Menu Settings
111 VQT0X92
4Press /to select [YES] or
[NO] and then press [MENU/SET].
• The picture is overwritten when you
select [YES]. If you convert the aspect
ratio of a picture and then overwrite it,
you cannot restore it.
• A picture with the converted aspect
ratio is newly created when you select
[NO].
• When the original picture is protected,
you cannot overwrite it. Select [NO] and
newly create a picture with the
converted aspect ratio.
5Press [MENU/SET] twice to close
the menu.
•...

Connecting to other equipment
112VQT0X92
Connecting to other equipment
Connecting to a PC
You can acquire recorded pictures to a PC
by connecting the camera and the PC.
The software [LUMIX Simple Viewer] or
[PHOTOfunSTUDIO-viewer-]
(for Windows
®) in the CD-ROM (supplied)
allows you to easily acquire pictures
recorded with the camera to a PC, print
them and send them by e-mail.
If you use “Windows98/98SE”, install
the USB driver and then connect it to
the computer.
For information about...

Connecting to other equipment
113 VQT0X92
[Windows]
The drive appears in the [My Computer] folder.• If you are connecting the camera to a PC
for the first time, the required driver is
installed automatically so that the camera
can be recognized by “Windows Plug and
Play”. The drive then appears on the
[My Computer] folder.
[Macintosh]
The drive is displayed on the screen.
• The drive is displayed as [LUMIX] when
you connect the camera with no card
inserted.
• The drive is displayed as [NO_NAME] or...

Connecting to other equipment
114VQT0X92
3When recording after selecting
[NO.RESET] (P29) from the [SETUP]
menu. (Pictures will be recorded to a
new folder with a number sequential to
the folder recorded to immediately
before. By using [NO.RESET] on a card
that does not contain folders or pictures,
such as one just formatted, the folder
number can be reset to 100.)
wPictBridge (PTP) setting
Even if you set [USB MODE] to
[PictBridge (PTP)], you can connect to your
PC if the OS is “Windows XP” or...

Connecting to other equipment
115 VQT0X92
Printing the Pictures
By connecting the camera directly to a
printer supporting PictBridge via the USB
connection cable (supplied), you can select
the pictures to print and start printing on the
camera’s screen.
Set print settings such as the print quality
on the printer beforehand. (Read the printer
operating instructions.)
: USB connection cable (supplied)
: AC adaptor (DMW-AC7; optional)
• It may take time to print some pictures.
Use a battery with...

Connecting to other equipment
116VQT0X92
wSingle picture
1Press  to select
[SINGLE PICTURE] and then
press
[MENU/SET].
2Press  to select the picture
and then press
.
• The message disappears in about
2 seconds.
3Press to select [PRINT START]
and then press
[MENU/SET].
• Press [MENU/SET] to cancel printing.
4Disconnect the USB connection
cable after printing.
wSetting date printing, the number of
prints, the paper size and the page
layout
Select and set each item in step
3.
• Items not...

Connecting to other equipment
117 VQT0X92
• An item cannot be selected if the printer
does not support the page layout.
wDPOF picture
• Set the DPOF print setting on the
camera in advance. (P105)
1Press  to select
[DPOF PICTURE] and then press
[MENU/SET].
2Press to select [PRINT START]
and then press [MENU/SET].
• You cannot select [PRINT START]
when the DPOF print setting is not set.
Select [DPOF SET] and then set the
DPOF print setting. (P105)
• Press [MENU/SET] to cancel printing....

Connecting to other equipment
118VQT0X92
Playing Back Pictures
on a TV Screen
wPlaying back pictures using the AV
cable (supplied)
• Set the aspect of the TV on the camera.
(P30)
• Turn the camera and the TV off.
1Connect the AV cable
(supplied) to the [AV OUT] socket
on the camera.
• Connect the AV cable with the [ ]
mark facing the [] mark on the
[AV OUT] socket.
• Hold the AV cable at  and insert
straight in or take straight out.
2Connect the AV cable to the video
input and the audio input...

Others
119 VQT0X92
Others
Using the MC
Protector/ND Filter
The MC protector (DMW-LMC55; optional)
is a transparent filter which affects neither
the colors nor the amount of light, so it can
always be used to protect the camera’s
lens.
The ND filter (DMW-LND55; optional)
reduces the amount of light to
approximately 1/8th (equal to adjusting the
aperture value 3 increments) without
affecting the color balance.
1Remove the lens cap.
2Attach the MC protector  or the
ND filter .
• You cannot...

Others
120VQT0X92
Using the Remote
Shutter
If you use the remote shutter (DMW-RSL1;
optional), you can avoid jitter (camera
shake) when using a tripod. The remote
shutter works similar to the shutter button
on the camera.
1Connect the remote shutter  to
the [REMOTE] socket on the
camera firmly.
2Take a picture.
: Press the button lightly to press
halfway.:
Press the button fully to take the
picture. (Press it as far as it will go.)
wAbout [LOCK] on the remote shutter
• You can keep the shutter...
