Panasonic Digital Color Imaging System DP-C106 Operating Instructions

Tools Mode
59
Limit Copy Set
The maximum number of copies allowed for a single job can be set between
1 set and 99 sets.
Use the following procedure to select a Limit Copy Set number:
1. Press the Tools button to display the Tools Main Menu on the Copier
Screen.
2.  Using the (        ) ARROW buttons highlight the Admin menu option.
3. Press the Select button. Password Input is displayed on the Copier
Screen.
4.  Using the Numeric Keypad, enter your Administrator Password. The
numbers display as...

Tools Mode
60
Timer Preset
The DP-C106 has time limits for certain conditions. In Tools Mode, you can
change the timer settings for the following options:
• Auto Reset: If the Copier/Printer is not operated within a designated
amount of time, the machine returns to print mode. The time-out before
returning to print mode can be 1 – 4 minutes.
• Reset Time: When the DP-C106 is in an error condition, the error
message automatically returns to the main screen after a certain time.
This allows printing to...

Tools Mode
61
6.  Use the (        ) ARROW buttons to highlight the Timer preset selection.
7. Press the Select button. Timer Preset selection is displayed on the
Copier Screen.
8.  Use the (        ) ARROW buttons to highlight the desired Timer feature
that you wish to change. Press the Select button.
If you are setting the Energy Saver Timer you must first turn the Energy
Saver Mode On and then you may set a time. Using the (        ) ARROW
buttons, highlight On and then press the Select button. The...

Tools Mode
62
Sound Preset
The DP-C106 emits tones when it is in certain conditions. These tones alert
you when the Copier/Printer has reached a certain state.
The following Audio Tone selections are available on the DP-C106:
• Valid Tone: An entry can be made so that a tone is produced when the
buttons of the control panel are pressed accurately.
• Invalid Tone: An entry can be made so that a tone is produced when
copying ends abnormally, such as when paper runs out or there is a
paper or document jam....

Tools Mode
63
6.  Use the (        ) ARROW buttons to highlight the Sound preset selection.
7. Press the Select button. Audio Tones selection is displayed on the
Copier Screen.
8.  Use the (        ) ARROW buttons to select the audio tone feature you
would like to change.
9. Press the Select button to open the selection screen for the selected
audio tone option.
10.  Use the (        ) ARROW buttons to highlight Off or On for the selected
Audio Tone.
11. Press the Select button. Audio Tone selection is...

Tools Mode
64
3. Press the Select button. Password Input is displayed on the Copier
Screen.
4.  Using the Numeric Keypad, enter your Administrator Password. The
numbers display as asterisks (*).
If you make a mistake while entering a password, press the Clear button.
5.  Once the correct password is entered, the Administrator Menu is
displayed on the Copier Screen.
6.  Use the (        ) ARROW buttons to highlight the Use Password selection.
7. Press the Select button. User Password selection is...

Tools Mode
65
ADMIN Password
The password for the machine supervisor is set to 9999 when the machine
ships from the factory. For secure control of the machine, please change this
password as soon as possible.
The Administrator Password can not be checked after it is entered. Record
this password so that it is not forgotten.
Use the following steps to change the Admin Password:
1. Press the Tools button to display the Tools Main Menu on the Copier
Screen.
2.  Using the ARROW buttons highlight the Admin...

Tools Mode
66
Version Information
If you should ever run into problems with your DP-C106 and have the need to
call for service, you may need to provide your software version information to
the service engineer helping you. You can access all software version
information through Tools Mode.
Use the following procedure to access Version Information:
1. Press the Tools button to display the Tools Main Menu on the Copier
Screen.
2.  Using the (        ) ARROW buttons highlight the Admin menu selection.
3....

Tools Mode
67
Self Diagnostics
The Self Diagnostics test allows you to prompt the DP-C106 to assess the
hardware status.
Use the following procedure to begin the self-diagnostics test:
1. Press the Tools button to display the Tools Main Menu on the Copier
Screen.
2.  Using the (        ) ARROW buttons highlight the Admin menu selection.
3. Press the Select button. Password Input is displayed on the Copier
Screen.
4.  Using the Numeric Keypad, enter your Administrator Password. The
numbers display as...

Tools Mode
68
Transporting the Scanner
The scanner module must be locked when transporting the DP-C106 to
ensure against damage.  Locking the module keeps it from sliding and either
damaging itself or causing damage to other parts of the scanner.
Use the following procedure to lock the scanner module:
1. Press the Tools button to display the Tools Main Menu on the Copier
Screen.
2.  Using the (        ) ARROW buttons highlight the Admin menu selection.
3. Press the Select button. Password Input is...
