Stiga Lawn Mower 8211-3500-02 12,5 12,5 HST Instruction Manual

45
DEUTSCHDE
LUFTFILTER
Wichtig! Niemals den Motor laufen lassen, wenn
der Luftfilter nicht montiert ist.
Der Vorfilter I ist alle 3 Monate oder alle 25 Be-
triebsstunden zu reinigen (Abb 17).
Den Papierfilter J jährlich oder alle 100 Betriebs-
stunden reinigen (Abb 17).
Achtung! Der Luftfilter ist öfter zu reinigen, wenn
der Boden staubig ist.
1. Schutzabdeckung, danach Schaumstoff-Filter
abnehmen.
2. Vorfilter in Wasser (mit Geschirrspülmittel) wa-
schen. Gut ausdrücken. Etwas Öl auf das Filter...

46
DEUTSCHDE
6. Der Riemenbügel L an der Motorriemenscheibe
soll bei gespanntem Keilriemen 3 - 5 mm vom
Keilriemen entfernt sein.
TREIBRIEMEN MOTOR - GETRIEBE
1. Den Riemenbügel L an der Motorriemenscheibe
lösen und ihn zur Seite drehen (Abb 20).
2. Den unteren Keilriemen abheben.
3. Die Spannrolle O am Kupplungsarm losschrau-
ben.
4. Den Keilriemen entfernen.
5. Den neuen Keilriemen auf seinen Platz legen. In
umgekehrter Reihenfolge zusammenmontieren.
Das Montieren geht leichter, wenn das Pedal...

47
DEUTSCHDE
13. Nach einigen Fahrstunden ist der Drahtzug er-
neut zu justieren
14. Den Lenkdrahtzug nicht zu stark spannen. Dies
kann unnötigen Verschleiß von Lenkdrahtzug,
Seilrollen usw. verursachen.
EINSTELLEN DER NEUTRALLAGE
(12,5 HST)
Bewegt sich (“kriecht”) der Mäher, wenn der
Fahrthebel in der gekennzeichneten Neutrallage
ist, sind Nacheinstellungen vorzunehmen.
1. Motor anlassen und im Leerlauf laufen lassen.
2. Das Auskupplungspedal darf nicht durchge-
drückt sein. (Eine Person muß sich...

48
ENGLISHGB
GENERAL
This symbol indicates WARNING. Per-
sonal injury and/or damage to property
may result if the instructions are not fol-
lowed carefully.
SYMBOLS
The following symbols are displayed on the ma-
chine in order to remind you about the safety pre-
cautions and attention necessary when using the
machine.
The symbols mean:
Warning!
Read the instruction book and safety man-
ual before using the machine.
Warning!
Beware of objects being flung out. Keep
spectators away.
Warning!
Always use...

49
ENGLISHGB
ENGINE CASING
Loosen the screw which fastens the front part of the
engine casing to the chassis.
Then unhook the three rubber loops D and E (fig 7).
Lift off the engine casing diagonally upwards/ back-
wards.
Before use - fit the black engine cover onto the en-
gine casing.
Do not use the machine without first fit-
ting the engine casing, otherwise there is
a risk of burn injuries or crushing acci-
dents.
BATTERY
The battery is a valve-regulated battery with 12 V
nominal voltage. The...

50
ENGLISHGB
1. Pedal released - forward
drive engaged, The machine
will move if a gear is engaged.
Service brake not activated.
2. Pedal only half depressed -
forward drive released, gear-
shifting can be performed.
Service brake not activated.
3. Pedal fully depressed - for-
ward drive released, Service
brake fully activated.
3. FREEWHEEL CLUTCH PEDAL
(12,5 HST)
Foot pedal for disengaging the transmission. Two
positions:
1. Pedal released - forward
drive engaged. The machine
will start off...

51
ENGLISHGB
1. Drive
Controls the machine’s direction of travel
and speed. Move the lever forward (F) -
the machine moves forward. The further
forward the lever is pushed, the faster the
machine moves.
Lever in the marked neutral position (N) -
the machine stands still. (If not, see “AD-
JUSTING THE NEUTRAL POSITION”
below).
Move the lever first outward and then
backward from the neutral position (R) -
the machine will reverse.
2. Cruise control
Inertia in the lever allows it to be released in...

52
ENGLISHGB
The maximum vertical load on the towing hitch
must not exceed 100 N.
The maximum over-run load on the towing hitch
from towed accessories must not exceed 500 N.
BEFORE STARTING
You must read these instructions for
use and the accompanying pamphlet
SAFETY INSTRUCTIONS careful-
ly before starting up the machine.
FILLING THE FUEL TANK
Always use lead-free petrol. Never use
oil-mixed 2-stroke petrol.
NOTE! Bear in mind that petrol is a perishable, do
not purchase more petrol than can be...

53
ENGLISHGB
2. Make sure that the sparking plug cable is prop-
erly in place.
3. Check to make sure the power take-off is en-
gaged.
4a. 12,5:
Put the gear lever in neutral.
4b. 12,5 HST:
Put the drive lever into neutral.
5. Starting cold engine - put the throttle control in
the choke position. Starting warm engine - put the
throttle control at full throttle (1 - 1.5 cm above the
choke position).
6. Depress the pedal fully.
7. Turn the starter key and start the engine.
8. Once the engine has...

54
ENGLISHGB
Always use a good grade of oil (service grade SE,
SF or SG).
The motor oil may be very warm if it is
drained off directly after the motor is
shut off. Therefore, allow the motor to
cool a few minutes before draining the
oil.
1. Tilt the machine to the left.
2. Screw out the oil drain plug F (fig 14). This is
situated on the left side of the engine (viewed from
rear). Let the oil run out into a collection vessel.
Do not allow oil to get on the v-belts.
3. Screw in the plug again.
4....
