NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 468NDA-24297, Issue 1
M-3 Miscellaneous Trunk Restriction
M-3 Miscellaneous Trunk Restriction
General Description
This feature provides for certain stations and certain dial-repeating TIE trunks to be denied access to particular trunk
groups, such as FX [F-2], WATS [W-1], CCSA [C-14], TIE LINE [T-3], Exchange Network, DICTATION [D-3]
or PAGING [P-1].
Operating Procedure
MISCELLANEOUS TRUNK RESTRICTION is accomplished via system data programming at the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 469
Miscellaneous Trunk Restriction M-3
Programming
STEP 1:ASYD- System Data 2, Index 1, Bits 4 & 5. Should a restricted station be routed to the Attendant
Console or receive reorder tone?
Reorder Tone: Bit 4 = 0, Bit 5 = 0.
Attendant Console: Bit 4 = 1, Bit 5 = 0.
STEP 2:ARSC- Follow the procedure for [M-2] MISCELLANEOUS TRUNK ACCESS [M-2]. By assigning
the ARSC command, restrict RSCs from receiving certain routes. RRI 3: RES must be“2”if...

NEAX2400 IPX Feature Programming ManualPage 470NDA-24297, Issue 1
M-4 Multiple Console Operation
M-4  Multiple Console Operation
General Description
This feature allows one or more ATTENDANT CONSOLEs [A-3] to operate within the same system.
Operating Procedure
No manual operation is required.
Service Conditions
1. The maximum number of consoles per PIM is 4.
2. The maximum number of consoles allowable per system is:
1IMG: 16
4IMG/IPX-U: 60
3. Each incoming call is displayed on an ATTENDANT CONSOLE [A-3],...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 471
Multiple Console Operation M-4
Interactions (cont’d)
4. When more than one Attendant Console is installed, a Primary Attendant Console may be assigned
(AMAT command). This Attendant Console will control the implementation of DAY/NIGHT CLASS OF
SERVICE [D-15].
5. If the Primary Attendant places the system into Night mode, the Night LED on the other consoles do not
light.
Programming
STEP 1:ASYD- System Data 1, Index 9. Assign the number of...

NEAX2400 IPX Feature Programming ManualPage 472NDA-24297, Issue 1
M-7 Music On Hold
M-7 Music On Hold
General Description
This feature allows a party to hear music while in the CALL HOLD [C-6], CALL TRANSFER [C-10, 11], or
ATTENDANT CAMP-ON WITH TONE INDICATION [A-1] conditions.
Operating Procedure
No manual operation is required for this software controlled feature.
Service Conditions
1. The system is capable of supplying two switch-selectable music channels. Music is generated by 3
synthesizers...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 473
Meet-Me Paging - Attendant M-11
M-11  Meet-Me Paging - Attendant
General Description
This feature allows an Attendant to hold an incoming call, page the called party, and connect the two after the called
party has answered the page.
Operating Procedure
Procedure 1
To page
1. Place the incoming call on hold by pressing the HOLD key.
2. The Attendant seizes an idle loop.
3. The Attendant dials the paging access code; receives continuous...

NEAX2400 IPX Feature Programming ManualPage 474NDA-24297, Issue 1
M-11 Meet-Me Paging - Attendant
Service Conditions (cont’d)
9. A Page waiting to be answered is automatically cancelled after a predetermined programmed duration. See
VARIABLE TIMING PARAMETERS[V-1]for selectable timing choices.
10. Loop signaling is the recommended signaling type.
a.) Both MEET-ME PAGING and PAGING ACCESS [P-1] (loudspeaker - basic) can be provided in
thesamesystem.
b.) A separate access code for MEET-ME PAGING and PAGING...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 475
Meet-Me Paging - Attendant M-11
Interactions
1. MEET-ME PAGING and PAGING ACCESS [P-1] can be provided simultaneously in the same system.
ARTD, CDN 6:TCL must be assigned as data“8”for MEET-ME PAGE, while PAGING ACCESS routes
maybeassignedasdata“11”, General Page, or as data“1”, DDD. Separate access codes for each feature
is required. MEET-ME PAGING answer and cancel codes are required for each MEET-ME PAGING
zone.
2. MEET-ME PAGING is...

NEAX2400 IPX Feature Programming ManualPage 476NDA-24297, Issue 1
M-11 Meet-Me Paging - Attendant
Programming (cont’d)
STEP 2:ARTD- Assign the Paging route as shown below:
RT: 1
1-OSGS :2 2-ONSG :3 5-TF :1 6-TCL :8 7-L/T :1
8-RLP :2 15-LSG :0/1
STEP 3:AT R K- Assign the LENs, Paging Trunk Route Number, Trunk Number, and Tenant Number.
STEP 4:MBTK- Assign the Make Idle status to the Paging trunks.
STEP 5:ANPD- Reserve levels for trunk access and for PAGE answer and cancel codes. Assign the trunk
access...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 477
Maintenance Printout M-15
M-15 Maintenance Printout
General Description
The NEAX2400 IPX can provide a hard copy of maintenance and system management data via the
MAINTENANCE ADMINISTRATION TERMINAL (MAT) [M-18] printer.
Operating Procedure
Refer to the NEAX2400 IPX Office Data Specification.
Service Conditions
The following hard copy reports can be obtained
1. History printout for command execution: When the command is executed, the...
