Page 51
51 ENGLISHEN 4. Slide the dipstick down completely and pull up again. 5. Read off the oil level. The oil level should be at the “Max” mark as illustrated in fig. 9. If the oil level is below the “Max” mark in fig. 9, fill with oil as follows: 1. Unscrew the oil filler cap (9:C). 2. Fill with the necessary amount of oil. Applica- ble oil types, see “5.4”. 3. Check the level as above. 4. When the level is correct, reinstall the oil filler cap and tighten. The oil level must never exceed the “Max” mark...
Page 52
52 ENGLISHEN 4.8 STOPDisengage the power take-off. Apply the parking brake. If the machine is left unattended, re- move the ignition key. The engine may be very warm immedi- ately after it is shut off. Do not touch the cylinder or cooling fins. This can cause burn injuries. 4.9 CLEANING To reduce the risk of fire, keep the en- gine, silencer, battery and fuel tank free from grass, leaves and oil. To reduce the risk of fire, regularly check the machine for oil and/or fuel leakage. Never use...
Page 53
53 ENGLISHEN 7. To clean the oil filter, see 5.4.1 below before continuing. 8. Remove the filler cap (9:C) and fill with oil. The engine has a capacity of around 1.7 litres. 9. After filling the oil, start the engine and run at idle speed for 30 seconds. 10.Check to see if there is any oil leakage. 11.Stop the engine. Wait for 30 seconds and then check the oil level. See 4.3. Top up the oil if necessary. 5.4.1 Oil filter The oil filter must be cleaned after 1000 hours of operation and when...
Page 54
54 ENGLISHEN The battery is a valve-regulated battery with 12 V nominal voltage. The battery fluid does not need to and cannot be checked or topped up. The only maintenance that is required is charging, for exam- ple after extended storage.The battery must be fully charged be- fore being used for the first time. The battery must always be stored fully charged. If the battery is stored while discharged, serious damage will occur. 5.10.1 Charging wi th the engine The battery can be charged using the...
Page 55
55 ENGLISHEN 5.13 LUBRICATIONAll lubrication points in accordance with the table below must be lubricated every 50 hours of opera- tion as well as after every wash. 5.14 FUSESIf any of the faults listed below occurs, replace the relevant fuse. See fig. 22. 6 PATENT - DESIGN REGISTRA- TION This machine or parts thereof is covered by the fol- lowing patent and design registration: SE9901091-0, SE9901730-3, SE9401745-6, US595 7497, FR772384, DE69520215.4, GB772384, SE0301072-5, SE04/000239 (PCT),...
Page 56
56 FRANÇAISFR 1 GÉNÉRALITÉS Ce symbole est un AVERTISSEMENT. Risque de blessure ou de dégât matériel en cas de non-respect des instructions. Avant de démarrer la machine, lire at- tentivement les instructions ainsi que les consignes contenues dans le fascicule « RÈGLES DE SÉCURITÉ » ci-joint. 1.1 SYMBOLESLes symboles suivants figurent sur la machine. Ils attirent votre attention sur les dangers et les mesu- res à respecter lors de l’utilisation et de la mainte- nance. Explication des symboles...
Page 57
57 FRANÇAISFR 2.4.3 Inhibiteur, frein de stationnement (3:A) Linhibiteur bloque la pédale « embraya- ge-frein » en position enfoncée. Cette fonction permet de circuler sur des ter- rains en pente, de transporter la machine, etc. lorsque le moteur est à l’arrêt. Le frein de stationnement doit toujours être relâché pendant lutilisation de lengin. Verrouillage : 1. Enfoncer à fond la pédale (3:B). 2. Déplacer l’inhibiteur (3:A) vers la droite. 3. Relâcher la pédale (3:B). 4. Relâcher linhibiteur...
Page 58
58 FRANÇAISFR 2.4.12 Levier de débrayage Levier permettant de débrayer la transmission va- riable. Le modèle 2WD est équipé d’un levier connecté à l’essieu arrière. Voir (5:R).Le levier d’embrayage ne doit jamais se trouver entre les positions extérieure et intérieure pour éviter de surchauffer le moteur et d’endommager la transmis- sion. pour permettre de bouger la machine à la main, moteur éteint. Deux positions sont possibles : 1. Levier orienté vers l’inté- rieur – la transmission est acti- vée...
Page 59
59 FRANÇAISFR 3 UTILISATION L’usage de la machine est réservé aux travaux sui- vants, avec les accessoires STIGA d’origine ren- seignés. La charge verticale maximum exercée sur la boule de remorquage doit être inférieure à 100 N. La charge d’inertie maximum exercée sur la boule de remorquage par les accessoires tractés doit être inférieure à 500 N. REMARQUE ! Avant d’utiliser un tracteur, contactez votre compagnie d’assurance. REMARQUE ! Cette machine n’est pas conçue pour circuler sur la voie...
