NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 978NDA-24297, Issue 1
M-42 Multiple Call Forwarding - Don’t Answer - CCIS
Service Conditions (cont’d)
f.) This service is restricted when a call from the CCIS line is forwarded to other lines except CCIS
(for example: C.O. line).
Interactions
When a calling party sets the services shown below while the destination party is in busy status, the services are
performed to the first forwarded party.
1. In the case of Busy Verification - CCIS [B-9] or Executive...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 979
Multiple Call Forwarding - Don’t Answer - CCIS M-42
Interactions (cont’d)
3. InthecaseofCallBack-CCIS[C-44],serviceiseffectivetoStationBinOfficeB.Theserviceisinvalid
to station D.
4. In the case of Step Call - CCIS [S-59], the service is valid to Station B in Office B. The service is invalid
to station D.
Programming
STEP 1:ASYD- System 1, Index 5, Bit 0: Access Code for C.F-Busy Line and C.F-Don’t Answer service. 0/1
= Same/Separate....

NEAX2400 IPX Feature Programming ManualPage 980NDA-24297, Issue 1
M-42 Multiple Call Forwarding - Don’t Answer - CCIS
Programming (cont’d)
STEP 2:ASFC- Allow Call Forwarding-Don’t Answer (SFI = 8) to the SFC of the stations.
STEP 3:ANPD- Assign minimum necessary number of digits for the first number of the access code for C.F-
Don’t Answer service.
STEP 4:ASPA- Assign the access code for C.F-Don’tAnswerservice.
To set: CI = N, SRV = SSC (Service Code), SID = 12
To cancel: CI = N, SRV = SSC (Service...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 981
Multiple Console Operation - CCIS M-43
M-43  Multiple Console Operation - CCIS
General Description
This feature provides console operation where ATTENDANT CONSOLEs [A-3] are installed in more than one
node in the CCIS network.
Operating Procedure
No manual operation is required.
Service Conditions
1. Call transfer among ATTENDANT CONSOLEs [A-3] in different nodes is possible, but call
identification information cannot be transferred from...

NEAX2400 IPX Feature Programming ManualPage 982NDA-24297, Issue 1
M-43 Multiple Console Operation - CCIS
Interactions (cont’d)
4. ATTENDANT CONSOLEs [A-3] may not dial another console directly. Talk path will occur only during
INTERPOSITION TRANSFER [I-5].
5. When more than one ATTENDANT CONSOLE [A-3] is installed, a Primary ATTENDANT CONSOLE
[A-3] may be assigned (AMAT command). This ATTENDANT CONSOLE [A-3] will control the
implementation of DAY/NIGHT CLASS OF SERVICE [D-15].
Programming
STEP 1:ASYD-...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 983
Message Center Interface - CCIS M-67
M-67  Message Center Interface - CCIS
General Description
This service feature provides an INTERFACE to the external CPU for MESSAGE CENTER information when a
specific UCD group or console in a CCIS network is called. This interface allows external control of Message
Waiting Lamp (MWL) indications on equipped PBX stations.
Message Center Interface can also be provided in a network established with FCCS...

NEAX2400 IPX Feature Programming ManualPage 984NDA-24297, Issue 1
M-67 Message Center Interface - CCIS
Operating Procedure (cont’d)
3. The PBX, upon receiving this control data from the MCI, will extinguish or illuminate the MWL
depending on the subscriber displayed on the attendant’s monitor/display.
4. The user at the called station will be able to receive a message from the system by dialing the Pilot number
of the UCD station group connected to the Voice Mail System.
5. The external CPU, upon...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 985
Message Center Interface - CCIS M-67
Service Conditions (cont’d)
ATTENDANT CAMP-ON WITH TONE INDICATION - CCIS [A-45]
AUTOMATIC RECALL [A-8]
Call Return from Hold
Operator Call
LDN Call
Feature 2:
Station dials Message Center Number Directory.
Direct Trunk Call to Message Center.
Trunk Call to Message Center extended by ATTENDANT
Station Call is FORWARDED-ALL CALLS to Message Center.
Trunk Call is FORWARDED-ALL CALLS to Message...

NEAX2400 IPX Feature Programming ManualPage 986NDA-24297, Issue 1
M-67 Message Center Interface - CCIS
Service Conditions (cont’d)
3. The centralized MCI function is activated by assigning MCI equipment and UCD group at the Center
FCCS group. (The MCI message cannot be transmitted to the Centralized MCI between FCCS groups.)
4. The signal of Call Waiting Lamp Controlling is sent from the MCI within the Center FCCS group to the
other FCCS groups and the NEAX2000 IVS
2system.
Programming
STEP 1:ASYD-...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 987
Message Center Interface - CCIS M-67
Programming (cont’d)
System 1, Index 78, Bit 1: (1) Calling and Intermediate Station number indication. Bit 1: (1) Kind of
service class indication.
System 1, Index 116 (Port 0) through Index 123 (Port 7): Assign the kind of terminal = 1: printer/MCI
to the corresponding output port. (Assigned via AIOC.)
System 2, Index 6, Bit 0: MCI service when terminating UCD group in this Tenant. 0/1 = Out/In...
