Basic
41 VQT0X92
• In review playback in recording mode
and in multi playback (P78), the
pictures can only be forwarded or
rewound one by one.
• This camera is based on the DCF
standard “Design rule for Camera File
system” which was established by the
“JEITA (Japan Electronics and Information
Technology Industries Association)”.
• The file format that can be played back on
the camera is JPEG. (In some cases,
even JPEG pictures cannot be played
back.)
• The LCD monitor may not be able to...

Basic
42VQT0X92
• If you select [MULTI DELETE], perform
steps
3 onwards.
• If you select [ALL DELETE], perform
steps
5 onwards.
• When [FAVORITE] (P103) is set to
[ON], [ALL DELETE EXCEPT ]
appears. If you select [ALL DELETE
EXCEPT ], perform steps
5 onwards.
(However, if none of the pictures have
[ ] displayed, you cannot select [ALL
DELETE EXCEPT ] even if
[FAVORITE] is set to [ON].)
3Press  to select the picture
and then press
 to set.
(Only when selecting [MULTI DELETE])
• Repeat the...

Advanced
43 VQT0X92
Advanced
About the LCD
Monitor/Viewfinder
Switching the LCD monitor/ViewfinderPress the [EVF/LCD] button to switch the
monitor screen.
LCD monitor (LCD)
Viewfinder (EVF)
• When the LCD monitor turns on, the
Viewfinder turns off (and vice versa).
Selecting the screen to be used
Press the [DISPLAY] button to change the
display.
• When the menu screen appears, the
[DISPLAY] button is not activated.
In playback zoom (P80), while playing
back motion pictures (P81) and during a...

Advanced
44VQT0X92
In playback mode
Normal display
Display with recording information and
histogram

No display
_5 Displayed if [BIRTHDAY SET.] and
[WITH AGE] were set in [BABY1]/
[BABY2] (P69) in scene mode before
taking pictures.
_6 The number of days that have passed
since the travel date are displayed if
[TRAVEL DATE] (P71) is set.
• In [NIGHT PORTRAIT] (P66),
[NIGHT SCENERY] (P66), [FIREWORKS]
(P68) and [STARRY SKY] (P68) in scene
mode, the guide lines is grey.
wOut-of-frame display
You...

Advanced
45 VQT0X92
• There may be white saturated areas if the
distance to the subject is too close when
taking pictures with the flash. White
saturated areas appear blinking in black.
wBrighten the LCD monitor for use
outdoors. (Power LCD)
Press and hold the [DISPLAY] button for
more than 1 second to activate the power
LCD function. The LCD monitor becomes
brighter than normal and it becomes easier
to use outdoors.
: Power LCD indication
• While taking a picture, the LCD monitor
automatically...

Advanced
46VQT0X92
wHistogram
• A histogram is a graph that displays
brightness along the horizontal axis (black
to white) and the number of pixels at each
brightness level on the vertical axis.
• It allows you to easily check a picture’s
exposure.
• It is very useful if manual adjustments of
the lens aperture and shutter speed are
available, especially in those situations
where automatic exposure may be difficult
due to uneven lighting. Using the
histogram feature allows you to get the
maximum...

Advanced
47 VQT0X92
Taking Pictures using
the Built-in Flash
To open the flash
Slide the [ OPEN] lever.
To close the flash
Press the flash until it clicks.
• Be sure to close the flash when not in use.
• The flash setting is fixed to Forced OFF
[ ] while the flash is closed.
wSwitching to the appropriate flash
setting
Set the flash to match the recording.
1Press  [].
2Press / to select a mode.
• You can also press  [ ] to select.
• For information about flash settings that
can be selected,...

Advanced
48VQT0X92
wAvailable flash settings by recording
mode
The available flash settings depend on the
recording mode.
(n: Available, —: Not available)
• The flash setting may change if the
recording mode is changed. Set the flash
setting again if necessary.
_2 The setting is not available when the
back light compensation function is
activated.wThe available flash range to take
pictures
The available flash range to take pictures
depends on the ISO sensitivity selected.
1
2
ISO...

Advanced
49 VQT0X92
• The available flash range is an
approximation.
• Refer to P85 for the ISO sensitivity.
• Refer to P34 for the focus range.
• If ISO sensitivity is set to [AUTO] or
[ ] when using the flash, it will be
automatically increased to a maximum of
[ISO400].
• To avoid picture noises, we recommend
reducing the ISO sensitivity, setting
[NOISE REDUCTION] in [PICT.ADJ.] to
[HIGH] or setting the items except
[NOISE REDUCTION] to [LOW] to take
pictures. (P94)
• In motion picture mode [...

Advanced
50VQT0X92
2Press [MENU/SET] to finish.
• You can adjust from [L2 EV] to [K2EV]
in steps of [1/3 EV].
• When the flash output is adjusted, the
flash output value appears on the upper
left of the screen.
• The flash output setting is memorized
even if the camera is turned off.
• The flash output cannot be adjusted in
the following cases:
– In the auto mode [ ]
– In the motion picture mode [ ]
– In [SCENERY], [NIGHT SCENERY],
[FIREWORKS], [STARRY SKY] or
[HIGH SENS.] in scene mode
• When...
