Panasonic Projector PT-DS12KU User Manual

Chapter 4 Settings — [SIGNAL LIST] menu
ENGLISH - 131
 fTo cancel the deletion, press the  button to return to the  [REGISTERED SIGNAL LIST] screen.
3) Press the  button.
 fThe selected signal will be deleted.
Note
 fA registered signal can also be deleted from [REGISTERED SIGNAL DELETE] on the [REGISTERED SIGNAL SETUP] screen.
Protecting the registered signal
1) Press  asqw to select the signal to protect.
2)
Press the  button.
 f The  [REGISTERED SIGNAL STATUS] screen is displayed.
3) Press the...

Chapter 4 Settings — [SIGNAL LIST] menu
132 - ENGLISH
Sub memory
The projector has a sub memory function that can register the multiple image adjustment data, even if it is recognized as the same signal by
the frequency or format of the synchronization signal source.
Use this function when you need to adjust the picture quality such as switching of the aspect ratio or white balance by the same
synchronization signal source. The sub memory includes all the data that can be adjusted for each signal, such...

Chapter 4 Settings — [SECURITY] menu
ENGLISH - 133
[SECURITY] menu
On the menu screen, select [SECURITY] from the main menu, and select an \
item from the sub-
menu.
Refer to “Navigating through the menu” (x
  page   65) for the operation of the menu screen.
 fWhen the projector is used for the first time
Initial password: Press  awsqawsq in order

, and press the  button.
 fAfter selecting the item, press

asqw to set.
Attention
 fWhen you select the [SECURITY] menu and press the  button, entering a...

Chapter 4 Settings — [SECURITY] menu
134 - ENGLISH
 fWhen numerical values are used for the security password, the security password is required to be initialized if the remote control is lost.
Consult your dealer for the method of initialization.
[DISPLAY SETTING]
Overlap the security message (text or image) over the projecting image.
1) Press  as to select [DISPLAY SETTING].
2)
Press
 qw to switch the item.
 fThe items will switch each time you press the button.
[OFF] The text display is disabled....

Chapter 4 Settings — [SECURITY] menu
ENGLISH - 135
2) Press the  button.
 fThe  [CONTROL DEVICE SETUP] screen is displayed.
3) Press  as to select [CONTROL PANEL] or [REMOTE CONTROL].
4)
Press the  button.
5)


Press
 as to select [CONTROL PANEL] or [REMOTE CONTROL].
6)

Press
 qw to switch [USER].
7)

Press
 as to select the button item to set.
 fWhen [INPUT  SELECT BUTTON] is selected, press the  button, and then press as to select the button to set.
Buttons that can be set
[CONTROL PANEL]...

Chapter 4 Settings — [SECURITY] menu
136 - ENGLISH
4) Press asqw to select [OK], and press the  button.
 fTo cancel, select [CANCEL].
Attention
 fThe initial password is “AAAA” by the factory default or when [ALL  USER DA TA] in [INITIALIZE] (x   page   125) is executed. fChange the password periodically that is hard to guess.

Chapter 4 Settings — [NETWORK] menu
ENGLISH - 137
[NETWORK] menu
On the menu screen, select [NETWORK] from the main menu, and select an i\
tem from the sub-
menu.
Refer to “Navigating through the menu” (x
  page   65) for the operation of the menu screen.
 fAfter selecting the item, press

asqw to set.
[NETWORK SETUP]
Perform the initial setting of the network before using the network function.
1) Press  as to select [NETWORK SETUP].
2)
Press the  button.
 f The  [NETWORK SETUP] screen is displayed....

Chapter 4 Settings — [NETWORK] menu
138 - ENGLISH
4) Press as to select [STORE], and press the  button.
5)
When the confirmation screen is displayed, press  qw

 to select [OK], and press the  button.
[NETWORK STATUS]
Display the status of the projector network.
1) Press as to select [NETWORK STATUS].
2)
Press the  button.
 f The  [NETWORK STATUS] screen is displayed.
[Art-Net SETUP]
Make settings to use the Art-Net function.
1) Press  as to select [Art-Net SETUP].
2)
Press
 qw to select an item....

Chapter 4 Settings — [NETWORK] menu
ENGLISH - 139
 rExample of a normal network connection
SDI 1/2
Computer
Projector
LAN cable (straight) LAN cable (straight) Hub
 fA web browser is required to use this function. Confirm that the web browser can be used beforehand.
Compatible OS: Windows XP/Windows Vista/Windows 7/Windows 8, Mac OS   X   v10.4/v10.5/v10.6/v10.7/v10.8
Compatible browser: Internet Explorer 7.0/8.0/9.0/10.0, Safari 4.0/5.0/6.0 (Mac OS)
 f Communication with an E-mail server is required to...

Chapter 4 Settings — [NETWORK] menu
140 - ENGLISH
Accessing from the web browser
1) Start up the web browser on the computer.
2)
Enter the IP
  address set on the projector into the URL entry field of the web browser.
3)

Enter the user name and the password.
 f The factory default setting of the user name is user1 (user rights)/admin1 (administrator rights) and the password is panasonic (lower
case).
4) Click OK.
 fThe [Projector status] page is displayed.
