NEC Neax 2400 Ipx Office Data Specification

NDA-24298 CHAPTER 4
Page 747
Issue 1
ACFCL : Assignment of Call Forwarding by SFC for LDM
(c) TYPE = 3 (ASYD SYS1, INDEX5 bit0 = 0 and INDEX79 bit2 = 1 is assigned);
DAY/ NIG HT
MODE
(D/N)TENANT
NUMBER
(TN)SERVICE
FEATURE
CLASS
(SFC)
0-15
CALL FORWARD ALL CALLS DESTINATION FOR
STATIONS
(CFAS)
MAX. 24 DIGITS [0-9, *, #]CALL FORWARD BUSY/DO NOT ANSWER
DESTINATION FOR STATIONS
(CFBS/CFDS)
MAX. 24 DIGITS [0-9, *, #]
CALL FORWARD ALL CALLS DESTINATION FOR
TRUNKS
(CFAT)
MAX. 24 DIGITS [0-9, *,...

CHAPTER 4 NDA-24298
Page 748
Issue 1
ACFCL : Assignment of Call Forwarding by SFC for LDM
(d) TYPE = 4 (ASYD SYS1, INDEX5 bit0 = 1 and INDEX79 bit2 = 1 is assigned);
DAY/ NIG HT
MODE
(D/N)TENANT
NUMBER
(TN)SERVICE
FEATURE
CLASS
(SFC)
0-15
CALL FORWARD ALL CALLS
DESTINATION  FOR STATIONS
(CFAS)
MAX. 24 DIGITS [0-9, *, #]CALL FORWARD BUSY
DESTINATION FOR STATIONS
(CFBS)
MAX. 24 DIGITS [0-9, *, #]CALL FORWARD DO NOT ANSWER
DESTINATION FOR STATIONS
(CFDS)
MAX. 24 DIGITS [0-9, *, #]
CALL FORWARD...

NDA-24298 CHAPTER 4
Page 749
Issue 1
ASLU1 : Assignment of Slumber Time Data 1
ASLU1: Assignment of Slumber Time Data 1
1. General
This command assigns the data related to the Slumber Time - Do Not Disturb service feature.
2. Precautions
1. The call terminating to the slumber group is forwarded to an Attendant Console or an Announcement
trunk (DAT circuit card) with a predetermined slumber time.
2. The station numbers belonging to the slumber group are assigned by the ASLU1 command.
3. The slumber time...

CHAPTER 4 NDA-24298
Page 750
Issue 1
ASLU1 : Assignment of Slumber Time Data 1
4. Data Sheet
TENANT
NUMBER
(TN)STATION
NUMBER
(STN)SLUMBER GROUP
NUMBER
(G)
1 – 7REMARKS

NDA-24298 CHAPTER 4
Page 751
Issue 1
ASLU1_T : Assignment of Slumber Time Data 1 – Telephone Number
ASLU1_T : Assignment of Slumber Time Data 1 – Telephone Number
1. General
This command is used to assign the data related to the Slumber Time - Do Not Disturb service feature. The sta-
tion data of ASLU1 command can be assigned by using Telephone Number.
2. Precautions
1. Only the Telephone Numbers assigned by the ALGSN command can be used. Telephone Numbers by the
ALGSL command is not available in this...

CHAPTER 4 NDA-24298
Page 752
Issue 1
ASLU1_T : Assignment of Slumber Time Data 1 – Telephone Number
4. Data Sheet

USER
GROUP
NUMBER
(UGN)TELEPHONE NUMBER
(TELN)
Max. 16 digitsSLUMBER
GROUP
NUMBER
(G)
1-7REMARKS

NDA-24298 CHAPTER 4
Page 753
Issue 1
ASLU2 : Assignment of Slumber Time Data 2
ASLU2: Assignment of Slumber Time Data 2
1. General
This command assigns the data related to the Slumber Time - Do Not Disturb service feature.
2. Precautions
1. The slumber time period and the forwarded destination are assigned by this command. A maximum of
four (4) different time periods can be assigned as the Slumber Time.
2. The G parameter corresponds to the one assigned by the ASLU1 command. The station numbers...

CHAPTER 4 NDA-24298
Page 754
Issue 1
ASLU2 : Assignment of Slumber Time Data 2
3. Data Entry Instructions
SLUMBER
TIME GROUP
NUMBER
(G)
1-7CNT
1-4TRANSFER
KIND
(TFR)
1/2SLUMBER TIME
START TIMESLUMBER TIME
END TIME
FROM
HOURFROM
MINUTETO
HOURTO MINUTE
G
Enter the number assigned by the ASLU1
command.SLUMBER TIME
Enter the time period for restricting the incoming call.
TFR
1 = Attendant
2 = Announcement

NDA-24298 CHAPTER 4
Page 755
Issue 1
ASLU2 : Assignment of Slumber Time Data 2
4. Data Sheet

SLUMBER TIME
GROUP
NUMBER
(G)
1-7CNT
1-4TRANSFER KIND
(TFR)
1/2SLUMBER TIME
START TIMESLUMBER TIME
END TIME
REMARKS
FROM HOURFROM
MINUTETO
HOURTO
MINUTE
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4

CHAPTER 4 NDA-24298
Page 756
Issue 1
ACSA : Assignment of Connection Service Index A
ACSA: Assignment of Connection Service Index A
1. General
This command assigns the call termination for CAS Line and Direct-in Termination (Day Only).
2. Precautions
1. The ACFR command assignment is also required to assign the trunk incoming call termination service
feature.
2. CAS data at the Satellite Station
(a) It is necessary to set the Telephone Class (TEC) of the CAS Line to “15” in the ASDT command.
(b) A...
