NEC Neax 2400 Ipx Office Data Specification

NDA-24298 CHAPTER 4
Page 517
Issue 1
ARTD : Assignment of Route Class Data
4. Data Sheet
RT
FUNCTIONREMARKS
1OSGSSignal Interface for Outgoing
0=CCIS No.7 1=RingDown
2 = Second Dial Tone 3 = Not used
4 = Sender (Immediate Start) Note
5=Not used
6 = Sender (Delay Dial Start)
7 = Sender (Wink start) 8-15= Not used Note:The select
signal in
ONSG should
be “DP.”
2 ONSGSignal Selection for Outgoing
0 = Not used 1 = DP, 10 pps, 33% Make
2 = PB, 60msec. Interruption or CCIS No.7
3=DP/PB 4=MF
5 = DP, 20...

CHAPTER 4 NDA-24298
Page 518
Issue 1
ARTD : Assignment of Route Class Data
Figure 4-15   SMDR2
b0b1b2b3
0/1: -/Incoming Call (SMDR is required)
0/1: SMDR is required for toll and local out-
going calls/SMDR is required only for toll
outgoing calls.
0:
1:
2:
3:Metering pulses are necessary. Hexadecimal
assignment is “01.”
Example:
b0b1b2b3
00 01
84 21b0=bit 0
b
1=bit 1...
The following explains what hexadecimal data “1” means for SMDR2:
 For incoming calls SMDR is required because Bit 0 is assigned as...

NDA-24298 CHAPTER 4
Page 519
Issue 1
ARTD : Assignment of Route Class Data
RT
FUNCTIONREMARKS
1OSGSSignal Interface for Outgoing
0=CCIS No.7 1=RingDown
2 = Second Dial Tone 3 = Not used
4 = Sender (Immediate Start) Note
5=Not used
6 = Sender (Delay Dial Start)
7 = Sender (Wink start) 8-15= Not used Note:The select
signal in
ONSG should
be “DP.”
2 ONSGSignal Interface for Outgoing
0 = Not used 1 = DP, 10 pps, 33% Make
2 = PB, 60msec. Interruption or CCIS No.7
3=DP/PB 4=MF
5 = DP, 20 pps, 33% Make...

CHAPTER 4 NDA-24298
Page 520
Issue 1
ARTD : Assignment of Route Class Data
6TCLTrunk Class
Specify the kind of trunk
 1 = DDD Line  2 = FX
 3 = WATS Line
 4 = Tie Line/Announcement Trunk
 5 = CCSA  6 = Toll Terminal
 7= CAS Line 8 = Paging
 9 = Code Call Trunk 10 = Dictation Trunk
11 = General Paging
12 = Radio Paging Trunk 13 - 31= Not used
7L/TLine/Trunk Identification
0 = Not used (Line) 1 = Trunk11111Always assign data “1.”
8RLPTrunk Release Pattern
0 = Calling Party Release (Outgoing only)
1=Not...

NDA-24298 CHAPTER 4
Page 521
Issue 1
ARTD : Assignment of Route Class Data
15 LSGLine Signal
0=Loop
1 = Ground Start C.O. Line
2=CDH
3 = Caller ID (Loop)
4=Loop
5=E&M Tie Line
6=DX
7=24V4
8 = Loop DID 9 - 11 = Not used
12 = Speech Line (for CCIS No. 7 or Bch of ISDN)
13 = Signal Line (for CCIS No. 7 or Dch of ISDN)
14-15 = Not used
16 SMDR2 Detailed Billing InformationSee Figure 4-15 and
Table 4-20.
17 H/MHotel Service in CCIS No. 7
0 = Out of Service 1 = In Service
18MC 00000Always assign data “0.”
19...

CHAPTER 4 NDA-24298
Page 522
Issue 1
ARTD : Assignment of Route Class Data
RT
FUNCTIONREMARKS
24 OC 0= -
1 = Originating Category Information is used For MFC signaling
(Brazil and Mexico)
25 R/LAttendant-Identification of Incoming Trunk Display.
0 = TN, RT, TK display
1 = C.O. Line Number display
26 RVSDTrunk Reversal Identification
This data is necessary when a specific Trunk route provides
battery reversal for answer super-vision.
0 = Battery Reversal System
1=Third Wire System
27 TL  Tone Level...

NDA-24298 CHAPTER 4
Page 523
Issue 1
ARTD : Assignment of Route Class Data
3 2 ICRLRelease timing for incoming trunk connections.
 0  =  288 msec.     Note       1 =  224 msec.
 2  =  288 msec.             3 =  352 msec.
 4  =  416 msec.             5 =  480 msec.
 6  =  544 msec.             7 =  608 msec.
 8  =  672 msec.             9 =  736 msec.
10 = 800 msec.        11 = 864 msec.
12 = 928 msec.        13 = 992 msec.
14 = 1056 msec.       15 = 1120 msec. Normally assign
data “0.
For ISDN,...

CHAPTER 4 NDA-24298
Page 524
Issue 1
ARTD : Assignment of Route Class Data
39 BCC.O Line Idle Balance Condition.
0 = Not balanced       1 = BalancedFor Australia only
40 TCMTravel Class Mark
0 = Out of Service       1 = In Service
41 TDMQTandem Off Hook OG Queuing
0 = Out of Service       1 = In Service
42 TRSCTrunk Restriction class
0 = Out of Service       1-15 =  In ServiceSee AEFR command.
43 BT Inter-office Busy Service
0 = Out of Service       1 = In ServiceFor CCIS voice route,
assign data “1.
44...

NDA-24298 CHAPTER 4
Page 525
Issue 1
ARTD : Assignment of Route Class Data
56 SMDR3Detailed billing for outgoing in tandem connection.
0 = Required     1 = Not requiredAssign this for the
incoming route (ICRT),
if necessary.
5 7 HDTHeterogeneous Data Trunk
0 = Not Heterogeneous Data Trunk
1 = Heterogeneous Data Trunk
58 CDConsecutive Dialing
0  = Out of Service      1  = In Service
59 CCHCommon Channel Handler
0 = CCH is not mounted (normal setting)
1  =  CCH is mounted (ISDN or CCIS line )...

CHAPTER 4 NDA-24298
Page 526
Issue 1
ARTD : Assignment of Route Class Data
68 SCFSplit Call Forwarding
The call is forwarded to the desired destination assigned at
0  = Split C. F. - All Calls (SSC, SID = 8), Split C. F. -
Busy Line (SSC, SID = 10), Split C. F. - Don’t An-
swer (SSC, SID = 12)
1  = C. F. - All Calls (SSCA, SIDA = 86), C. F. - Busy
Line (SSCA, SIDA = 87), C. F. - Don’t Answer (SS
CA, SIDA = 88) This data is valid when
ASYD, SYS,INDEX 79,
b2 = 1.
69 SMDR4Detailed billing for incoming...
