Advanced
71 VQT0X92
Recording which day
of the vacation you
take the picture
If you set the departure date in advance,
you can record which day of the vacation
you take the picture.
• When you play back a picture, the date on
which it was taken is displayed.
: The number of days that have passed
since the departure date
• The number of days that have passed
since the departure date can be printed
on each picture by using the software
[LUMIX Simple Viewer] or
[PHOTOfunSTUDIO-viewer-] in the...

Advanced
72VQT0X92
7Take a picture.
: The number of days that have passed
since the departure date
• The current date and time and which
day of the vacation it is are displayed for
about 5 seconds at the bottom of the
screen if the camera is turned on when
the travel date is set, after setting the
clock, departure date or travel date,
after changing the world time setting
and after switching from playback mode
to another mode.
• When [TRAVEL DATE] is set, [ ]“
appears on the lower right of...

Advanced
73 VQT0X92
Displaying the time at
the travel destination
(World Time)
If you set your home area and the travel
destination area when traveling abroad
etc., the local time at the travel destination
area can be displayed on the screen and
recorded on the pictures taken.
• Select [CLOCK SET] to set the current
date and time in advance. (P26)
1Press [MENU/SET] and then
press
.
2Press  to select the [SETUP]
menu icon [ ] and then press
.
3Press / to select
[WORLD TIME] and then...

Advanced
74VQT0X92
• If you are setting the home area for the
second time etc., the screen returns to the
screen shown in step
3 after you press
[MENU/SET] to set your home area.
Press [MENU/SET] again to close the
menu.
wSetting the travel destination area
(Perform steps
1,2 and 3.)
Press  to select [DESTINATION] and
then press [MENU/SET] to set.
: Depending on the setting, the time at
the travel destination area or the
home area is displayed.
• If you are setting the travel destination...

Advanced
75 VQT0X92
_“GMT” is an abbreviation of “Greenwich Mean Time”.
Location candidates for World Time settings
Offset from
GMTListed location name
-11 Midway Islands Samoa
-10 Hawaii Honolulu Tahiti
-9 Alaska Anchorage
-8 Vancouver Seattle Los Angeles
-7 Denver Phoenix
-6 Chicago Houston Mexico City
-5 Toronto New York Miami Lima
-4 Caracas Manaus La Paz
-3:30 Newfoundland
-3 Rio de Janeiro Sao Paulo Buenos Aires
-2Fernando de
Noronha
-1 Azores
0 London Casablanca
+1 Berlin Paris Rome Madrid
+2...

Advanced
76VQT0X92
Motion Picture Mode
1Press the shutter button halfway
to focus and then press it fully to
start recording.
• When the subject is focused, the focus
indication lights.
• The aperture value is fixed to the
setting when recording starts (first
frame).
• The available recording time  is
displayed on the top right and the
elapsed recording time  is displayed
on the bottom right of the screen.
For example, 1 hour 20 minutes and
30 seconds is displayed as
[1h20m30s].
• The...

Advanced
77 VQT0X92
• You can record smoother motion
pictures with “30 fps”.
• You can record longer motion pictures
with “10 fps” although the picture quality
is lower.
• The file size with [10fpsQVGA] is small
so it is suitable for e-mails.
6Press [MENU/SET] to close the
menu.
• You can also press the shutter
button halfway to close the menu.
•The focus range is 30 cm  (0.98 feet)
[AF MACRO: 5 cm (0.16 feet)] (Wide)/
2 m (6.56 feet) (Tele) to
c.
• Refer to P131 for information about the...

Advanced
78VQT0X92
Displaying Multiple
Screens (Multi Playback)
1Rotate the front dial to the left to
display multiple pictures.
(Screen when 9 screens are displayed)
1 screen9 screens
25 screensCalendar screen display
• After the multiple screens are
displayed, rotate the front dial further
towards the left to display 25 screens
and the calendar screen (P79). Rotate
the front dial towards the right to return
to the previous screen.
• When you switch to multiple screens, a
scroll bar ...

Advanced
79 VQT0X92
Displaying pictures by
recording date
(Calendar playback)
You can display pictures by recording date
using the calendar playback function.
1Rotate the front dial towards the
left to display the calendar
screen.
• The recording date of the picture
selected in the playback screen
becomes the date selected when the
calendar screen is first displayed.
• If there are multiple pictures with the
same recording date, the first picture
recorded on that day is displayed.
• The...

Advanced
80VQT0X92
Using the Playback
Zoom
1Rotate the front dial towards the
right to enlarge the picture.
• When you rotate the front dial towards
the left after the picture is enlarged, the
magnification becomes lower. When
you rotate the front dial towards the
right, the magnification becomes
higher.
• When you change the magnification,
the zoom position indication  appears
for about 1 second so that you can
check the position of the enlarged
section.
2Press to move the...
