Panasonic Dmc Fz50 Operating Instructions Manual

Preparation
21 VQT0X92
Attaching the Lens
Cap/Strap
wLens Cap (supplied)
1Attach the lens cap.
• When you turn the camera off, carry the
camera or play back the pictures, attach
the lens cap to protect the surface of the
lens.
• Detach the lens cap before turning on the
camera in the recording mode.
• Be careful not to lose the lens cap.wStrap (supplied)
1Pass the strap through the hole at
the strap eyelet.
2Pass the strap through the
stopper and fasten the strap.
: Pull the strap 2 cm or more.
•...

Preparation
22VQT0X92
Attaching the Lens
Hood
In bright sunlight or backlight, the lens hood
will minimize lens flare and ghosting. The
lens hood cuts off excess lighting and
improves the picture quality.
• Check that the camera is turned off.
• Close the flash.
1Place the camera upside down,
align the white mark on the
lens hood with lens hood
positioning groove  on the unit
and insert it straight in until it
clicks.
• Make sure the lens hood is properly
attached.
wWhen removing the lens...

Preparation
23 VQT0X92
wWhen removing the lens hood
Press lock release button
 and
remove the lens hood
• If you press the lock release button too
strongly, it may be difficult to detach the
lens cap.
• Make sure that the mark on the lens hood
is correctly aligned with the lens hood
positioning groove. The lens hood is not
correctly attached if they are not aligned.
• When taking pictures with flash with the
lens hood attached, the lower portion of
the photo may turn dark (vignetting effect)...

Preparation
24VQT0X92
LCD Monitor
Adjusting the LCD monitor makes it
possible to take pictures from various
angles.
wTaking pictures at a normal angle.
• You can switch between the LCD monitor
and the Viewfinder.
wTaking pictures at a high angle
Open the LCD monitor with one of the
LCD monitor open knobs.
• You can use the LCD monitor only.
: LCD Monitor open knobs
• This is convenient when there is someone
in front of you and you cannot get close to
the subject.wTaking pictures at a low angle...

Preparation
25 VQT0X92
wTaking pictures with the camera held
vertically
Take hold of the LCD monitor opening knob
with your fingers, and pull the monitor all
the way toward you (by rotating it 180Q ),
and rotate it to an angle where it is easy to
see. (It can be rotated up to a maximum of
270Q.)
wTaking pictures at a normal angle.
wTaking pictures at a high angle
wTaking pictures at a low angle
• If the LCD monitor turns on when it is
closed with the screen facing inwards, the
camera...

Preparation
26VQT0X92
Setting Date/Time
(Clock Set)
wInitial setting
The clock is not set so the following screen
appears when you turn the camera on.
: [MENU/SET] button
: Cursor buttons
1Press [MENU/SET].
2Press  to select the
date and time.
: Time at the home area
: Time at the travel destination (P73)
•/: Select the desired item
.
•/: Set the display order for the date
and time.
• Press [ ] to cancel the clock setting
without storing the date and time.• Refer to [WORLD TIME] (P73)...

Preparation
27 VQT0X92
About the Setup Menu
• Set items as required. (Refer to P28  to 31
for each menu item.)
• Menu items differ depending on the mode
selected with the mode dial (P6).
The following example shows how to set
[AUTO REVIEW] when program AE mode
[ ] is selected.
• Select [RESET] to return the settings to the
initial settings at the time of purchase. (P30)
1Press [MENU/SET] and then
press
.
2Press  to select the [SETUP]
menu icon [ ] and then press
.
3Press  to select the...

Preparation
28VQT0X92
[CLOCK SET]
Press [ ] to display the [SETUP] menu
and select this item. (P27)
Change date and time. (P26)
[WORLD TIME]
Press [ ] to display the [SETUP] menu
and select this item. (P27)
[ ]: The time at your home area is
set.
[ ]: The local time at the travel
destination area is set.
• Refer to P73 for information about setting
[WORLD TIME].
[CUST. SET MEM.]
Press [ ] to display the [SETUP] menu
and select this item. (P27)
The current camera settings are registered
in [ ], [ ]...

Preparation
29 VQT0X92
[PLAY ON LCD]
Press [ ] to display the [SETUP] menu
and select this item. (P27)
[ON]:If you were using the viewfinder to
record, the display automatically
switches to the LCD monitor when
reviewing or playing back pictures.
(P44)
[OFF]:Does not automatically switch.
[POWER SAVE]
Press [ ] to display the [SETUP] menu
and select this item. (P27)
[1MIN.]/[2MIN.]/[5MIN.]/[10MIN.]:
Power save mode is activated (the
camera is automatically turned off to
save the battery life) if...

Preparation
30VQT0X92
• To reset the folder number to 100, format
(P111) the card first and then use this
function to reset the file number.
A reset screen for the folder number will
then appear. Select [YES] to reset the
folder number.
• Refer to P113 for detailed information
about the file number and the folder
number.
[RESET]
Press [ ] to display the [SETUP] menu
and select this item. (P27)
The [REC], [CUST. SET MEM.] or [SETUP]
menu settings are reset to the initial
settings.
• The birthday...
