NEC Neax 2400 Ipx Office Data Specification

NDA-24298 CHAPTER 4
Page 497
Issue 1
AHLS : Assignment of Hot Line Station
AHLS: Assignment of Hot Line Station
1. General
This command assigns the data related to the Hot Line service feature.
2. Precautions
1. Prior to assigning this command, the Hot Line station should be given the TEC = 14 (Hot Line class) by
the ASDT/AAST command. Additionally, TEC = 13 (Data Terminal via D
term) and TEC = 18 (Virtual
Line Appearance) can also be applied to the Hot Line service.
2. If you want to delete the station...

CHAPTER 4 NDA-24298
Page 498
Issue 1
AHLS : Assignment of Hot Line Station
4. Data Sheet
(a) Connection Type: Station (Type = 1)
HOTLINE
TENANT
NUMBER
(HOT TN)HOTLINE
STATION NUMBER
(STN)TYPEDESTINATION
STATION’S
TENANT
NUMBER
(CON TN)DESTINATION
STATION NUMBER
(STN)REMARKS
1

NDA-24298 CHAPTER 4
Page 499
Issue 1
AHLS : Assignment of Hot Line Station
(b) Connection Type: Abbreviated Digit Code (ADC) (Type = 2)
HOTLINE
TENANT
NUMBER
(HOT TN)HOTLINE
STATION NUMBER
(STN)TYPEDESTINATION
STATION’S
TENANT
NUMBER
(CON TN)SPEED CALLING
CODE
(ADC)
MAX. 4 DIGITSREMARKS
2

CHAPTER 4 NDA-24298
Page 500
Issue 1
AHLS : Assignment of Hot Line Station
(c) Connection Type: Trunk Line Appearance (Type = 3)
HOTLINE
TENANT
NUMBER
(HOT TN)HOTLINE
STATION NUMBER
(STN)TYPEDESTINATION
STATION’S
ROUTE
NUMBER
(CON RT)OPPOSITE
PA R T Y’S
TRUNK NUMBER
(TK)REMARKS
3

NDA-24298 CHAPTER 4
Page 501
Issue 1
AHLSN : Assignment of Hot Line Station for NDM
AHLSN: Assignment of Hot Line Station for NDM
1. General
This command assigns the data related to the Hot Line service feature. The data assigned by this command is
written in the Network Data Memory (NDM) of the Network Control Node (NCN), updating the NDM at each
Local Node (LN).
2. Precautions
1. Prior to assigning this command, the Hot Line station should be given the TEC = 14 (Hot Line class) using
the ASDT command....

CHAPTER 4 NDA-24298
Page 502
Issue 1
AHLSN : Assignment of Hot Line Station for NDM
4. Data Sheet
(a) Connection Type: Station (Type = 1)
HOTLINE
USER GROUP
NUMBER
(HOT UGN)HOTLINE
TELEPHONE NUMBER
(HOT TELN)
MAX. 16 DIGITSTYPEDESTINATION
STATION’S
USER GROUP
NUMBER
(CON UGN)DESTINATION
TELEPHONE NUMBER
(CON TELN)
1

NDA-24298 CHAPTER 4
Page 503
Issue 1
AHLSN : Assignment of Hot Line Station for NDM
(b) Connection Type: Abbreviated Digit Code (ADC) (Type = 2)
HOTLINE
USER GROUP
NUMBER
(HOT UGN)HOTLINE
TELEPHONE NUMBER
(HOT TELN)TYPEDESTINATION’S
USER GROUP
NUMBER
(CON UGN)SPEED CALLING
CODE (ADC)
MAX. 4 DIGITSREMARKS
2

CHAPTER 4 NDA-24298
Page 504
Issue 1
AHLSN : Assignment of Hot Line Station for NDM
(c) Connection Type: Trunk Line Appearance (Type = 3)
HOTLINE
USER GROUP
NUMBER
(HOT UGN)HOTLINE
TELEPHONE NUMBER
(HOT TELN)TYPEDESTINATION
STATION’S
LOGICAL ROUTE
NUMBER
(CON LGRT)OPPOSITE
PA R T Y’S
TRUNK NUMBER
(TK)
3

NDA-24298 CHAPTER 4
Page 505
Issue 1
ADA1_T : Assignment of DTE Attribute Data 1 – Telephone Number
ADA1_T : Assignment of DTE Attribute Data 1 – Telephone Number
1. General
This command is used to assign and delete Attribute Data 1 for each terminal (DTE). Attribute Data 1 is stored
as the office data of the switching unit, and is rarely modified in normal operation. Attribute Data 2, on the other
hand, is stored on the data terminal side and is modified in the course of operation. The station data can...

CHAPTER 4 NDA-24298
Page 506
Issue 1
ADA1_T : Assignment of DTE Attribute Data 1 – Telephone Number
4. Data Sheet
Note: The existing data can be readout by pressing “Get” button after UGN and TELN is entered.
CDNUser Group Number (UGN)
Telephone Number (TELN) Max. 16 digits
1MEDIAMedia (1-15)
1=Voice
 2=Data
3=FAX
 4=Telex
5=Teletex
 6=Image
7-15=Not used
2CNTPConnection Protocol (0-15)
0=ICS Protocol
1=X.20
 2=X.21
3=V.24 200 Series
4=X.20 bis
 5=X.21 bis
6-15=Not used
3TCPTransmission Control...
