Performing push scan using the LCD (KV-S5076H
only) If you are using a  KV-S5076H with Image Capture Plus, you can perform push scan using the LCD. Registered
jobs are displayed on the LCD. Use the cursor button ( A) and OK button ( B) to select a job.
Note
•Register jobs in advance. For details about registering jobs, refer to the Image Capture Plus help.
• The group name is displayed on the first line, and the job name is displayed on the second line of the
LCD.
1. Place the documents on the feed tray...

Using Control SheetsPlacing a control sheet in the middle of documents lets you change the scanning conditions for pages scanned
after the control sheet. Also, you can change the folder used to save the scan data of documents scanned
after the control sheet.
• Print out control sheets from the included CD-ROM.
Control sheet functions
Simplex, Duplex, Binary, 256 level gray, Color, Dynamic Threshold, Dither, Error diffusion, Function #1–
#9, Separation Sheet
• For details about control sheets, refer to...

About Printing Control Sheets•Print the control sheet at the specified size; do not enlarge or reduce the size.
• When printing the control sheet, make sure that the pattern is 25 mm (1 in.) from the top of the page and
centered horizontally.
• Use the control sheet that is the same size as the document you are scanning.
• Be careful not to get the control sheet dirty. Do not fold or crease the control sheet. Scanning will not be
performed properly.
• For details about control sheets, refer to...

Printing control sheets
Note•In order to print control sheets, Adobe Reader must be installed on your computer.
• Refer to the instruction manual for your printer for details about changing print settings.
1. Insert the included CD-ROM into the CD/DVD driver on your computer.
• If you have a feature called "Autorun" activated, the installation process will start automatically.
• The setup window will appear.
Note
•If the AutoPlay dialog box is displayed, select [CDRun.exe].
• If the setup window...

Clearing Paper JamsTorn paper, thin paper or paper that is creased on the top edge may cause paper jams. If a paper jam occurs,
remove the jammed sheet according to the following procedure.
CAUTION
•Do not touch the conveyor immediately after continuous scanning.
This area becomes very hot and can cause burns.
Wait until the conveyor’s temperature decreases.
1. Push the ADF door release ( A) upwards, and open the ADF door ( B).
• Remove any documents from the feed tray.
Operating Manual45C
l
e
a
r
i
n
g...

2.Remove the jammed sheet of paper.
When a paper jam occurs inside the scanner:
Remove the jammed sheet of paper from the inside of the ADF door.
When a paper jam occurs at the exit slot:
Pull the jammed paper from the exit slot ( A) towards the front.
46Operating Manual
Clearing Paper Jams 1

3.Close the ADF door.
• Push both sides of the ADF door down slowly until it clicks into place.Operating Manual47
Clearing Paper Jams

Cleaning the Outside of the Scanner
Notice•Do not use commercially available cleaners, detergent, thinner, or benzine. (Doing so may cause
deformation, discoloration or damage.)
• Clean the scanner at least once a month.
1. Press and hold the power button for one second or more to turn off the unit’s power.
2. Clean the outside of the scanner with a soft, slightly damp cloth.
• The document feeder ( A) and exit slot ( B) get dirty easily. Make sure to clean them.
3. Remove dirt and dust from the fan...

Cleaning the Inside of the Scanner
CAUTION•Do not touch the conveyor immediately after continuous scanning.
This area becomes very hot and can cause burns.
Wait until the conveyor’s temperature decreases.
Note
•Clean the inside of the scanner when approximately 20,000 sheets have been scanned. The time for
cleaning may differ depending on documents you scan. To maintain proper scanning, clean the scanner
parts frequently.
• Clean the rollers and sensors if paper jamming or double feeding occurs...

About the roller cleaning paperUsing a pair of scissors, open the bag along the dotted line ( A), and take out the roller cleaning paper.
Notice
•Keep the roller cleaning paper out of reach of small children.
• Do not store the roller cleaning paper in direct sunlight or in a place with temperature over 40 °C
(104 °F).
• Only use the roller cleaning paper to clean the rollers and scanning glass.
• For details about the roller cleaning paper, please refer to the Material Safety Data Sheet (MSDS).
