Advanced
61 VQT0X92
• [MF1]:  The center of the screen is
enlarged. You can adjust the focus
while determining the composition
of the whole of the screen.
• [MF2]:  The whole of the screen is
enlarged. This is convenient when
adjusting the focus in Wide.
• [OFF]:  The screen is not enlarged.
5Press [MENU/SET] to close the
menu.
• You can also close the menu by
pressing the shutter button halfway.
wTechnique for Manual focus
Rotate the focus ring slowly.
Rotate it little more.
Finely focus on...

Advanced
62VQT0X92
2Press /// to change the
expanded area.
• The expansion is canceled after
approximately 2 seconds.
• The following will return the AF area to the
original position.
– Changing the Focus switch to [AF] or
[AF MACRO].
– Changing the picture size or aspect.
– Turning the camera off.
• You can also record with manual focus in
motion picture mode [ ]. However the
screen is not expanded while recording
motion pictures.
• If you focus on the subject in Wide and
then rotate the...

Advanced
63 VQT0X92
5Press  to select [YES] and then
press [MENU/SET].
• When [YES] is selected, the settings
that were previously stored are
overwritten.
• You cannot save the following menu
items because they affect all the
recording modes.
- [CLOCK SET]
- [RESET]
- [NO.RESET].
6Press [MENU/SET] to close the
menu.
Taking pictures in
Custom mode
You can select one of your own custom
settings to suit the picture-taking conditions
and other factors from among the
registered patterns you have...

Advanced
64VQT0X92
Scene Mode
When you select a scene mode to match
the subject and recording situation, the
camera sets the optimal exposure and hue
to obtain the desired picture.
• Refer to P65  to 70 for each scene menu.
1Press / to select the scene
mode.
• Press  at  to switch to the next
menu screen.
• If [SCENE MODE] menu does not
appear, press [MENU/SET] to display
the [SCENE MODE] menu.
• When you press , explanations about
each scene mode are displayed. (When
you press , the...

Advanced
65 VQT0X92
Press [ ] to display the [SCENE MODE]
menu and select a scene mode. (P64)
The background is blurred and the person
stands out with a healthier complexion.
wTechnique for Portrait mode
To increase the effective of this mode:
1Rotate the zoom ring as far as possible
to the right
2Move close to the subject to make this
mode more effective.
• This mode is only suitable when taking
pictures outdoors in the daytime.
Press [ ] to display the [SCENE MODE]
menu and select a scene mode....

Advanced
66VQT0X92
Press [ ] to display the [SCENE MODE]
menu and select a scene mode. (P64)
This mode allows you to take pictures of a
subject and a landscape with near real-life
brightness by using the flash and slowing
down the shutter speed.
wTechnique for Night portrait mode
• Use the flash.
• Since the shutter speed becomes slower,
we recommend using a tripod and the
self-timer (P51) for taking pictures.
• Keep the subject still for about 1 second
after taking the picture.
• We recommend...

Advanced
67 VQT0X92
Move the camera smoothly while
following the subject in the viewfinder.
Press the shutter button while you are
moving the camera.
	Move the camera continuously.
• We recommend the following:
– Using the Viewfinder. (P43)
– Selecting a subject with quick motion.
– Using prefocus. (P61)
– Use this mode with burst mode. (P55)
(You can then select the best pictures
from all the pictures taken.)
• The shutter speed in panning mode
becomes slower to achieve the panning
effect. As a...

Advanced
68VQT0X92
Press [ ] to display the [SCENE MODE]
menu and select a scene mode. (P64)
This mode allows you to take pictures with
a candle-lit atmosphere.
wTechnique for Candle light mode
• If you make the most of the candle light,
you can take successful pictures without
using the flash.
• We recommend using a tripod and the
self-timer (P51) for taking pictures.
• The focus range is 5 cm (0.16 feet)
(Wide)/2 m (6.56 feet) (Tele) to c.
• The flash setting can be set to Slow sync./
Red-eye...

Advanced
69 VQT0X92
could not take in [NIGHT SCENERY] by
making the shutter speed slower.
wSetting the shutter speed
• Select a shutter speed of [15 SEC.],
[30 SEC.] or [60 SEC.].
1Press  to select the number of
seconds and then press [MENU/SET].
2Taking Pictures.
• Press the shutter button to display the
countdown screen. Do not move the
camera after this screen is displayed.
When countdown finishes,
[PLEASE WAIT...] is displayed for the
same length of time as the set shutter
speed for...

Advanced
70VQT0X92
wBirthday setting
1Press  to select [BIRTHDAY SET.]
and then press [MENU/SET].
2When the message [PLEASE SET THE
BIRTHDAY OF THE BABY] appears,
select items (Year/Month/Day) using
/ and set them using /.
3Press [MENU/SET] to finish the setting.
• If you select [WITH AGE] without setting
the birthday in advance, a message is
displayed. Press [MENU/SET] and set the
birthday in steps 2 and 3.
• The focus range is 5 cm (0.16 feet)
(Wide)/2 m (6.56 feet) (Tele) to c.
• The...
