Panasonic Dmc Fz50 Operating Instructions Manual

Preparation
31 VQT0X92
[SCENE MENU]
Press [ ] to display the [SETUP] menu
and select this item. (P27)
[AUTO]:[SCENE MODE] menu appears
automatically when setting the
mode dial to scene mode. Select
the desired scene mode. (P64)
[OFF]:[SCENE MODE] menu does not
appear when setting the mode
dial to scene mode and the
camera is operated in scene
mode currently selected. If you
change the scene mode, press
[MENU/SET] to display the
[SCENE MODE] menu and then
select the desired scene mode....

Basic
32VQT0X92
Basic
Taking Pictures
The camera automatically sets the shutter
speed and the aperture value according to
the brightness of the subject.
• Remove the lens cap.
1Turn the camera on.
Select program AE mode [ ].
• The power indicator  (green) lights.
When it blinks, the remaining battery
power is low. Insert a fully charged
battery.
2Aim the AF area  to the point
you want to focus on and then
press the shutter button halfway.
•: Press the shutter button halfway to
focus.
•:...

Basic
33 VQT0X92
• To avoid picture noise, we recommend
decreasing the ISO sensitivity, and/or
setting [NOISE REDUCTION] in
[PICT.ADJ.] to [HIGH] or setting every
item except [NOISE REDUCTION] to
[LOW]. (P94).
(ISO sensitivity is set to [AUTO] when the
camera is shipped. Therefore, when
taking pictures indoors etc. the ISO
sensitivity increases.)
wProgram shift
In program AE mode, you can change the
preset aperture value and shutter speed
without changing the exposure. This is
called program...

Basic
34VQT0X92
• Make sure the camera does not shake
when you press the shutter button.
• Do not cover the microphone or the AF assist
lamp with your fingers or other objects.
• Do not touch the front of the lens.
• If the LCD monitor screen is difficult to see
because of light from the sun etc. shining
on it, we recommend using your hand or
another object to block the light when
using the camera.
When recording with LCD Monitor
When recording with Viewfinder
: When holding the camera vertically...

Basic
35 VQT0X92
In dark places, the AF assist lamp (P91)
may turn on to focus on the subject.
• Even when the focus indication appears
and the subject is focused, it is canceled if
you release the shutter button. Press the
shutter button halfway again.
• Please do not rotate the zoom ring during
auto focus.
wPreventing jitter (camera shake)
• Be careful of jittering when pressing the
shutter button.
• If jitter could occur because of slow
shutter speed, the jitter alert  appears.
•
When the...

Basic
36VQT0X92
Taking Pictures in
Auto Mode
This mode allows beginners to take pictures
easily. The settings for those functions which
are easy to make mistakes with are fixed at
the time of purchase allowing pictures to be
taken with fewer mistakes.
wAuto Mode Settings
In auto mode the following items are fixed
at the time of purchase to prevent mistakes
being made when using the camera.
• Select [AF] or [AF MACRO] with the focus
switch.wThe Backlight Compensation
Backlight refers to when light...

Basic
37 VQT0X92
Taking Pictures with
the Zoom
You can make people and subjects appear
closer with the 12M optical zoom and
landscapes can be recorded in wide angle.
(35 mm film camera equivalent: 35 mm to
420 mm)
wTo make subjects appear closer use
Te l e
Rotate the zoom ring  towards
the right.
• When the setting for picture size is
[ ] (10M).
wTo make subjects appear further away
use Wide
Rotate the zoom ring towards
the left.
• When the setting for picture size is
[ ] (10M).
• Depending...

Basic
38VQT0X92
wPicture size and maximum zoom
magnification
(n: Available, —: Not available)
• Refer to P87 for aspect ratio settings and
P87 for picture size.
• “EZ” is an abbreviation of
“Extended optical Zoom”.
• You can further enhance the zoom
magnification with the extended optical
zoom without worrying about further
picture distortion.
• If you set a picture size that activates the
extended optical zoom, the extended
optical zoom icon [ ] is displayed on the
screen when you use the zoom...

Basic
39 VQT0X92
wEntering the digital zoom range
In the [REC] menu (P82), setting [D.ZOOM]
to [2M] or [4M] allows you to magnify a
subject up to a maximum of 48 times.
(Except when using extended optical
zoom.)
Optical zoom
Digital zoom
wThe digital zoom and extended optical
zoom can be used together.
Example: When the digital zoom is set to
[4M] and the picture size to [ ] (3M EZ),
you can use the extended optical zoom at
the same time.
	When using the digital zoom [4M] and
the extended...

Basic
40VQT0X92
3Press to move the
position.
• When you change the magnification or
the position to be displayed, the zoom
position indication  appears for about
1 second so that you can check the
enlarged area.
wDeleting the recorded picture during
Review (Quick deletion)
1Press [ ].
2Press  to select [YES].
3Press [MENU/SET].
• Once deleted, pictures cannot be
recovered. Double-check pictures
before deleting them.
• Multiple pictures or all the pictures can
be deleted. For...
