Panasonic Dmc Fz50 Operating Instructions Manual

Advanced
81 VQT0X92
Playing Back Motion
Pictures/Pictures with
Audio
wMotion pictures
Press  to select a picture
with a motion picture icon [ ]/
[]/[]/[]/[ ]/
[ ] and then press
 to play
back.
• The motion picture recording time  is
displayed on the screen. After playback
starts, the motion picture recording time
disappears and the elapsed playback time
is displayed on the bottom right of the
screen.
For example, 1 hour 20 minutes and
30 seconds is displayed as [1h20m30s].
• The cursor...

Menu Settings
82VQT0X92
Menu Settings
Using the [REC] Mode
Menu
Increase the variety of pictures you can
take by setting color effect, picture
adjustment etc.
• Set the mode dial to the desired recording
mode.
• Menu items differ depending on the mode
selected with the mode dial (P6). This
page describes how to set [AUDIO REC.]
in program AE mode [ ]. (Refer to P83  to
101 for each menu item.)
• Select [RESET] in the [SETUP] menu to
return the menu settings to the initial
settings at the time...

Menu Settings
83 VQT0X92
wUsing FUNCTION setting
You can use the [FUNCTION] button to
easily set the following 6 items when
recording.
• AF mode (P90)
• Metering mode (P89)
• White balance (P83)
• ISO sensitivity (P85)
• Picture size (P87)
• Quality (P87)
1Press [FUNCTION] when
recording.
2Press /// to select the
menu item and then press
[FUNCTION] to close the menu.
• You can select menu items by rotating
the front dial or rear dial.
• The menu items that can be set differ
depending on the...

Menu Settings
84VQT0X92
wAuto white balance
The available white balance range is shown
in the following illustration. When you take
a picture beyond the available white
balance range, the picture may appear
reddish or bluish. Even when you take a
picture inside the range shown in the
illustration, auto white balance may not
operate properly if there are many light
sources or there is no color close to white.
In these cases, set the white balance to a
mode other than [AUTO].
1 Auto white balance...

Menu Settings
85 VQT0X92
Press [ ] to display the [REC] mode
menu and select the item to set. (P82)
You can adjust the white balance finely
when you cannot acquire the desired hue
by setting the white balance.
1Press /// to finely adjust
the white balance.
•: A (AMBER: ORANGE)
• : B (BLUE: BLUISH)
• : GA(GREEN: GREENISH)
• : MB (MAGENTA: REDDISH)
2Press [MENU/SET] to finish.
• You can also press the shutter
button halfway to finish.
• If you finely adjust the white balance to
A (amber),...

Menu Settings
86VQT0X92
• When setting to [AUTO], the ISO
sensitivity is automatically adjusted from
[ISO100] to [ISO200] according to the
brightness. (It can be adjusted from
[ISO100] to [ISO400] when using the
flash.)
wAbout [ ] (Intelligent ISO
sensitivity control)
The camera detects the movement of the
subject near the center of the screen and
then sets the optimal ISO sensitivity and
shutter speed according to the movement
and the brightness of the subject.
• Jitter is avoided when taking...

Menu Settings
87 VQT0X92
• ISO sensitivity cannot be set in motion
picture mode [ ].
• To avoid picture noises, we recommend
reducing the ISO sensitivity, setting
[NOISE REDUCTION] in [PICT.ADJ.] to
[HIGH] or setting the items except
[NOISE REDUCTION] to [LOW] to take
pictures. (P94)
• Refer to P57 for information about Shutter
speed.
Press [ ] to display the [REC] mode
menu and select the item to set. (P82)
By changing the aspect ratio, you can
select an angle of view that matches the...

Menu Settings
88VQT0X92
wWhen the aspect ratio is [ ].
wWhen the aspect ratio is [ ].
wWhen the aspect ratio is [ ].
wQuality
You can increase the number of recordable
pictures without changing the picture size if
quality is set to [ ].
• The number of pixels that can be selected
differs depending on the aspect ratio. If
you change the aspect ratio, set the
picture size.
• “EZ” is an abbreviation of
“Extended optical Zoom”. This is a
function which further extends the optical
zoom ratio. If you...

Menu Settings
89 VQT0X92
Press [ ] to display the [REC] mode
menu and select the item to set. (P82)
You can record audio with the still picture if
this is set to [ON]. This means you can
record the conversation that took place
when you were recording or an explanation
of the picture.
• [ ] appears on the screen when you set
[AUDIO REC.] to [ON].
• Focus on the subject and press the
shutter button to start recording.
Recording will automatically stop about
5 seconds later. There is no need to...

Menu Settings
90VQT0X92
Press [ ] to display the [REC] mode
menu and select the item to set. (P82)
Select the mode that matches the
recording conditions and the composition.wAbout [ ] and [ ]
• You can focus on the subject more quickly
than other AF modes.
• The picture may stop moving for a
moment before being brought into focus
when you press the shutter button
halfway. This is not a malfunction.
wSelecting the AF area
When selecting 1-area-focusing or
1-area-focusing (High speed), the AF area...
