1.Prepare the following cleaning supplies.
• Soft and dry cloth
Used to clean the conveyor.
• Thin cotton swab
Used to clean the ion outlets and sensors.
• Roller cleaning paper (KV-SS03)
Used to clean the rollers, scanning backgrounds, and scanning glasses.
Use of the roller cleaning paper is recommended. If you do not have the roller cleaning paper, use a
soft cloth with a small amount of isopropyl alcohol or water.
Do not use commercially available cleaners, detergent, thinner, or benzine. (Doing so...

5.Close the ADF door.
• After cleaning, push both sides of the ADF door down slowly until it clicks into place.
6.Press the power button to turn on the unit’s power.
Notice
•If roller cleaning notifications via the After Clean Roller Counter are enabled, after turning on the
unit’s power, reset the After Clean Roller Counter in User Utility to 0.
For details, refer to the User Utility help.
52Operating Manual
Care and Maintenance

Cleaning the Conveyor1.With a soft and dry cloth, wipe off any dirt on the conveyor ( A).
2. With a soft and dry cloth, wipe off any dirt on the self-cleaning brushes ( C, D ) of the reference plates
( A , B ).
• Push  E and  F in the direction indicated by the arrow to rotate the reference plate on the ADF door
side so that you can clean the brush. In the same way, push  G and  H in the direction indicated by the
arrow to rotate the reference plate on the main unit side to clean the brush.
Operating...

Cleaning the Ion Outlets and Sensors1.Remove dust from the ion outlets ( A) with a cotton swab.
• With a thin cotton swab, remove dust from the ion outlets, and then wipe the center of the inner parts
approximately 5 times.
Notice
•Do not apply too much pressure on the parts.
2. Remove dust from the sensors ( A, B , C , D , E , F ) and reflectors ( G) with a cotton swab.
Location of Sensors
AWaiting sensorBDouble feed detectorCSlip detect sensorDStarting sensorEPaper sensorFSkew sensor54Operating Manual...

Location of ReflectorsGReflectors Operating Manual55
Care and Maintenance7 7

Cleaning the Rollers1.Use the roller cleaning paper (page 50) to remove the dirt from the surfaces of all rollers.
Direction to wipe rollersDouble feed prevention roller, Separation rollerOther rollers
Notice •After removing the double feed prevention roller, gently wipe dirt from the surface of the roller in
the direction indicated by the arrows in the illustration. If you wipe too hard, you may damage or
misalign the roller.
For instructions on how to remove the double feed prevention roller, see...

Location of RollersAPaper feed rollerBSeparation rollerCFree rollersDDouble feed prevention rollerEDrive rollers  Operating Manual57
Care and Maintenance3
4
12 5

Cleaning the Scanning Backgrounds1.Wipe the scanning backgrounds ( C, D ) on each reference plate ( A, B ) with the roller cleaning paper
(page 50).
• Push  E and  F in the direction indicated by the arrow to rotate the reference plate on the ADF door
side. Clean both the white and black backgrounds. In the same way, push  G and  H in the direction
indicated by the arrow to rotate the reference plate on the main unit side to clean the white and black
backgrounds.58Operating Manual
Care and Maintenance56...

Cleaning the Scanning Glasses1.Wipe the scanning glasses ( A, B ) with the roller cleaning paper (page 50).
Location of Scanning GlassesAScanning glass (F)BScanning glass (B)Operating Manual59
Care and Maintenance1 2

Consumables and Optional Accessories Part NamePart NumberNotes
Consumables
Roller exchange kit
• Paper feed roller
module
• Double feed prevention
roller
KV-SS060—
Roller cleaning paperKV-SS03See "About the roller cleaning
paper" (page 50).
Ink cartridgeKV-SS021
For optional imprinter unit.
For instructions on installation and
removal, see "Installing the
Imprinter Unit and Ink Cartridge"
(page 67).
Optional
AccessoriesImprinter unitKV-SS014
Prints text and numbers on
documents. Includes...
