Panasonic Dmc Fz50 Operating Instructions Manual

Advanced
51 VQT0X92
Taking Pictures with
the Self-timer
1Press  [].
2Press / to select a mode.
• You can also press  [ ] to select.
3Press [MENU/SET].
• You can also press the shutter
button halfway to finish.
• The menu screen disappears after
about 5 seconds. At this time, the
selected item is automatically set.
4Press the shutter button halfway
to focus and then press it fully to
take the picture.
•: Press the shutter button halfway to
foc us.
•: Press the shutter button fully to take...

Advanced
52VQT0X92
Compensating the
Exposure
Use this function when you cannot achieve
appropriate exposure due to the difference
in brightness between the subject and the
background. Look at the following
examples.
Under exposed
Compensate the exposure towards
positive.
Properly exposed
Over exposed
Compensate the exposure towards
negative.
1Press  [ ] until [EXPOSURE]
appears, compensate the
exposure with
/.
• You can compensate from [L2EV] to
[K2 EV] in steps of [1/3 EV].
• Select [0 EV]...

Advanced
53 VQT0X92
Taking Pictures using
Auto Bracket
In this mode, 3 pictures are automatically
recorded in the selected exposure
compensation range each time the shutter
button is pressed. You can select the
picture with the desired exposure from the
3 pictures with different exposures.
1Press  [ ] several times until
[AUTO BRACKET] appears, set
the compensation range of the
exposure with
/.
• You can select [0] (OFF), [F1/3 EV],
[F2/3 EV] or [F1EV].
• When you do not use auto bracket,...

Advanced
54VQT0X92
Optical Image
Stabilizer
This mode detects jitter and compensates
for it.
1Press and hold the optical image
stabilizer button  until
[STABILIZER] appears.
2Press  to select the
stabilizer function mode and then
press [MENU/SET].
wDemonstration of the optical image
stabilizer (Demonstration Mode)
Press  to display the demonstration. After
the demonstration ends, the screen returns
to the stabilizer function mode selection
menu. Press  again if you want to exit the...

Advanced
55 VQT0X92
Taking Pictures using
Burst Mode
1Press and hold the burst mode
button.
2Press / to select a mode.
• You can also press the burst mode
button to select.
3Press [MENU/SET].
• You can also press the shutter
button halfway to finish.
• The menu screen disappears after
about 5 seconds. At this time, the
selected item is automatically set.
4Take a picture.
• Hold down the shutter button fully to
activate the burst mode.
wNumber of pictures recorded in burst
mode_The burst speed...

Advanced
56VQT0X92
Taking Close-up
Pictures
This mode allows you to take close-up
pictures of the subject, e.g. When taking
pictures of flowers.
You can take pictures approaching the
subject at a distance up to 5 cm (0.16 feet)
from the lens by rotating the zoom ring
upmost to Wide (1M).
1Set the focus switch to
[AF MACRO].
wFocus range
• We recommend using a tripod and the
self-timer (P51) with AF macro.
• When a subject is close to the camera, the
effective focus range (depth of field) is...

Advanced
57 VQT0X92
Aperture-priority AE
Set the aperture value to a higher number
when you want a sharp focus background.
Set the aperture value to a lower number
when you want a soft focus background.
1Rotate the front dial to the left or
right to set the aperture value.
2Take a picture.
• If the direct exposure compensation
function (P93) is activated, the way in
which the dial is operated changes. The
explanation here shows the direct
exposure compensation function
deactivated as an...

Advanced
58VQT0X92
– Slow sync./Red-eye reduction [ ] (P47)– [AUTO] or [ ] in ISO sensitivity
(P85) (The ISO sensitivity is
automatically set to [ISO100] when you
switch from [AUTO] to Aperture-priority
AE or Shutter-priority AE.)
• The aperture value and the shutter speed
turn red when the exposure is not
adequate.
• We recommend using a tripod when the
shutter speed is slow.
Manual exposure
Determine the exposure by manually
setting the aperture value and the shutter
speed.
1Rotate the front...

Advanced
59 VQT0X92
Aperture Value and
Shutter Speed
Aperture-priority AE
Shutter-priority AEManual exposure
• The aperture values given in the table
above are values when the zoom ring is
rotated to Wide.
• Depending on the zoom magnification,
some of the shutter speeds and aperture
values cannot be selected.
Available Aperture
Va l u e
(Per 1/3 EV)Shutter Speed
(Sec)
F8.0 to F11.0 8 to 1/2000
F7.1 F6.3 F5.6 8 to 1/1600
F5.0 F4.5 F4.0 8 to 1/1300
F3.6 F3.2 F2.8 8 to 1/1000
Available Shutter...

Advanced
60VQT0X92
Taking Pictures with
Manual Focus
Use this function when you want to fix the
focus or when the distance between the
lens and the subject is determined and you
do not want to activate auto focus.
1Slide the focus switch to [MF].
2Rotate the focus ring  to focus
on the subject.
: MF assistance
• The MF assistance appears on the
center of the screen.
• When you stop rotating the focus ring,
the MF assistance disappears about
2 seconds after.
• You can also set [MF ASSIST] to...
