Panasonic Dmc Fz50 Operating Instructions Manual

Menu Settings
91 VQT0X92
• The camera is focusing on all the AF
areas when multiple AF areas (max.
9 areas) light at the same time.
The focus position is not predetermined. It
is set to a position automatically
determined by the camera at the time of
focusing. If you want to determine the
focus position to take pictures, switch the
AF mode to [ ], [ ] or [ ].
• Switch the AF mode to [ ] or [ ]
mode if it is difficult to focus using [ ].
Press [ ] to display the [REC] mode
menu and select the...

Menu Settings
92VQT0X92
animals in dark places), set the
[AF ASSIST LAMP] to [OFF]. In this case,
it will become more difficult to focus on the
subject.
• In auto mode [ ], the [AF ASSIST
LAMP] setting is fixed to [ON].
• A vignetting effect may appear on the
circumference of the AF assist lamp
because the AF assist lamp may be
obscured by the lens, however, this does
not cause a problem with the performance
of the camera.
• The setting for the [AF ASSIST LAMP] is
fixed to [OFF] in [SCENERY]...

Menu Settings
93 VQT0X92
• If you rotate the focus ring while the focus
is locked, the focus lock indication [ ]
blinks red.
• The exposure is set, even if the brightness
of the subject changes.
• The subject can be focused again by
pressing the shutter button halfway even
when AE is locked.
• Press the [FOCUS/AE LOCK] button once
more to cancel the AE lock.
• Program shift can be set even when AE is
locked.
• You can fix the focus and the exposure by
pressing the [FOCUS/AE LOCK] button. You
do...

Menu Settings
94VQT0X92
• When a memorized custom mode setting
is selected, this memorized setting has
priority. (However, this is not the case
when Manual exposure is set in custom
set.)
• You cannot directly compensate the
exposure in the following cases.
-When manually setting the exposure.
-When in auto mode [ ].
Press [ ] to display the [REC] mode
menu and select the item to set. (P82)
Select a color effect that matches the
recording conditions and your image of the
recording.
Press [ ] to...

Menu Settings
95 VQT0X92
Press [ ] to display the [REC] mode
menu and select the item to set. (P82)
This camera allows you to create motion
picture files up to 20 seconds long by
connecting images recorded in flip
animation mode.
Example:
When capturing images of the subject in
sequence moving the camera little by little
and aligning the images, the subject looks
as if it is moving.
• You can play back created flip animations
with the same method used to play back
motion pictures. (P81)
1Press...

Menu Settings
96VQT0X92
4Press [MENU/SET], press  to
select [CREATE MOTION
PICTURE] and then press
.
5Select [FRAME RATE] and then
press
.
6Press  to select [5fps] or
[10fps] and then press
[MENU/SET].
7Press  to select [CREATE
MOTION PICTURE], press
 and
then create a flip animation.
• The file number appears after creating
a flip animation.
• Press [MENU/SET] three times to close
the menu after creating the flip
animation.
wDeleting all still images used to create
flip...

Menu Settings
97 VQT0X92
Press [ ] to display the [REC] mode
menu and select the item to set. (P82)
The tele conversion lens (DMW-LT55;
optional) allows you to record even more
close-up pictures (1.7M). The wide
conversion lens (DMW-LW55; optional)
allows you to record even wider angle
pictures (0.7M). The close-up lens
(DMW-LC55; optional) allows you to take
close-up pictures of a small subject.
1Remove the lens cap.
2attach the conversion lens or the
close-up lens.
• Conversion lens cannot be...

Menu Settings
98VQT0X92
5Rotate the zoom ring to Tele or
Wide.
: Zoom ring
• Always set to Tele when using a tele
conversion lens and to Wide when
using a wide conversion lens. The
conversion icon ([ ] or [ ]) changes
from red (blinking) to white.
• When using a conversion lens, ensure
the conversion icon is white when
taking pictures. If pictures are taken
when it is blinking, performance will not
be up to specification.
wRecordable range when using a
conversion lens
When attaching the tele...

Menu Settings
99 VQT0X92
• The full range of the zoom can be used
when using the close-up lens.
• Digital zoom cannot be used when using a
wide conversion lens.
• When there is dirt (water, oil, and
fingerprints, etc.) on the surface of the
lens, the image may be affected. Lightly
wipe the surface of the lens with a soft,
dry cloth before and after taking pictures.
• Ensure that [CONVERSION] is set to
[OFF] when not using a conversion lens or
close up lens.
• When using the conversion lens or...

Menu Settings
100VQT0X92
• What screen will be displayed here
depends on the flash mode setting of
the external flash unit
• When the flash mode of the dedicated
flash is set to [TTL AUTO], various
different flash settings can be selected to
suit the recording mode. For the flash
settings that can be selected, refer to P49.
• When the flash mode of the dedicated
flash is set to [TTL AUTO] or [AUTO], the
flash output can be adjusted by the
camera. For details, refer to the operating
instructions...
