Panasonic Dmc Fz50 Operating Instructions Manual

Preparation
11 VQT0X92
5 Diopter Adjustment Dial (P44)
6 Viewfinder (P13, 43)
7 [DISPLAY] Button (P43)
8 [EVF/LCD] Button (P43)
9 [FOCUS/AE LOCK] Button (P35, 92)
10 Speaker (P81)
11 Rear dial (P33, 40, 57, 58)
12 LCD Monitor (P13, 24, 43)
13 [FUNCTION] Button (P83)
14 Delete Button (P41)
15 Cursor Buttons
/Self-timer Button (P51)
/[REV]Button (P39)
/Flash Setting Button (P47)
/Exposure Compensation (P52)/Auto
Bracket (P53)/Flash Output Adjustment
(P49)/Backlight Compensation in auto
mode (P36)...

Preparation
12VQT0X92
Quick Guide
This is an overview of how to record and
playback pictures with the camera. For
each step, be sure to refer to the pages
indicated in brackets.
1Charge the battery. (P16)
• The battery is not charged when the
camera is shipped. Charge the
battery before use.
2Insert the battery and the card.
(P18, 19)
3Turn the camera on to take
pictures.
• Set the clock. (P26)
Set the mode dial to [ ].
Press the shutter button to take
pictures. (P32)
4Play back the pictures....

Preparation
13 VQT0X92
Screen DisplayIn recording
  Out-of-frame display
1 Recording mode (P32)
2 Flash mode (P47)
3 Focus (P32)
4 Picture size (P87)
5 Quality (P87)
In Motion picture mode (P76)
//// /
: Jitter alert (P35)
6 Battery indication (P16)
7 Number of recordable pictures/
Available recording time
In Motion picture mode (P76)
e.g.:
8 Card access indication (P20)
9 Recording state
10 Histogram (P46)
11 Travel date (P71)
12 Elapsed recording time (P76)
13 Program shift (P33)
14 Shutter speed...

Preparation
14VQT0X92
24 White balance (P83)
White balance fine adjustment (P85)
25 ISO sensitivity (P85)
26 Burst (P55)
: Audio recording (P76, 89)
27 Flip animation (P95)
28 Color effect mode (P94)
29 Custom setting (P62)
30 Continuous AF (P91)
31 Zoom (P37)/Extended optical zoom
(P37)/Digital zoom (P38)
32 Operation for backlight compensation (P36)
33 Current date and time
• This is displayed for about 5 seconds
when the camera is turned on, after
setting the clock and after switching
from...

Preparation
15 VQT0X92
17 Number of days that have passed since
the travel date (P71)
18 Audio playback (P81)
: In motion picture mode
(P81)
19 Flip animation (P95)
20 Favorites (P103)
PLAY MOTION

Preparation
16VQT0X92
Charging the Battery
with the Charger
The battery is not charged when the
camera is shipped. Charge the battery
before use.
1Insert the battery terminals and
attach the battery to the charger.
2Connect the charger to the
electrical outlet.
• Charging starts when the [CHARGE]
indicator  lights green.
• If the [CHARGE] indicator blinks, refer
to P17.
3Detach the battery after charging
is complete.
• Charging is complete when the
[CHARGE] indicator  turns off (after
about...

Preparation
17 VQT0X92
• Using the supplied battery.
• Starting recording 30 seconds after the
camera is turned on. (When the optical
image stabilizer function is set to
[MODE1])
•Recording once every 30 seconds with
full flash every second recording.
• Turn the camera off every 10 recordings.
• CIPA is an abbreviation of
[Camera & Imaging Products
Association].
_The number of recordable pictures
decreases when the power LCD function
is used.
The number of recordable pictures
when using the...

Preparation
18VQT0X92
Inserting /Removing
the Battery
• Check that the camera is turned off.
• Close the flash.
1Slide the release lever in the
direction of arrow and open the
battery door
.
€ Always use genuine Panasonic
batteries (CGR-S006A).
2Insert:
Insert the charged battery until it
clicks.
Remove:
Slide the lock  to remove the
battery.
3Close the battery door.
Slide the release lever in the
direction of the arrow.
• Remove the battery after use.
• When a fully charged battery has been...

Preparation
19 VQT0X92
Inserting/Removing
the Card
• Check that the camera is turned off.
• Prepare an SD Memory Card (supplied),
an SDHC Memory Card (optional) or a
MultiMediaCard (optional).
• Close the flash.
1Slide the card door to open it.
2Insert:
Insert the card fully until it clicks
and it is locked.
Remove:
Push the card until it clicks, then
pull the card out upright.
• Check the direction of the card.
• Do not touch the connection terminals
on the back side of the card.
• The card may be...

Preparation
20VQT0X92
About the Card
wAccess to the card
The card access indication  lights red
when pictures are being recorded onto the
card.
When the card access indication lights,
pictures are being read or deleted or the
card is being formatted. Do not:
• turn the camera off.
• remove the battery or the card.
• shake or impact the camera.
The card and the data may be damaged or
the camera may not operate normally.
wSD Memory Card (supplied), SDHC
Memory Card (optional) and
MultiMediaCard...
