NEAX2400 IPX Feature Programming ManualPage 458NDA-24297, Issue 1
L-28 LDN Night Connection
FCCS Programming (cont’d)
CCI: Call Category Index (Assign 1 = LDN (C.O. Line))
RES: RestrictionData(Assign1=Allowed)

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 459
LDN Night Connection - Outside L-30
L-30  LDN Night Connection - Outside
General Description
This feature routes LOCAL DIRECTORY NUMBER (LDN) calls to a preselected station outside the system when
the system is in Night mode.
This feature also enables the ATTCON to transmit terminated LDN calls to outside, using the outgoing trunk in the
FCCS network.
Operating Procedure
To answer LDN NIGHT CONNECTION calls (DID, TIE)
1. An incoming LDN...

NEAX2400 IPX Feature Programming ManualPage 460NDA-24297, Issue 1
L-30 LDN Night Connection - Outside
Service Conditions (cont’d)
Note 3:When forwarding destination for this feature is not assigned, busy tone is sent.
10. When assigning a forwarding destination number for Night Mode using ALDNN command, the maximum
16 digits can be programmed by using TYPE = 1 (Station Number) / 2 (DC). If the user requires digit
number greater than 16 or more, assign an Abbreviated Digit Number (ADC) of the forwarding...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 461
LDN Night Connection - Outside L-30
Service Conditions (cont’d)
19. When system is changed from Day Mode to Night Mode while a LDN call is terminating to ATTCON,
the LDN call is transferred to preprogrammed forwarding destination. If the LDN call cannot be
transferred according to normal priority by restriction for the forwarding destination, the LDN call is
processed in order of following precedence:
1. TRUNK ANSWER FROM ANY STATION...

NEAX2400 IPX Feature Programming ManualPage 462NDA-24297, Issue 1
L-30 LDN Night Connection - Outside
FCCS Programming
The following command assignments are required to use this feature via FCCS link.
When destination number is programmed by using TYPE = 2 (DC) of ALDNN command
STEP 1:ASYDL- System Data 1, Index 640, Bit 0-7. Assign FPC of a node which transmits Day/Night
changeover information.
System Data 1, Index 704-735. Assign FPC of a node which receives the Day/Night changeover
information...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 463
LDN Night Connection - Outside L-30
FCCS Programming (cont’d)
STEP 2:ANPDN- Assign the first digit for Listed Directly Number (LDN) and forwarding destination.
TN: Tenant Number (1-255)
1st DC: 1st Digit Code (0-9,*,#)
CI: Connection Status Index (N = Normal/H = Hooking/B = Busy)
NND: Number of Necessary Digits (max. 6 digits)
BLF: Busy Lamp Field (0 = Out of Service/1 = In Service)
STEP 3:ASPAN - Assign the number of digit of access code...

NEAX2400 IPX Feature Programming ManualPage 464NDA-24297, Issue 1
M-1 Meet-Me Paging
M-1 Meet-Me Paging
General Description
This feature allows a user dial access to paging equipment, and connects both parties automatically, after the called
party has answered the page.
Operating Procedure
To page
1. Calling station dials the Paging access code; receives continuous ringback tone for 1 second.
2. Calling station pages the desired party.
3. Calling station remains off-hook or hangs up.
To answer
1. Called...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 465
Meet-Me Paging M-1
Interactions (cont’d)
4. BUSY VERIFICATION [B-3] and EXECUTIVE OVERRIDE [E-1]: These features will be denied for a
connection that includes the Paging route.
5. DELAY OPERATION: Station A is connected to party B. Station A momentarily presses the switch hook
and dials the MEET-ME PAGE route access code. When connected to the page, Station A requests Station
C to dial the MEET-ME PAGE answer code. Station A hangs up....

NEAX2400 IPX Feature Programming ManualPage 466NDA-24297, Issue 1
M-1 Meet-Me Paging
Programming (cont’d)
STEP 5:ANPD- Reserve levels for trunk access and for MEET-ME PAGE answer and cancel codes. Assign
the trunk access level for a Connection Index (CI) of Normal (N) and Hooking (H) service. Number of
necessary digits is usually one or two. Busy Lamp Field is not activated. If the MEET-ME PAGE
answer and cancel codes reside in a level reserved for features, then assign according to a
predetermined...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 467
Miscellaneous Trunk Access M-2
M-2  Miscellaneous Trunk Access
General Description
This feature provides access to all types of external and customer provided equipment/facilities, such as FX [F-2],
WATS [W-1], CCSA [C-14], TIE LINE [T-3], and Exchange Network, along with DICTATION [D-3], PAGING
[P-1], and CODE CALLING [C-21].
Operating Procedure
MISCELLANEOUS TRUNK ACCESS is accomplished via system data programming at the MAINTENANCE...
