Panasonic Dmc Fz50 Operating Instructions Manual

Menu Settings
101 VQT0X92
• You can set the aperture value, the shutter
speed and the ISO sensitivity on the
camera even when attaching the external
flash.
• Some commercial external flashes have
synchro terminals with high-voltage or
reversed polarity. Using such extra flashes
may cause a malfunction or the camera
may not operate normally.
• If you use commercially available
external flashes with communication
functions other than the dedicated one,
they may not operate normally or they
may...

Menu Settings
102VQT0X92
Using the [PLAY] mode
menu
You can use various functions in playback
mode to rotate pictures, set protection for
them etc.
• Refer to P102  to 111 for each menu item.
1Press [MENU/SET].
2Press / to select the menu
item and then press .
• Press  at  to switch to the next
menu screen.
• After performing steps 1 and 2, refer to
the description of the menu item in the
operating instructions and then set it.
wAbout the menu screen items• There are 3 menu screens (1/3, 2/3...

Menu Settings
103 VQT0X92
• The cursor displayed during a slide
show  or while a slide show is paused
 or during [MANUAL] slide show  is
the same as ///.
•Press  to pause the slide show. Press
 again to cancel pause.
•Press / while paused to display the
previous or next picture. (However, the
selected effect is disabled.)
3Press  to finish.
wSetting the audio, duration and effect
Select [DURATION], [EFFECT] or [AUDIO]
on the screen shown in step
2 and set.• You can only select [MANUAL]...

Menu Settings
104VQT0X92
2Press [MENU/SET] to close the
menu.
3Press  to select the picture
then press
.
• Repeat the above procedure.
•If  is pressed while the [ ] favorites
icon is displayed, [ ] is cleared, and
the favorites setting is canceled.
• You can set up to 999 pictures as
favorites.
wDeleting all favorites
1Select [CANCEL] on the screen shown in
step
1 and then press [MENU/SET].
2Press  to select [YES] and then press
[MENU/SET].
3Press [MENU/SET] to close the menu.
• When...

Menu Settings
105 VQT0X92
2Press  to select the direction
to rotate the picture and then
press [MENU/SET].
3Press [MENU/SET] twice to close
the menu.
wExample
When rotating clockwise ( )
Original
• When [ROTATE DISP.] is set to [ON],
pictures recorded holding the camera
vertically are played back vertically
(rotated).
• If you take pictures when aiming the
camera up or down, it may not be possible
to display the pictures vertically. (P34)
• The picture may be slightly blurred when
the...

Menu Settings
106VQT0X92
wSingle setting
1Press  to select the picture
to print and then press
 to
set the number of prints.
• The number of prints icon [ ]
appears.
• The number of prints can be set from
0 to 999. The DPOF print setting is
canceled when the number of prints is
set to [0].
2Press [MENU/SET] twice to close
the menu.
wMulti setting
1Press  to select the picture
to print then press
 to set
the number of prints.
• The number of prints icon [ ]
appears.
• Repeat the...

Menu Settings
107 VQT0X92
• DPOF print setting is a convenient
function when printing pictures with a
printer that supports PictBridge. The date
printing setting on the printer may take
priority over the date printing setting on
the camera. Check the date printing
setting on the printer also. (P115)
• It is necessary to delete all previous
DPOF print information made on other
equipment when setting DPOF print on
the camera.
• If the file is not based on the DCF
standard, the DPOF print setting...

Menu Settings
108VQT0X92
Press [ ] to display the [PLAY] mode
menu and select the item to set. (P102)
You can add the audio after taking a
picture.
1Press  to select the picture
and then press
 to start audio
recording.
• The message [OVERWRITE AUDIO
DATA?] screen appears when audio has
already been recorded. Press  to
select [YES] and then press [MENU/
SET] to start audio recording. (The
original audio is overwritten.)
• Audio dubbing cannot be used with the
following pictures.
– Motion...

Menu Settings
109 VQT0X92
2Press  to select the size and
then press
.
• Sizes smaller than the recorded picture
are displayed.
– [ ]/[ ]/[ ]/[ ]/[ ]/[ ]
(When the aspect ratio setting is
[].)
–[ ]/[ ]/[ ]
(When the aspect ratio setting is
[].)
–[ ]/[ ]
(When the aspect ratio setting is
[].)
• The message [DELETE ORIGINAL
PICTURE?] appears.
3Press  to select [YES] or
[NO] and then press [MENU/SET].
• The picture is overwritten when you
select [YES]. Resized pictures cannot
be restored...

Menu Settings
110VQT0X92
5Press  to select [YES] or
[NO] and then press [MENU/SET].
• The picture is overwritten when you
select [YES]. The trimmed pictures
cannot be restored when they are
overwritten.
• A trimmed picture is newly created
when you select [NO].
• When the original picture is protected,
you cannot overwrite it. Select [NO] and
newly create a trimmed picture.
6Press [MENU/SET] twice to close
the menu.
\
• Depending on the cut size, the picture size
of the trimmed picture may...
