Panasonic Multi Hybrid Control Panel Aw Rp505 Operating Instructions

-9-
Caution:In connecting a halogen lamp to the Pan/tilt
Head AC Adaptor (AW-PS300), make sure that it is
in the wattage range of 250 to 500W.  If a halogen
lamp less than 250W is used, the LED may flash
when LAMP ON/OFF Switch @4is in the on position
even if the lamp is normal.
@4Lamp Switch [LAMP, ON/OFF]
Switches on and off the halogen lamp connected to the
lamp AC receptacle of the pan/tilt head AC adapter
(AW-PS300).  Select a pan/tilt head with CONTROL
Switch @2, then switch the halogen lamp on or...

-10-
To preset them in these buttons, first select a camera
and pan/tilt head with CONTROL Switch @22, then select
a head pan/tilt position, lens zoom/focus/iris, or cam-
era white balance (ATW Channel A or B); press MEM-
ORY Switch @7(so it lights yellow green and all the 10
buttons of PRESET Switch @8flash); while keeping the
MEMORY Switch @7depressed, press one of the 10
buttons of PRESET Switch @8) as desired.  The
pressed button in which the selected item is stored
lights.
@8Preset Position...

Note:At the same time as a pan/tilt head is selected
with CONTROL Switch @22, the heater or fan of the
selected pan/tilt head is switched on or off
depending on the position of H/F ON/OFF Switch
#2.
#3Lens Extender Switch [EXT, ON/OFF]
If this switch is connected to a lens with a built-in exten-
der function, it switches on and off the lens extender.
For details, refer to the Operating Instructions for the
Lenses and Pan/tilt Head.
Note:At the same time as a pan/tilt head is selected
with CONTROL Switch...

-12-
#7Focus Lever [FOCUS FAR/NEAR]
Used to adjust the focus of the lens that is connected
to the pan/tilt head selected with CONTROL Switch @22.
Used to adjust the lens focus at varying speed
depending on the angle of the lever.  The lens is
focused far when the lever is moved toward FAR, or
near when the lever is moved toward NEAR, provided
that FOCUS REVERSE Switch %2 is in the NOR posi-
tion.  When FOCUS REVERSE Switch %2 is set to the
REV position, the lens focus operates in the opposite
direction....

-13-
TALLYDC12V IN
AUX  CONTROL  IN
1 2 3 4
5
PREVIEW IN OUT G/L  OUTPREVIEW MONITOR OUT
CONTROL CONTROL  OUTPAN/TILT CAMERA
TD  MULTI  PORT  HUBG / L  IN
#9TALLY Terminal [TALLY] (6-pin Terminal Board)
Connect it to the tally connector on a special effect
generator (SEG) or a video switcher, for example.
When the voltage of any of the jacks [1] to [5] of the ter-
minal falls to the ground level, the corresponding
TALLY Indicator @1and the Tally Indicator on the
Pan/tilt Head (AW-PH300) light red.
$012V...

-14-
$3Preview Video Input Connector [TO MULTIPORT
HUB, PREVIEW IN] (BNC Connector)
Connect it to the preview video output connector
[PREVIEW OUT] on the Multiport Hub with a coaxial
cable (5C-2V or equivalent).  The maximum allowable
length of the cable is 10 meters.
$4Genlock Output Connector [TO MULTIPORT HUB,
G/L OUT] (BNC Connector)
Connect it to the G/L input connector [G/L IN] on the
Multiport Hub with a coaxial cable (5C-2V or equiva-
lent) in operating the camera in external sync mode.
The cable...

-15-
$7Preview Video Output Connector [PREVIEW
MONITOR OUT] (BNC Connector)
The video signals of the camera selected with CON-
TROL Switch @2are output from this connector so that
the selected camera can be visually confirmed.
Connect this connector to the monitor video input with
a coaxial cable.
Note:The preview video signals are for confirmation
of which camera has been selected, so the picture
quality proper to the camera cannot be guaran-
teed.  To output camera video signals, use video
output...

-16-
SPEED.SW
CHANGELOW  HIGH
ZOOM
REVERSENOR   REV
ZOOM/FOCUS
EXCHANGEOFF    ON
FOCUS
REVERSENOR   REV
TILT
REVERSENOR   REV
PA N
REVERSENOR   REV
$9Speed Switch Changing Switch
[SPEED SW CHANGE, LOW/HIGH]
Changes the polarity of SPEED Switch @9.  If ZOOM
lever #6, FOCUS Lever #7, or PAN/TILT Lever #8is
moved while keeping SPEED Switch @9depressed,
the corresponding operation takes place at low
speed, provided that SPEED SW CHANGE Switch $9
is in the LOW position.  If one of these levers is
moved with...

-17-
REV position, the operating directions shown on the
panel are reversed.  In this case, paste the supplied
seal on the panel.
%1Zoom/Focus Exchange Switch
(ZOOM/FOCUS EXCHANGE, ON/OFF]
ZOOM Lever #6and FOCUS Lever #7exchange their
function between them when this switch is set to the
ON position.  Unless this exchange is needed, keep
the switch in the OFF position.
With ZOOM/FOCUS EXCHANGE Switch %1in the ON
position, the operations shown on the panel do not
agree with the indications on the panel....

-18-
Note:TILT REVERSE Switch %3and PAN REVERSE
Switch %4may be used to reverse the operating
direction of the pan/tilt head, but be sure to set the
operating direction of the pan/tilt head with its
mounting direction selection switch during its
installation depending on whether the pan/tilt head
is mounted on the floor or is suspended.  Unless
the mounting direction selection switch on the
pan/tilt head is properly set, the pan/tilt head will
pan or tilt in the opposite direction and the pan/tilt
head...
