Panasonic Dmc Fz50 Operating Instructions Manual

Others
121 VQT0X92
Others
Cautions for Use
wOptimal use of the camera
Take care not to drop or knock the unit
or put a lot of pressure on it.
• Take care not to drop or knock the bag
that you inserted the unit in as it may
strongly shock the unit.
• A strong shock may break the lens,
screen or outer case and cause the
camera to malfunction.
Keep the camera as far away as possible
from electromagnetic equipment (such
as microwave ovens, TVs, video games
etc.).
• If you use the camera on top of or...

Others
122VQT0X92
wCard
Do not leave the card where the
temperature is high, where
electromagnetic waves or static
electricity are easily generated or
exposed to direct sunlight.
Do not bend or drop the card.
• The card may be damaged or the recorded
content may be damaged or deleted.
• Put the card in the card case or the
storage bag after use and when storing or
carrying the card.
• Do not allow dirt, dust or water to get into
the terminals on the back of the card and
do not touch the...

Others
123 VQT0X92
[NO VALID PICTURE TO PLAY]
Record a picture or insert a card with a
recorded picture and then play it.
[THIS PICTURE IS PROTECTED]
Delete or overwrite the picture after
canceling the protect setting. (P107)
[THIS PICTURE CANNOT BE DELETED]/
[SOME PICTURES CANNOT BE
DELETED]
Pictures not based on the DCF standard
cannot be deleted. If you want to delete
some pictures, format the card after saving
necessary data on a PC etc. (P111)
[NO ADDITIONAL DELETE SELECTIONS
CAN BE MADE]
You...

Others
124VQT0X92
Troubleshooting
If you return the menu settings to the initial
settings at the time of purchase, the
condition may improve.
Select [RESET] in the [SETUP] menu.
(P30)
wBattery and power source
1: The camera cannot be operated even
when it is turned on.
• Is the battery inserted correctly?
• Is the battery sufficiently charged?
– Use a battery that has been
sufficiently charged.
2: The LCD monitor turns off while the
camera is turned on.
• Does the picture appear on the...

Others
125 VQT0X92
taking pictures indoors etc. the ISO
sensitivity increases.)
– Decrease the ISO sensitivity. (P85)
– Set [NOISE REDUCTION] in
[PICT.ADJ.] to [HIGH] or set every
item except [NOISE REDUCTION] to
[LOW]. (P94)
– Take pictures in bright places.
• In [HIGH SENS.] (P70) in scene mode,
the resolution of the recorded picture
decreases slightly because of high
sensitivity processing.
This is not a malfunction.
8: Motion picture recording stops in the
middle.
• Are you using a...

Others
126VQT0X92
2: The flash is activated 2 times.
• When you select red-eye reduction
(P47), the flash is activated once before
the actual recording to reduce the
red-eye phenomenon (eyes of the
subject appearing red in the picture)
and then activated again for the actual
recording.
wPlayback
1: The picture being played back is
rotated and displayed in an
unexpected direction.
The camera has a function that
automatically rotates the display of
pictures recorded holding the camera...

Others
127 VQT0X92
4: The picture cannot be transferred
when the camera is connected to a
PC.
• Is the camera connected to the PC
correctly?
• Is the camera recognized by the PC
correctly?
• Set [USB MODE] to [PC]. (P30, 112)
5: The card is not recognized by the PC.
• Disconnect the USB connection cable.
Connect it again while the card is
inserted in the camera.
6: The picture cannot be printed when
the camera is connected to a printer.
• Does the printer support PictBridge?
– You cannot print...

Others
128VQT0X92
8: The clock is reset.
• If you do not use the camera for a long
time, the clock may be reset. When the
message [PLEASE SET THE CLOCK]
appears, set the clock again. (P26)
• When you take a picture before setting
the clock, [0:00 0. 0. 0] is recorded.
9: Colors appear on the picture which
were not found in the actual scene.
• Depending on the zoom magnification,
the picture may have some colored
fringes around the subject. This is
called chromatic aberration and may be
more...

Others
129 VQT0X92
Others
Number of recordable pictures and available
recording time
• The number of recordable pictures and the available recording time are an
approximation. (These vary depending on the recording conditions and the type of card.)
• The number of recordable pictures varies depending on the subjects.
wNumber of recordable pictures
Aspect ratio
Picture size (10M):
(3648M2736 pixels) (8M EZ):(3264M2448 pixels)
Quality
Card
16MB02526
32 MB 1 5 11 6 14
64MB2 11241430
128 MB 5 24 49 30 61...

Others
130VQT0X92
Aspect ratio
Picture size (8.5M):
(3600M2400 pixels) (7M EZ):(3248M2160 pixels) (4.5M EZ):(2560M1712 pixels)(2.5M EZ):(2048M1360 pixels)
Quality
Card
16MB02537512918
32MB1 6 13 7 1613262040
64MB3 1327173427544383
128 MB 6 28 57 35 70 56 110 88 165
256 MB 12 56 110 69 135 110 210 170 330
512 MB 23 110 220 135 270 210 430 340 650
1 GB 48 220 440 270 540 440 860 680 1310
2 GB 97 450 900 560 1090 890 1700 1360 2560
4 GB 190 900 1770 1100 2150 1740 3350 2680 5020
Aspect ratio
Picture size...
