NEC Neax 2400 Ipx Office Data Specification

NDA-24298 CHAPTER 4
Page 547
Issue 1
ARTDN : Assignment of Route Class Data for NDM
8 1 LPTMSender Inter-Digit Pause Index
  0 = DP/1 sec., PB/0.5sec.   1 = 600 msec.
  2 = 800 msec.   3 = 1000 msec.
  4 = 1200 msec.   5 = 1400 msec.
  6 = 1600 msec.      7 = 1800 msec.
  8 = 2000 msec.   9 = 2200 msec.
10 = 2400 msec. 11 = 2600 msec.
12 = 2800 msec. 13 = 3000 msec.
14 = 3200 msec. 15 = 3400 msec.
(In case of MFC)
  0 = 12.0 sec.   1 = 5.5 sec.
  2 = 7.0 sec.   3 = 8.5 sec.
  4 = 10.0 sec.   5 =...

CHAPTER 4 NDA-24298
Page 548
Issue 1
ARTDN : Assignment of Route Class Data for NDM
98 CIISDN transmitting information
    0 = Out of Service
    1 = 16-Digit Caller Number Service, Attribute Informa-
tion Notification Service, and Calling Sub-Address
Transfer Service
2-15= Not used
99 OID 0 0 0 0 Always assign data“0.”
100 TKS 0 0 0 0 Always assign data“0.”
101 PAD2Pad Control Data 2
0-7 = For Pad value, See the NEAX2400 IPX Circuit Card
Manual.PAD value can also be
set by switch setting on
the...

NDA-24298 CHAPTER 4
Page 549
Issue 1
ARTDN : Assignment of Route Class Data for NDM
Table 4-23 provides examples of standard route class settings.
12 1 CONVSMDR Called Number Conversation
0 = Conversation Number
1 = In Service
122 OPRTOriginally Trunk Information
0 = Out of Service 1 = In Service
123 CNICalling Number Identification Format
0=No ANI
1 = Feature Group D Format
2=Not used 3=Not used
Table 4-23 Examples of Route Class Settings
PARAMETERKIND OF LOGICAL TRUNK ROUTE
DUMMY
ROUTE ANALOG
C.O...

CHAPTER 4 NDA-24298
Page 550
Issue 1
ARTDN : Assignment of Route Class Data for NDM
23 TR 0 0 0 0 0 0 0 0
24 OC 0 0 0 0 0 0 0 0
25R/L 00000000
26 RVSD 0 0 0 0 0 0 0 0
27 TL 0 0 0 0 0 0 0 0
28 ANS 0 1 1 1 0 1 1 0
29 TELP 0 0 0 0 0 0 0 0
30PAD 00047470
31OGRL00000100
32 ICRL 0 0 0 0 0 1 0 0
33 HD 0 0 0 0 0 0 0 0
34GUARD00000000
35 WINK 0 0 0 0 0 0 0 0
36VAD00000000
37CLD00000000
38 FA 0 0 0 0 0 0 0 0
39 BC 0 0 0 0 0 0 0 0
40TCM00000000
41 TDMQ 0 0 0 0 0 0 0 0
42 TRSC 0 0 0 0 0 0 0 0
43 BT 0 0 0 1 0 0 0 0...

NDA-24298 CHAPTER 4
Page 551
Issue 1
ARTDN : Assignment of Route Class Data for NDM
60TC/EC00000000
61IRE 00000000
62SCR 00000000
63LYER100000000
64NET 00000000
65 INT 0 0 0 0 0 0
66 DC 0 0 0 0 0 0
67 HKS 0 0 0 0 0 0 0 0
68SCF 00000000
69SMDR400000000
70 TCMN 0 0 0 0 0 0 0 0
71 TCMC 0 0 0 0 0 0 0 0
72 MFSP 0 0 0 0 0 0 0 0
73 KPST 0 0 0 0 0 0 0 0
74 KPPT 0 0 0 0 0 0 0 0
75STC 00000000
76 MC 0 0 0 0 0 0 0 0
77 MT 0 0 0 0 0 0 0 0
78 TONE 0 0 0 0 0 0 0 0
79 PPTM 0 0 0 0 0 0 0 0
80 MPTM 0 0 0 0 0 0 0 0
81...

CHAPTER 4 NDA-24298
Page 552
Issue 1
ARTDN : Assignment of Route Class Data for NDM
97 DT 0 0 0 0 0 0 0 0
98 CI 0 0 0 0 0 0 0 0
99OID 00000000
100 TKS 0 0 0 0 0 0 0 0
101 PAD2 0 0 0 0 0 0 0 0
102 TRM 0 0 0 0 0 0 0 0
103TRPX00000000
104 LDR 0 0 0 0 0 0 0 0
105 TSC 0 0 0 0 0 0 0 0
106SATS00000000
107RVPX00000000
108DQ 00000000
109SLOV00000000
110SDTO00000000
111ADVPRA0000000
112 IND 0 0 0 0 0 0 0 0
113 UUI 0 0 0 0 0 0 0 0
114 DCH 0 0 0 0 0 0 0 0
115CMRT00000000
116PREF00000000
117 DFS 0 0 0 0 0 0 0 0
118...

NDA-24298 CHAPTER 4
Page 553
Issue 1
ALRNN : Assignment of Logical Route and Route Class Data for NDM
ALRNN: Assignment of Logical Route and Route Class Data for NDM
1. General
As the functions of ALRTN, ARTD and ARTDN commands are combined into this command, it can be used
to allocate the Logical Route number and to assign/delete Route Class data at the same time. The data assigned
by this command is written in Network Data Memory (NDM) of the Network Control Node (NCN), updating
the NDM at each Local...

CHAPTER 4 NDA-24298
Page 554
Issue 1
ALRNN : Assignment of Logical Route and Route Class Data for NDM
4. Data Sheet
LOGICAL ROUTE (LGRT) 1-899
REMARKS FUSION POINT CODE (FPC) 1-253
ROUTE NUMBER (RT) 1-255
1OSGSSignal Interface for Outgoing
0 = CCIS No.7 1 = RingDown
2 = Second Dial Tone 3 = Not used
4 = Sender (Immediate Start)Note
5=Not used
6 = Sender (Delay Dial Start)
7 = Sender (Wink start) 8-15= Not used Note:The select
signal in
ONSG should
be “DP.”
2 ONSGSignal Selection for Outgoing
 0 =...

NDA-24298 CHAPTER 4
Page 555
Issue 1
ALRNN : Assignment of Logical Route and Route Class Data for NDM
6TCLTrunk Class
Specify the kind of trunk
 1 = DDD Line 2= FX
 3= WATS Line
 4 = Tie Line/Announcement Trunk
 5= CCSA 6 = Toll Terminal
 7= CAS Line 8= Paging
 9 = Code Call Trunk 10 = Dictation Trunk
11 = General Paging Trunk
12 = Radio Paging Trunk 13 - 31 = Not used
7L/TLine/Trunk Identification
0 = Not used (Line) 1 = Trunk11111Always assign data “1.”
8RLPTrunk Release Pattern
0 = Calling Party...

CHAPTER 4 NDA-24298
Page 556
Issue 1
ALRNN : Assignment of Logical Route and Route Class Data for NDM
15 LSGLine Signal
 0= Loop
 1 = Ground Start C.O. Line
 2= CCH
 3 = Caller ID (Loop)
 4= Loop
 5 = E&M Tie Line
 6= DX
 7= 24V4
 8 = Loop DID 9 - 11 = Not used
12 = Speech Line (for CCIS No. 7 or Bch of ISDN)
13 = Signal Line (for CCIS No. 7 or Dch of ISDN)
14 = Not used     15 = Not used
16 SMDR2 Detailed Billing InformationSee Figure 4-17 and
Table 4-24.
17 H/MHotel Service in CCIS No. 7
0 = Out of...
