass Tray:
1.  If the DP-C106 is in printer mode, press the Copy button to enter copy
mode.
2. Press the Clear All button to restore default settings.
3.  Position the originals on the Document Glass or in the ADF.
For more information on positioning originals on the Document Glass or
using the ADF, go to the Basic Copying.
4. Use the Paper Supply buttons to select the Bypass Tray. The Bypass
Tray...

Copy Features
32
CAUTION
Feeding paper into the Bypass Tray that has been printed on one side from
another copier can damage the DP-C106 because of the differences in toner
temperature and chemical specifications. It is recommended that you create
manual, 2-Sided copies using paper printed on by the DP-C106 only.
6. Press the Select button. Paper Size selection is displayed on the Copier
Screen.
7.  Use the  (        ) ARROW  buttons to highlight the paper size loaded in
the Bypass Tray.
8. Press the...

Copy Features
33
• Color - The Copier/Printer will use all Toner Cartridges for full color copy
output. The following Original Type selections are available in Full color
mode:
• Text/Photo – Use this setting when the original consists of color text
and photographs or color text and a photo from a magazine or
newspaper.
• Printed Photo – Use this setting when the original is a photograph
from a magazine or a newspaper.
• Photograph – Use this setting when the original document is an
original photograph...

Copy Features
34
Using the Color Mode Feature
Follow these steps to make a copy using the Color Mode feature:
1.  If the DP-C106 is in printer mode, press the Copy button to enter copy
mode.
2. Press the Clear All button to restore default settings.
3.  Position the original on the Document Glass or in the ADF.
For more information on positioning originals on the Document Glass and
using the ADF, go to the Basic Copying.
4. Press the Color Mode button. Color Mode selection is displayed on the
Copier...

Copy Features
35
Lighten/Darken
The Lighten/Darken feature enables you to adjust the overall density of the
copy output. This feature offers an Auto Contrast option as well as five
lighten/darken levels.
When the Auto option is selected, the Copier/Printer automatically determines
the density of the original. The Copier/Printer then adjusts the density levels
of the copy output to optimize image quality.
Using the Lighten/Darken Feature
Follow these steps to make a copy using the Lighten/Darken feature:...

Copy Features
36
Quality Adjustment
The Quality Adjustment feature allows you to adjust the following features:
• Sharpness – to adjust the line sharpness of your copy output.
For detail use a darker line sharpness. For softness use a lighter line
sharpness.
• Color Level – to adjust the amount of color in the copy output.
• Background Mask – to keep undesired images printed on the back of an
original from appearing on the copy output.
The Background Suppression option is useful for copying newspaper...

Copy Features
37
8. Press the Select button. Quality Adjustment selection is displayed on
the Copier Screen.
9. Press the Exit button. The Main Screen is displayed on the Copier
Screen.
10.  Enter your desired number of copies using the Numeric Keypad.
11. Press the Start button.
Using the Color Level Adjustment
Follow these steps to make a copy using the Color Level adjustment:
1.  If the DP-C106 is in printer mode, press the Copy button to enter copy
mode.
2. Press the Clear All button to restore...

Copy Features
38
Using the Background Mask Feature
Follow these steps to make a copy using the Background Mask feature:
1.  If the DP-C106 is in printer mode, press the Copy button to enter copy
mode.
2. Press the Clear All button to restore default settings.
3.  Position the original on the Document Glass or in the ADF.
For more information on positioning originals on the Document Glass and
Using the ADF, go to the Basic Copying.
4. Press the Quality Adjustment button. Quality Adjustment selection is...
