Panasonic Document Scanner Kv S5076h_s5046h Operating Manual

When Scanning Documents ManuallyYou can select either continuous scanning (Auto) or manual scanning (Manual) by using the manual feed
selector.
Continuous scanning (Auto)
Manual scanning (Manual)
Notice •When scanning a document manually (Manual), feed the document 1 sheet at a time.
• When scanning important documents or bound documents, feed them manually.
Note
•When scanning a document manually (Manual), the double feed detection function is disabled.
Operating Manual31
Operation

When Scanning Documents with Pages of Different Sizes at One
Time When scanning documents with pages of different sizes at one time, please note the following.
• Align the document pages along one side.
• Align the document position so that the center of the smallest sheet will be fed to the center of the paper
feed roller, and adjust the document guides accordingly.
• Exiting sheets may become out of order on the exit tray. Documents may need to be reordered after they
are scanned.
1. Slide the document...

2.Completely spread apart the document guides ( A).
3. Align the documents sheet by sheet at one corner.
Align the documents sheet by sheet at one corner as shown below. Documents that stick together, are not
aligned correctly at one corner, or are at an angle cannot be fed correctly.
Operating Manual33
Operation1 ABC
A

4.Place the documents on the feed tray ( A) with the scanning side facing up.
• Align the document position so that the center of the smallest sheet will be fed to the center of the paper
feed roller ( B). If the document is not properly aligned, the pages will not be fed correctly.
Notice
•The height of the documents should not exceed the limit mark ( C) on the document guide.
Exceeding the limit mark may cause a paper jam or skewing.
• Depending on the types of paper, the document may not be fed...

When scanning long sheets of paper
Pull out the feed extension tray ( D) from the feed tray.
5. Adjust the left and right document guides ( A) to the width of the documents.
Operating Manual35
Operation4 A
1

6.Remove the document, and then slide the document guides selector in the direction shown in the illustration
until the
 ( A ) and  (B ) marks are aligned.
7. Place the document on the feed tray again and adjust the document guide according to the size of the
document to be scanned.
Notice
•Make sure to align the document pages along one side.
• Make sure that the center of the smallest sheet of the document will be fed to the center of the
paper slot.
• To secure the document guides, lower the document...

Adjusting the left and right document guides to their original position1.Slide the document guides selector in the direction shown in the illustration until the
 (A ) and  (B )
marks are aligned.
2. Completely spread apart the document guides.
3. Slide the document guides selector in the direction shown in the illustration until the
 (A ) and  (B )
marks are aligned.
Operating Manual37
Operation  12   12

When Changing the Scanned Data Background ColorUsing the software, you can switch the background color of scanned images between white and black.
For details, refer to the Image Capture Plus, TWAIN, or ISIS help.38Operating Manual
Operation

Starting Up Scanner Applications AutomaticallyYou can configure settings so that the application starts up automatically by  "placing a document on the unit ’s
feed tray" ("Touch Free Scanning") or by "Single Touch Scanning".
Note
•If you are using a KV-S5076H, you can perform push scan using the LCD (page 41).
• If you are using a KV-S5046H, press the Start/Stop button to perform Single Touch Scanning.
Setting the application to start up Set whether an application will...

Checking eventsCheck the following if an application does not start up after being set.
1. Display the Scan properties screen.
• If you are using Windows 8 / Windows 7:
[Control Panel]  ® [View devices and printers], right-click the scanner icon, and display the [Scan
properties] screen.
• If you are using Windows Vista:
[Control Panel]  ® [Scanners and Cameras], select the scanner icon, and then click the Properties
button.
• If you are using Windows XP:
[Control Panel]  ® [Scanners and Cameras],...
