NEC Neax 2400 Ipx Office Data Specification

NDA-24298 CHAPTER 4
Page 557
Issue 1
ALRNN : Assignment of Logical Route and Route Class Data for NDM
Figure 4-17    SMDR2 (ALRNN)
Table 4-24 SMDR2 (ALRNN)
CONTENTS/INPUT 0123456789101112131415
b00-Detailed billing is not required for incoming calls.××××
1-Detailed billing is required for incoming calls.××××
b10-Detailed billing is required for toll and local
outgoing calls.
×× ××
1-Detailed billing is required only for toll outgoing
calls.×× ××
b2, 30-
1-Metering pulses are used.××××
2-
3-
b0b1b2b3...

CHAPTER 4 NDA-24298
Page 558
Issue 1
ALRNN : Assignment of Logical Route and Route Class Data for NDM
LOGICAL ROUTE (LGRT) 1-899
REMARKS FUSION POINT CODE (FPC) 1-253
ROUTE NUMBER (RT) 1-255
24 OC 0= -
1 = Originating Category Information is used For MFC signaling
(Brazil and Mexico)
25 R/LAttendant-Identification of Incoming Trunk Display.
0 = TN, RT, TK display
1 = C.O. Line Number display
26 RVSDTrunk Reversal Identification
This data is necessary when a specific Trunk route provides
battery...

NDA-24298 CHAPTER 4
Page 559
Issue 1
ALRNN : Assignment of Logical Route and Route Class Data for NDM
32 ICRLRelease timing for incoming trunk connections.
 0 = 288 msec.Note 1 = 224 msec.
 2 = 288 msec.  3 = 352 msec.
 4 = 416 msec.  5 = 480 msec.
 6 = 544 msec.  7 = 608 msec.
 8 = 672 msec.  9 = 736 msec.
10 = 800 msec. 11 = 864 msec.
12 = 928 msec. 13 = 992 msec.
14 = 1056 msec. 15 = 1120 msec. Normally assign
data “0”.
For ISDN, see Table
4-25 (Example of
Route Class
Settings).
Note:160...

CHAPTER 4 NDA-24298
Page 560
Issue 1
ALRNN : Assignment of Logical Route and Route Class Data for NDM
40 TCMTravel Class Mark
0 = Out of Service 1 = In Service
41 TDMQTandem Off Hook OG Queuing
0 = Out of Service 1 = In Service
42 TRSCTrunk Restriction class
0 = Out of Service 1-15= In ServiceSee AEFR command.
43 BT Inter-office Busy Service
0 = Out of Service 1 = In ServiceFor CCIS voice route,
assign data “1.”
44 PRVLine Trunk Privacy
0 = Privacy Out of Service
1 = Privacy In Service For Busy...

NDA-24298 CHAPTER 4
Page 561
Issue 1
ALRNN : Assignment of Logical Route and Route Class Data for NDM
5 7 HDTHeterogeneous Data Trunk
0 = Not Heterogeneous Data Trunk
1 = Heterogeneous Data Trunk
58 CDConsecutive Dialing
0 = Out of Service 1 = In Service
59 CCHCommon Channel Handler
0 = CCH is not mounted (normal setting)
1 = CCH is mounted (ISDN or CCIS line) 0000Always assign data “0”
even ISDN/CCIS.
60 TC/EC 0 0 0 0 Always assign data “0.”
61 IRE Inter-rearranging signal
1=SupervisoryWhen assigning...

CHAPTER 4 NDA-24298
Page 562
Issue 1
ALRNN : Assignment of Logical Route and Route Class Data for NDM
71 TCMCTCM and KP Sending Sequence
0=KP-ST 1=KP TCM-ST
2 = TCM KP-ST 3 = KP (TCM)-STUse this when ONSG/
INSG = 4 (MF).
7 2 MFSPSending Speed
Tone ON Tone OFF   Digit/sec.
     0= 68 msec.  68 msec. 7.5
     1 = 56   m sec.  56 m sec. (C CITT No.5 )          Note
     2= 68 msec.  32 msec. 10
     3= 68 msec.  36 msec. 10
     4= 48 msec.  48 msec. 10
     5= 52 msec.  52 msec. 10
6-15= Not used
(In...

NDA-24298 CHAPTER 4
Page 563
Issue 1
ALRNN : Assignment of Logical Route and Route Class Data for NDM
7 4 KPPTPause after KP sending
 0 = 48 msec.  1 = 56 msec.
 5 = 88 msec.  6 = 96 msec.
 7 = 104 msec.  8 = 112 msec.
12 = 144 msec. 13 = 152 msec.
14 = 160 msec. 15 = 168 msec.
(In case of MFC)
 0 = 12.0 sec.    1 = 5.5 sec.
 2 = 7.0 sec. 3 = 8.5 sec.
 4 = 10.0 sec.  5 = 11.5 sec.
 6 = 13.0 sec.  7 = 14.5 sec.
 8 = 16.0 sec. 9 = 17.5 sec.
10 = 20.0 sec. 11 = 22.0 sec.
12 = 24.0 sec. 13 = 26.0...

CHAPTER 4 NDA-24298
Page 564
Issue 1
ALRNN : Assignment of Logical Route and Route Class Data for NDM
80 MPTM Sender Minimum Pause
 0 = 10 PPS/600 msec., 20 PPS/450 msec.
 1 = 600 msec.  2 = 800 msec.
 3 = 1000 msec. 4 = 1200 msec.
 5 = 1400 msec.  6 = 1600 msec.
 7 = 1800 msec.  8 = 2000 msec.
 9 = 2200 msec. 10 = 2400 msec.
11 = 2600 msec. 12 = 2800 msec.
13 = 3000 msec. 14 = 3200 msec.
15 = 3400 msec.
(In case of MFC)
 0 = 12.0 sec.  1 = 5.5 sec.
 2 = 7.0 sec. 3 = 8.5 sec.
 4 = 10.0 sec.  5 =...

NDA-24298 CHAPTER 4
Page 565
Issue 1
ALRNN : Assignment of Logical Route and Route Class Data for NDM
91 TOCITrunk Override Calling
0 = Override Inhibited (Calling side).
1 = Tie Line Override Service is provided (Calling side).
92 TOCDTrunk Override Called
0 = Override Inhibited (Called side).
1 = Tie Line Override Service is provided (Called side).
9 3 ODGD 0 0 0 0 Always  assi gn  data “0.”
94 RLS 0 0 0 0 Always assign data “0.”
95 GWDGate Way Data Service
      0= Out of Service 1 = Gate Way...

CHAPTER 4 NDA-24298
Page 566
Issue 1
ALRNN : Assignment of Logical Route and Route Class Data for NDM
Table 4-25 provides examples of standard route class settings.
114 DCH 0 0 0 0 Always assign data “0.”
115 CMRT Common use of Route Numbers of ISDN trunks
0 = Out of Service 1 = In Service
116 PREF 0 0 0 0 Always assign data “0.”
117 DFS 0 0 0 0 Always assign data “0.”
118 BOBBroad Band
0=64K 1=N
× 64K0000
119 HO1CH 0 0 0 0 Always assign data “0.”
120 IFRIndonesia Compulsion Cut Service
0 = Out of...
