Main Unit
Front
Document guides
ADF door release
Feed extension tray
Document guides selector
Exit guides
Exit tray
Exit stoppers
Exit extension tray
ADF door
Manual feed selector
Switches the scanning method between continuous scanning (Auto) and manual scanning (Manual).
Feed tray
Control panel
For details, refer to "Control Panel and LED Indicators" (page 13).
Operating Manual11L
o
c
a
t
i
o
n
o
f
C
o
n
t
r
o
l
s
Location of Controls7
1
2
3
4
5
8
9
10
11
126

Rear
Imprinter door
You open this door when installing an imprinter unit (sold separately) or ink cartridge. For details about
installing an imprinter, refer to "Installing the Imprinter Unit and Ink Cartridge" (page 67).
Fan exhaust vent
AC inlet
Power cord
Plugs may vary in shape depending on country/area.
USB connector
12Operating Manual
Location of Controls1
2
3
54

Control Panel and LED IndicatorsASkip button (SKIP)
If you press this button after a double feed or a dog -eared document is detected and scanning has
been paused, the document that was detected as a double feed or the dog -eared document will be
scanned, and then ejected from the scanner. Scanning will continue after the document is scanned and ejected.BLED ( Green )
Shows the scanner’s status.CPower button ()
Press the power button for more than one second to turn the unit off.DLCD (KV-S5076H only)
If...

About LEDThe status of the scanner is displayed by the LED (Green) (C) and the LED  (Red) (D), as shown in the
table below:C  LED ( Green )D LED ( Red)StatusOFFOFFPower OFF *1ONOFFReady mode or ScanningBlinking (Slow)OFFSleep mode *2OFFONError*3Blinking (Fast)OFFWarming upBlinking (Fast, 2 times consecutively)OFFDouble Feed Skip modeBlinking (Fast, 3 times consecutively)OFFDog-ear Detection Skip mode
*1
If the power off feature in sleep mode is enabled, and if no operation is performed for a certain...

About the Installation LocationIn order to ensure proper operation, install the unit maintaining the proper distances from surrounding objects,
as shown in the following illustration.
Notice
•Do not move the unit immediately from a cold place to a warm place. It may cause dew.
Note
•It is recommended to move this unit with two persons, and holding it by both side grips.
• The weight of this unit is approximately 24 kg (53 lb.) when packaged, or approximately 18 kg
(39.5 lb.) by itself.
Operating...

Installing the Unit1.Remove all packing tape.
2. Push the ADF door release ( A) upwards, and open the ADF door ( B).
3. Use the indents ( A) to pull the double feed prevention roller cover towards you to open it.
16Operating Manual
Installation12 1

4.Install the double feed prevention roller.
• Align the shaft that is shaped as indicated by  A with the notch in the roller mount  (B ), and then insert
the shaft in the notch. Push the shaft on the opposite side ( C) until it clicks into place.
Notice
•After you install the double feed prevention roller, make sure that the shaft is inserted into the tab.
If the roller is not installed correctly, it may cause double feeding or a paper jam.
Operating Manual17
Installation1
132
2

5.Push the double feed prevention roller cover until it clicks into place to close it.
Notice
•Make sure that the double feed prevention roller cover does not stick up.
If the double feed prevention roller cover is closed incompletely, damage or paper jams can occur.
6. Close the ADF door.
• Push both sides of the ADF door down slowly until it clicks into place.
18Operating Manual
Installation

7.Connect the power cord and the USB cable to the scanner.
Notice
•Use only the power cord and the USB cable that are provided with the unit.
• When the unit is not used over an extended period of time, turn the unit off, and unplug the power
cord. The unit consumes approximately 0.3 W of electricity even when the main unit is turned off.
• Do not turn ON the unit’s power before installing the software.
Operating Manual19
InstallationUSB connector
To the computer USB Cable To the AC outletPower cordAC...

Installing the SoftwareThe software on the enclosed Software / Manual CD-ROM can be installed on your computer.
You can select from the 2 installation methods below, depending on your needs.
a. Complete : Install all the drivers, applications, utilities and Operating Manual.
b. Custom : Install one of the software or Operating Manual.
Note
•Normally, it is recommended to select [Complete].
Notice
•Make sure to log on as an administrator to install the software.
1. Check that the unit has been turned...
