NEC Neax 2400 Ipx Office Data Specification

NDA-24298 CHAPTER 4
Page 797
Issue 1
AARS : Assignment of Alternative Route Service Restriction
AARS: Assignment of Alternative Route Service Restriction
1. General
This command assigns various service connections between the outgoing route and the incoming route when
they are to be restricted, or to assign the existing restrictions when such service connections are to be canceled.
2. Precautions
If the data is not assigned, the specified connections are to be restricted.
3. Data Entry Instructions...

CHAPTER 4 NDA-24298
Page 798
Issue 1
AARS : Assignment of Alternative Route Service Restriction
4. Data Sheet
INCOMING
ROUTE
 NUMBER
(ICRT)OUTGOING ROUTE
 NUMBER
(OGRT)ROUTE SERVICE
 (RSV)
0/1RESTRICTION DATA
 (RES)
 0 – 2REMARKS

NDA-24298 CHAPTER 4
Page 799
Issue 1
AARSN : Assignment of Alternative Route Service Restriction for NDM
AARSN: Assignment of Alternative Route Service Restriction for NDM
1. General
This command assigns various service connections between the outgoing route and the incoming route when
they are to be restricted, or to assign the existing restrictions when such service connections are to be canceled.
The data assigned by this command is written in the Network Data Memory (NDM) of the Network Control
Node...

CHAPTER 4 NDA-24298
Page 800
Issue 1
AARSN : Assignment of Alternative Route Service Restriction for NDM
4. Data Sheet
INCOMING LOGICAL
ROUTE NUMBER
(IC_LGRT)
1-899OUTGOING LOGICAL
ROUTE NUMBER
(OG-LGRT)
1-899ROUTE SERVICE
(RSV)
0/1RESTRICTION
DATA
(RES)
0-2REMARKS

NDA-24298 CHAPTER 4
Page 801
Issue 1
ALPE: Assignment of Line Privacy Expansion Data
ALPE:Assignment of Line Privacy Expansion Data
1. General
This command assigns the eight-party Conference Trunk (CFT card), which is seized in Line Privacy Expansion
Service on a per-tenant basis.
2. Precautions
1. Enter the data “1” at the TN parameter when “1” is entered at the TNF parameter.
2. The applicable Tenant Number (TN) range is designated by the ASYD command, SYS 1, INDEX 8.
3. The Station Number entered in...

CHAPTER 4 NDA-24298
Page 802
Issue 1
ALPE: Assignment of Line Privacy Expansion Data
4. Data Sheet
TENANT FLAG
(TNF)
0/1TENANT
NUMBER
 (TN)STATION NUMBER
(STN)
MAX. 6 DIGITSREMARKS

NDA-24298 CHAPTER 4
Page 803
Issue 1
ARPC : Assignment of Remote Point Code for Centralized Service
ARPC: Assignment of Remote Point Code for Centralized Service
1. General
This command assigns the data related to the Message Center Interface - CCIS service feature.
2. Precautions
1. This command is used only at the main office of the Message Center Interface - CCIS service feature.
2. The MCI is installed at the main office of the CCIS network, and the MCI text is transmitted (or received)
to (from)...

CHAPTER 4 NDA-24298
Page 804
Issue 1
ARPC : Assignment of Remote Point Code for Centralized Service
4. Data Sheet
CENTRALIZED SERVICE
NUMBER
(CSN)
1-7REMOTE POINT CODE
COUNTER
(CNT)
1-32REMOTE POINT CODE
(RPC)
1-16383REMARKS
11
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32

NDA-24298 CHAPTER 4
Page 805
Issue 1
ARDN : Assignment of Remote Control Day/Night
ARDN: Assignment of Remote Control Day/Night
1. General
This command assigns the data related to the Centralized Day/Night Mode Change service feature.
2. Precautions
1. This command is used only at the Main office which controls the Day/Night mode for the satellite office
via the CCIS link.
2. When there are multiple satellite offices created by grouping tenant numbers, the mode can be changed on
all the satellite...

CHAPTER 4 NDA-24298
Page 806
Issue 1
ARDN : Assignment of Remote Control Day/Night
3. Data Entry Instructions
4. Data Sheet
POINT CODE INDEX
 (INDEX)
0 – 15POINT CODE
(PC)
1 – 16383REMARKS
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
POINT CODE INDEX
          (INDEX)
             0-15POINT CODE
        (PC)
    1-16383REMARKS
INDEX
Enter an arbitrary unique number within
the range from 0 to 15.PC
Enter the PC of satellite office.
